Operation
™
Pro Plus
A30 / Pro Plus
- For Portable Spray Applications of Architectural Paints and Coatings -
Models:
™
Pro Plus
A30 (16E664) - Series B
Maximum Working Pressure: 207 bar, 21 MPa (3000 PSI)
Includes:
•
0.91 lpm (0.24 gpm) cart-mount sprayer
•
SG3 gun - Manual 312830
•
0.635 cm (1/4 in) x 7.5 m (25 ft) hose
™
Pro Plus
A45 (16E665) - Series B
Maximum Working Pressure: 207 bar, 21 MPa (3000 PSI)
Includes:
•
1.17 lpm (0.31 gpm) cart-mount sprayer
•
SG3 gun - Manual 312830
•
0.635 cm (1/4 in.) x 15 m (50 ft) hose
Important Safety Instructions
Read all warnings and instructions in this
manual. Save these instructions.
Pro Plus A30
(16E664)
™
A45 Airless Sprayer
- Not for use in explosive atmospheres -
Use water-based or mineral spirit-type materials only.
Do not use materials having flash points lower than 70°
F (21° C). For more information about your material,
request MSDS from distributor or retailer.
Pro Plus A45
(16E665)
3A1177B
EN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Magnum Pro Plus A30 and is the answer not in the manual?

Questions and answers

Related Manuals for Graco Magnum Pro Plus A30

Summary of Contents for Graco Magnum Pro Plus A30

  • Page 1 Operation 3A1177B ™ ™ Pro Plus A30 / Pro Plus A45 Airless Sprayer - For Portable Spray Applications of Architectural Paints and Coatings - - Not for use in explosive atmospheres - Models: ™ Pro Plus A30 (16E664) - Series B Maximum Working Pressure: 207 bar, 21 MPa (3000 PSI) Use water-based or mineral spirit-type materials only.

  • Page 2: Table Of Contents

    Tip Number ......14 Graco Standard Warranty ....24 Spraying Techniques .

  • Page 3: Warnings

    Warnings Warnings The following warnings are for the setup, use, grounding, maintenance and repair of this equipment. The exclamation point symbol alerts you to a general warning and the hazard symbol refers to procedure-specific risks. Refer back to these warnings. Additional, product-specific warnings may be found throughout the body of this manual where appli- cable.
  • Page 4 All parts of the spray system, including the pump, hose assembly, spray gun, and objects in and around the spray area shall be properly grounded to protect against static discharge and sparks. Use Graco conductive or grounded high-pressure airless paint sprayer hoses.
  • Page 5 Warnings WARNING WARNING WARNING WARNING PRESSURIZED ALUMINUM PARTS HAZARD Use of fluids that are incompatible with aluminum in pressurized equipment can cause serious chemical reaction and equipment rupture. Failure to follow this warning can result in death, serious injury, or property damage. •...

  • Page 6: Grounding Instructions

    Grounding Instructions Grounding Instructions 3. Do not use an extension cord with damaged ground plug. Recommended extension cords: Sprayer must be grounded. Grounding reduces the risk •15 m (49.2 ft) 1.0 mm of static and electric shock by providing an escape wire •30 m (98.4 ft) 1.5 mm for electrical current due to static build up or in the event of a short circuit.

  • Page 7: Component Identification (16E664)

    Component Identification (16E664) Component Identification (16E664) ti15963a Paint hose SG3 airless spray gun Electric motor (inside enclosure) Tip guard Power switch Reversible spray tip Pressure control knob Trigger safety lever Pump fluid outlet fitting Gun fluid inlet fitting Suction Tube Smooth Glide™...

  • Page 8: Component Identification (16E665)

    Component Identification (16E665) Component Identification (16E665) ti15964a SG3 airless spray gun Tip guard Electric motor (inside enclosure) Reversible spray tip Power switch Trigger safety lever Pressure control knob Gun fluid inlet fitting Pump fluid outlet fitting Smooth Glide™ swivel Suction Tube Gun fluid filter (in handle) Prime tube (with diffuser) W Hose/cord wrap bracket...

  • Page 9: Pressure Relief Procedure

    Pressure Relief Procedure Pressure Relief Procedure Follow this Pressure Relief Procedure whenever you 3. Turn Prime/Spray valve to PRIME. stop spraying and before cleaning, checking, servicing, or transporting equipment. ti2019a 4. Turn pressure control knob left (minimum pressure). 1. Turn OFF power switch. ti2018a ti2020a 2.

  • Page 10: Setup

    Setup Setup Install Tip and Guard on Gun 1. Turn OFF power switch. 1. Engage trigger lock. ti2018a ti8908a 2. Connect one end of grounded fluid hose to SG3 spray gun. Use a wrench to tighten. 2. Verify tip and guard parts are assembled in order shown.

  • Page 11: Unclogging Spray Tip

    Setup Unclogging Spray Tip 3. Aim gun at piece of scrap or cardboard. 4. Unlock trigger lock. Pull trigger to clear clog. To avoid fluid splash back: Never pull gun trigger when arrow-shaped • handle is between SPRAY and UNCLOG ti8909a positions.

  • Page 12: Priming

    Priming Priming 5. Push pump priming button two times. For flushing storage fluid and loading pump and hose with paint. ti15972a Before priming sprayer, follow Cleaning procedure, Steps 1-6, 6. Turn ON power switch. Align arrow on sprayer and page 16. bucket symbol on pressure control knob.

  • Page 13: Selecting The Right Tip

    Selecting the Right Tip Selecting the Right Tip Tip Hole Size • Spray should be atomized (evenly distributed, no • Use small tip hole size when spraying thinner coat- gaps or edges). Start at a low pressure setting, ings. increase pressure a little at a time until paint atom- •...

  • Page 14: Tip Number

    Selecting the Right Tip Tip Number The last three digits of tip number (example 262413) contain information about hole size and fan width when gun is held 30.5 cm (12 in.) from surface being sprayed. Reversible Tip Selection Table Fan Width Tip Part Number Hole Size 305 mm (12 in.) from surface...

  • Page 15: Spraying Techniques

    Spraying Techniques Spraying Techniques Getting Started Hold gun 30 cm (12 in.) from surface and aim straight at surface. Tilting gun to direct spray angle causes an uneven finish. Motor runs only when gun is triggered. Sprayer is designed to stop pumping when gun trigger is released. Pressure Adjustment ti2035a 1.

  • Page 16: Cleanup

    Cleanup Cleanup 4. Turn ON power switch. Align arrow on sprayer and bucket symbol on pressure control knob. 1. Engage gun trigger lock. ti2028a 5. While pump continues to stroke, remove trigger lock. Trigger gun into paint pail. Turn Prime/Spray valve to SPRAY.

  • Page 17: Cleaning Sg3 Gun Filter

    Cleanup Cleaning SG3 Gun Filter 3. Remove filter and clean it in compatible solvent. Perform Pressure Relief Procedure, page 9. ti2055a 1. Engage gun trigger lock. NOTE: Do not soak entire gun in solvent. Prolonged exposure to solvent can ruin packings. 4.

  • Page 18: Filling Sprayer With Storage Fluid

    Cleanup Filling Sprayer with Storage Fluid 4. Turn ON power switch. Always pump storage fluid through pump system after ti2028a1 cleaning. Water left in sprayer will corrode sprayer and 5. Align arrow on sprayer with roller symbol on pres- damage pump. sure control knob.

  • Page 19: Troubleshooting

    Check for broken insulation or wires. Replace damaged electrical cord. Motor or control damaged. Return sprayer to authorized Graco service center. Paint frozen or hardened in pump. Unplug sprayer from electrical outlet. If paint if frozen in sprayer: Do NOT try to start frozen sprayer. Thaw completely or you may damage motor, control board and/or drivetrain.
  • Page 20 Refill paint pail and reprime sprayer. Suction tube has vacuum air leak. Tighten suction tube connection. Inspect for cracks or vacuum leaks. If cracked or damaged, replace. Pump check valves are dirty or Return sprayer to Graco/M authorized service AGNUM damaged.
  • Page 21 Check for broken insulation or wires. Replace damaged soon as sprayer is plugged into electrical cord. outlet and sprayer is turned on. Damaged motor or control. Return sprayer to Graco/M authorized service AGNUM center. Fan pattern varies dramatically Pressure control switch is worn...

  • Page 22: Maintenance

    AGNUM Pump When pump wears, paint will begin to leak down outside of pump. Replace pump at first sign of leaking or addi- tional damage could occur. Pump repair kits are available from Graco/M AGNUM authorized service centers. 3A1177B...

  • Page 23: Technical Data

    Technical Data Technical Data Maximum fluid working pressure - sprayer 207 bar, 21 MPa (3000 psi) Sprayer inlet size 3/4 in. internal thread (standard garden hose USA) Sprayer outlet size 1/4 npsm external thread Electric motor (open frame universal motor) 1/2 hp 4.5 Amp 5/8 hp 4.5 Amp Sprayer weight only...

  • Page 24: Graco Standard Warranty

    Graco distributor to the original purchaser for use. With the exception of any special, extended, or limited warranty published by Graco, Graco will, for a period of twelve months from the date of sale, repair or replace any part of the equipment determined by Graco to be defective.
