- Page 1 THANKS FOR PURCHASING OUR PRODUCT OWER IG210S OWER IG210S Inverter MIG/MAG/MMA Semi-auto ARC Welding Machine Advanced Product Operation Manual (Read the manual carefully before installation ,operation and maintenance)
-
Page 2: Safety Precautions
SAFETY PRECAUTIONS Follow these precautions carefully. Improper use of any welder can result in injury or death. 1. ONLY CONNECT WELDER TO A POWER SOURCE FOR WHICH IT WAS DESIGEND. The specification plate on the welder lists this information. When welding outdoors only use an extension cord intended for such use. - Page 3 Prolegomenon We do very appreciated for your selecting our products. This kind of welding power Model POWERMIG210S is taken foreign advanced technology to develop and manufacture the new generation inverter integrated controlling Semi-auto MIG/MAG ARC and MMA Welding machine. It can be composed the POWERMIG210S MIG/MMA multi function Welding system equipped with wire feeder and welding gun .It has many characteristic such as easy Arc starting .good Arc springiness .adjustable arc thrusting ,low splash,good welding form ,easy welding operation,wide range and electricity save.
- Page 4 1. Main characteristic and suitable range This kind of welding power Model POWERMIG210S is taken foreign advanced technology to develop and manufacture the new generation inverter integrated controlling Semi-auto MIG/MAG Arc welding machine.It makes use of the import key parts such as Siemens IGBT module of Germany,alloy magnetic core and the resume diode module of America.
-
Page 5: Main Technical Data
★ Preset the welding voltage :Preset the welding current to read the welding criterion easy. ★ Adjusting the arc thrusting: Control the splash and steady arc. ★ Strong resistance for the fluctuate of the electricity 2.Main technical Data : ★ Input Voltage 1~220V/230V/240V ;... - Page 6 If the thrusting is high,the arc is strong and high splash. Use the arc thrusting continuously by the control knob on the front panel of POWERMIG210S. 3.3 Recycle function We design the function to settle two problems. 1) Control the diameter of the wire ball at the end of wire . 2) Prevent the wire into the pool after the Arc stopping.
- Page 7 4.1.7 MIG/MMA Process Selector Each icon graphically repre-sents each process for rapid eye acquisition when changing processes. The top function represents MIG. The bottom function represents MMA. 4.1.8 unit of voltage 4.1.9 Amp/Wire Speed Adjustment Knob For Stick function, this adjusts the amps. For MIG opera-tion,the amps are directly tied to the wire speed feed.
- Page 8 Select your wire type according to the basic categories of Fe (Steel), Ss (Stainless Steel) or Al ( Aluminum). This input must be made to properly use the Synergic function to automatically adjust the Volts needed to weld at the selected wire speed. 4.1.18Wire Diameter/ALT selector: Select your wire diameter according of the type wire you are using.
-
Page 9: Side View
flow meter switch for power air breaker back panel. gasinlet 230V power FUSE yellow/green double cable diagram 6 TO INSTALL WIRE: 1. Loosen top idler tensioner, rotating counter-clockwise 2. Flip tensioners down, releasing top drive rolls. 3. Raise top drive rolls. 4. -
Page 10: Synergic And Basic Mig Operation
SYNERGIC AND BASIC MIG OPERATION Synergic vs. Manual Setup and Operation How Synergic MIG operates: The Synergic function of the MIG (200S) component allows the user to only need to use the wire feed speed control to make the unit operate. The welder is programmed to automatically adjust the voltage based off the users input of wire diameter, and filler metal type when the wire speed is increased or decreased by turning the wire speed adjustment knob. - Page 11 6. If used in the manual mode (ALT), select the appropriate wire feed speed and voltage to match wire type, and size. Listen for a steady frying sound while welding to give you a key as to when it is adjusted properly.
- Page 12 7. Operatings ★ "ON" and "OFF" indicating switch on the real panel. ★ Preset the welding voltage ,welding current(wire speed).and Arc force.Diagram 4 ★ Confirm the specification of the wire feed hose ★Confirm the specification of nib base .It affects the extended length of the wire . ★Confirm the specification of nib.
-
Page 13: Maintenance
8. working elements Diagram for the POWERMIG210S working elements.Digram9 working piece rectifier rectifier inverter input filter filter circuit wire feeder welding gun input output IGBT control circuit panel indictor Digram 9 Input AC 220V/230V/240V,rectifier and filter it into 300VDC. Control the IGBT by PWM+PFM,inverter the 300VDC to 40KHZ AC. High frequency transformer pass the power by insulation and voltage reducing with high... - Page 14 Check the abrasion of the nib.Change it in time.(suggest 5~10pieces nibs/40kg wire). 10.Troubles and Remedy Troubles and remedy and remedy are as the form 10 as following Troubles Cause Remedy 1.Fan not works 1.the fan line lose 1.Connect the line properly 2.Fan breakage 2.Change the fan...
- Page 15 11.Transportation,storage and environment conditions ★The package (Wooden cases or cartons)of the manufacturer is suitable for air ,sea ,railway and highway (three class more) transportation.. ★Pay attention to the indication on the package during the transportation. ★ the environment conditions A Temperature range operating 0 ~ 40 ℃...
-
Page 16: Packing List
13.ACCESSORIES:SEE PACKING LIST,PLEASE PACKING LIST ★★★★★★★★★★★★★★★★★★★★★★★★ POWERMIG210S Welding machine adapter connector+cable+Ground pliers adapter connector+cable+holder optional accessory welding torch gas inlet pipe flow meter optional accessory Adjustable foot control optional accessory Operation instructions Certificate of quality ━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━ Certificate of quality ─ ─ ─ ─ ─ ─ ─ ─ ─ ─ ─ ─ ─ ─ ─ ─ ─ ─ ─ ─ ─ ─ ─ Name of product: MIG/MAG / MMA Semi-auto ARC Welding Machine Type of product: POWERMIG210S Packing... - Page 17 Do not touch electrically live parts or Keep flammable materials away. Wear eye, ear and body protection. WARNING electrode with skin or wet clothing. Insulate yourself from work and ground. Spanish No toque las partes o los electrodos Mantenga el material combustible Protéjase los ojos, los oídos y el AVISO DE bajo carga con la piel o ropa moja-...
- Page 18 Keep your head out of fumes. Turn power off before servicing. Do not operate with panel open or Use ventilation or exhaust to guards off. WARNING remove fumes from breathing zone. Spanish Los humos fuera de la zona de res- Desconectar el cable de ali- No operar con panel abierto o AVISO DE...
