Assembly and operating instructions
REMKO Series RVT-ARCTIC
Inverter heat pump
RVT 264 ARCTIC, RVT 354 ARCTIC,
RVT 524 ARCTIC, RVT 684 ARCTIC
Read the instructions prior to performing any task!
0135-2018-09 Edition 2, en_GB

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RVT 264 ARCTIC and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for REMKO RVT 264 ARCTIC

Summary of Contents for REMKO RVT 264 ARCTIC

  • Page 1 Assembly and operating instructions REMKO Series RVT-ARCTIC Inverter heat pump RVT 264 ARCTIC, RVT 354 ARCTIC, RVT 524 ARCTIC, RVT 684 ARCTIC Read the instructions prior to performing any task! 0135-2018-09 Edition 2, en_GB...
  • Page 2 Read these operating instructions carefully before commis- sioning / using this device! These instructions are an integral part of the system and must always be kept near or on the device. REFRIGERANT Subject to modifications; No liability accepted for errors or mis- prints! Installation and operating instructions (translation of the orig- inal)

  • Page 3: Table Of Contents

    2.2 Unit dimensions ..........................12 2.3 Distance-dependent sound level....................13 2.4 Performance curves for heating and cooling ................14 Design and function..........................18 3.1 Characteristics of REMKO inverter air conditioner with split design..........18 3.2 Unit description..........................20 Operation............................. 21 4.1 General notes..........................21 4.2 Display on indoor unit........................
  • Page 4 REMKO Series RVT-ARCTIC 8.3 Connecting the outdoor unit......................42 8.4 Electrical wiring diagram....................... 43 8.5 Electrical drawings........................45 8.6 Connection of a superordinate controller provided by the customer ..........48 Before commissioning........................51 Commissioning........................... 51 Trouble-shooting, fault analysis and customer service..............53 11.1 Störungsbeseitigung und Kundendienst..................

  • Page 5: Safety And Usage Instructions

    Safety and usage instructions DANGER! This combination of symbol and signal word 1.1 General safety notes warns of a situation in which there is immediate danger, which if not avoided may be fatal or Carefully read the operating manual before com- cause serious injury.

  • Page 6: Dangers Of Failure To Observe The Safety Notes

    REMKO Series RVT-ARCTIC 1.4 Dangers of failure to observe Do not operate any further devices that pro- duce high heat or naked flames in the same the safety notes room. Failure to observe the safety notes may pose a risk All housing parts and unit openings, e.g.

  • Page 7: Unauthorised Modification And Changes

    "certificate of warranty" to The setup, connection and operation of the REMKO GmbH & Co. KG at the time when the units and its components must be undertaken units are purchased and commissioned.

  • Page 8: Environmental Protection And Recycling

    REMKO Series RVT-ARCTIC 1.12 Environmental protection and recycling Disposal of packaging All products are packed for transport in environ- mentally friendly materials. Make a valuable contri- bution to reducing waste and sustaining raw mate- rials. Only dispose of packaging at approved collection points.

  • Page 9: Technical Data

    Technical data 2.1 Unit data RVT 264 DC RVT 354 DC RVT 524 DC RVT 684 DC Series Inverter wall-mounted room air conditioner combination for Operating mode cooling and heating 2.40 2.50 4.20 5.60 Nominal heat capacity (0.80-3.90) (0.90-5.10) (1.30-7.00) (2.10-9.40) Energy efficiency ratio SCOP Rated power consumption,...
  • Page 10 REMKO Series RVT-ARCTIC RVT 264 DC RVT 354 DC RVT 524 DC RVT 684 DC Data specific to indoor unit Application area (room volume), approx. Adjustment range room temp. °C +17 to +30 +8 with "FP" function Operating range °C...
  • Page 11 RVT 264 DC RVT 354 DC RVT 524 DC RVT 684 DC Data specific to outdoor unit Power supply V/Ph/Hz 230 / 1~ / 50 Operating range, cooling °C +5 to +50 Operating range, heating °C -20 to +34 Air flow rate, max. 1900 2100 2,700...

  • Page 12: Unit Dimensions

    REMKO Series RVT-ARCTIC 2.2 Unit dimensions Outdoor units Dimensions (mm) RVT 264-354 DC AT RVT 524 DC AT RVT 684 DC AT Indoor units Dimensions (mm) RVT 264 DC IT RVT 354 DC IT RVT 524 DC IT RVT 684 DC IT...

  • Page 13: Distance-Dependent Sound Level

    2.3 Distance-dependent sound level Fig. 1: Distance-dependent sound level for the outdoor unit in relation to installation type, in accordance with the drawing Distance-dependent sound level *) Installation type, in Max. sound power in Unit type accordance with the [dB(A)] [dB(A)] [dB(A)] [dB(A)]...

  • Page 14: Performance Curves For Heating And Cooling

    REMKO Series RVT-ARCTIC 2.4 Performance curves for heating and cooling Heating capacity RVT 264 DC 6,50 6,00 5,50 5,00 4,50 4,00 3,50 3,00 2,50 2,00 1,50 1,00 0,50 0,00 [°C] Fig. 2: Performance curves, heating RVT 264 DC (data for room temperature 20 °C)
  • Page 15 Heating capacity RVT 354 DC 6,50 6,00 5,50 5,00 4,50 4,00 3,50 3,00 2,50 2,00 1,50 1,00 0,50 0,00 [°C] Fig. 4: Performance curves, heating RVT 354 DC (data for room temperature 20 °C) A: Outside temperature 1: COP 2: Heating capacity in kW 3: Power consumption in kW Outside temperature in °C Heating capacity in kW...
  • Page 16 REMKO Series RVT-ARCTIC Heating capacity RVT 524 DC 6,50 6,00 5,50 5,00 4,50 4,00 3,50 3,00 2,50 2,00 1,50 1,00 0,50 0,00 [°C] Fig. 6: Performance curves, heating RVT 524 DC (data for room temperature 20 °C) A: Outside temperature...
  • Page 17 Heating capacity RVT 684 DC 9,50 9,00 8,50 8,00 7,50 7,00 6,50 6,00 5,50 5,00 4,50 4,00 3,50 3,00 2,50 2,00 1,50 1,00 0,50 0,00 [°C] Fig. 8: Performance curves, heating RVT 684 DC (data for room temperature 20 °C) A: Outside temperature 1: COP 2: Heating capacity in kW...

  • Page 18: Design And Function

    Heat regulation in the fact turn itself off when heat is removed. The Remko inverter air conditioner is modulated to the same applies in the opposite direction with actual need. The electronics system has an inte- heating.
  • Page 19 Cooling mode The comfort zone in the illustration below shows which values for temperature and humidity are Because of circuit reversal, heating is also pos- considered comfortable for people. This range sible. In heating mode, the components of the should ideally be met when heating or air-condi- refrigeration circuit are used to produce warm air tioning buildings.

  • Page 20: Unit Description

    REMKO Series RVT-ARCTIC 3.2 Unit description The RVT 264-684 DC room air conditioners have a REMKO RVT...AT outdoor unit as well as an RVT...IT indoor unit. In cooling mode, the outdoor unit serves to output the heat extracted by the indoor unit from the room being cooled.

  • Page 21: Operation

    Operation 4.1 General notes Alarms are indicated by a code (see chapter The indoor unit is easily operated using the Troubleshooting and customer service). standard infrared remote control. The indoor unit beeps to acknowledge the correct transmission of data. If it is not possible to program the indoor unit with the remote control, then it can also be man- ually operated.

  • Page 22: Keys On The Remote Control

    REMKO Series RVT-ARCTIC 4.3 Keys on the remote control "SLEEP" key Activates/deactivates the "SLEEP" function. Pressing this key will automatically increase or decrease the target temperature by 1 °C within an hour in cooling and heating mode respectively. Press this key to maintain the most convenient temperature and save energy.
  • Page 23 “SILENCE/FP” key Indicators on the LCD Activates/deactivates the silent mode. Pressing the key for longer than 2 seconds activates the unit's frost protection function. In silent unit mode, the compressor runs at a lower frequency, and the indoor unit fan rotates at a slower speed.
  • Page 24 REMKO Series RVT-ARCTIC Press the "MODE" key to select from oper- ating modes "Cooling", "Heating" or "Recircu- lation". The illustration of the LCD with all of the sym- Press the "Arrow up/down" key to set the bols present is only intended to provide a desired temperature.
  • Page 25 "Dehumidification" mode "Timer" mode Make sure that the indoor unit is connected to the Press the "TIMER ON" key to set the "switch-on power supply, and is switched on. time" and the "TIMER OFF" key to set the "switch- off" time for the unit. The operating mode indicator on the display of the indoor unit begins to flash.
  • Page 26 REMKO Series RVT-ARCTIC Setting the “switch-off time” Example TIMER function settings Press the "TIMER OFF" key. The remote "TIMER ON" (Auto on mode) control shows "TIMER OFF", the last "switch- Example: off time" setting and the symbol "H" appear on the display. The unit is now ready to reset You want the air conditioning unit to switch on 2 the "switch-off time"...
  • Page 27 Combined TIMER (setting "TIMER ON" and "TIMER ON ð "TIMER OFF" "TIMER OFF" at the same time) (Off ð Start ð Stop) "TIMER OFF ð "TIMER ON" Example: (On ð Stop ð Start) You want the air conditioning unit to switch on in Example: two hours from the time it was programmed, and switch back off five hours later.
  • Page 28 REMKO Series RVT-ARCTIC SLEEP function The sleep function saves energy while you sleep. This function is activated by pressing the key on the remote control. Press the key before going to sleep. In cooling mode, the unit automatically increases the set room temperature by 1 °C after 1 hour.

  • Page 29: Installation Instructions For Qualified Personnel

    Installation instructions for qualified personnel 5.1 Important notes prior to instal- 5.2 Wall openings lation A wall opening of at least 70mm diameter and 10mm incline from the inside to the outside Transport the unit in its original packaging as must be created.

  • Page 30: Installation, Mounting Outdoor Unit

    REMKO Series RVT-ARCTIC 5.5 Installation, mounting During installation, add about 20 cm to the expected snow depth to guarantee unimpeded outdoor unit intake and exhaust of outdoor air year round Outdoor unit installation location (Fig. 30). The installation site of the outdoor unit should...
  • Page 31 Assessment level in accordance with TA noise Point of emissions days in dB(A) nights in dB(A) Industrial areas Commercial areas Core areas, village areas and mixed zones General residential areas and small housing estates Exclusively residential areas Spa areas, hospitals and mental institutions Isolated noise peaks of short duration may not exceed 30 dB(A) during the day and 20 dB(A) at night.

  • Page 32: Minimum Clearances

    REMKO Series RVT-ARCTIC 5.6 Minimum clearances Observe the minimum clearances to allow access for maintenance and repair work and facilitate optimum air distribution. Fig. 31: Minimum clearances of the indoor unit and outdoor unit AT: Outdoor unit IT: Indoor unit...

  • Page 33: Oil Return Measures

    5.7 Oil return measures A: Outdoor unit B: Indoor unit If the outdoor unit is installed at a higher level than 1: One oil pump bend in suction pipe to outdoor the indoor unit, suitable oil return measures must unit every 7 metres of height difference, radius: be taken.

  • Page 34: Connection Of The Indoor Unit When The Refrigerant Piping Is Installed Under The Plaster

    REMKO Series RVT-ARCTIC 5.9 Connection of the indoor unit when the refrigerant piping is installed under the plaster If the customer routes the refrigerant piping to the unit underneath the plaster, observe the following note. The principal connection options can be found in the "Connection variants for the indoor unit" and "Wall bracket"...

  • Page 35: Wall Bracket For The Indoor Units

    5.10 Wall bracket for the indoor units Fig. 35: Wall bracket mounting points RVT 264-684 DC (rear view) Unit type/size (all dimensions in mm) RVT 264 DC IT RVT 354 DC IT RVT 524 DC IT RVT 684 DC IT All dimensions in mm.

  • Page 36: Connecting The Refrigerant Piping

    REMKO Series RVT-ARCTIC The wall bracket for the units must be attached The following instructions describe the installation with suitable screws and anchors. of the cooling cycle and the assembly of the indoor unit and the outdoor unit. 6.2 Connecting the refrigerant The required pipe diameters are given in the table "Technical data".
  • Page 37 Label the refrigerant piping (injection and suc- tion pipes) as well as the associated electrical control lines of each interior unit with a letter. Only connect the lines to their associated con- nections. NOTICE! Always pay attention to the affiliation of the electrical lines and refrigerant piping! The con- nections of the individual circuits must not be mixed up.

  • Page 38: Additional Notes On Connecting The Refrigerant Piping

    REMKO Series RVT-ARCTIC 6.4 Leak testing Once all the connections have been made, the pressure gauge station is attached to the Schrader valve as follows (if fitted): red = small valve = high pressure blue = large valve = suction pressure Once the connection has been made successfully, the leak test is carried out with dry nitrogen.

  • Page 39: Adding Refrigerant

    Condensate drainage 6.5 Adding refrigerant connection and safe The units contain a basic quantity of refrigerant. In addition, an additional amount of refrigerant must drainage be added for refrigerant piping lengths exceeding 5 metres per circuit. Refer to the following chart: Up to and From 5m to incl.
  • Page 40 Safe drainage in the event of leakages For the designations of 1,3,5,8,9 and 11, please refer to the legend for the Fig. 41 The REMKO oil separator OA 2.2 fulfils the fol- lowing list of requirements from regional regula- dimensioning of the strip foundation (in mm) tions and laws.

  • Page 41: Electrical Wiring

    Electrical wiring 8.1 General Information 8.2 Connecting the indoor unit A protected power supply cable is to be connected We recommend installing a main / repair switch to the outdoor unit and a fünfadrige control line to on the building close to the indoor unit. This is the indoor unit respectively.

  • Page 42: Connecting The Outdoor Unit

    REMKO Series RVT-ARCTIC Make the connection as follows: Remove the screws [A] und [B], which are behind of the cover (see Fig. 45). You can now fold up the unit cover [C] (see Fig. 46). Connect the control line provided by the cus- tomer to the terminals [D] (see Fig.

  • Page 43: Electrical Wiring Diagram

    8.4 Electrical wiring diagram Connection RVT 264-684 DC 1(L) 2(N) S 1(L) 2(N) S 230V/1~/50 Hz Fig. 49: Electrical wiring diagram A: Outdoor unit RVT 264-684 DC AT B: Indoor unit RVT 264-684 DC IT 1: Power supply 2: Communication line...
  • Page 44 REMKO Series RVT-ARCTIC Connection of optional condensate pump KP 6 / KP 8 W 1(L) 2(N) W 1(L) 2(N) L N PE Fig. 50: Electrical wiring diagram Outdoor unit Condensate pump supply Indoor unit Condensate pump fault contact Condensate pump KP 6 / KP 8...

  • Page 45: Electrical Drawings

    8.5 Electrical drawings Indoor units RVT 264-684 DC IT CN27 CN13 CN12 CN19 CN22 CN26 WEISS L-OUT CN29 L-IN CN701 BLAU(SCHWARZ) GELB GELB/GRÜN N_IN CN15 CN18 CN32 CN31 CN14 1(L) 2(N) CN40 CN43 CN42 CN41 CN44 Cn45 CN46 HA HB E 12V/5V Fig.
  • Page 46 REMKO Series RVT-ARCTIC Outdoor units RVT 264-354 DC AT Gelb oder Schwarz Blau Braun Schwarz Fig. 52: Electrical drawings RVT 264-354 DC AT A: Control board Condensate tray heating (optional) Compressor Heat gas probe Supply line to the indoor unit...
  • Page 47 Outdoor units RVT 524-684 DC AT CN414 L-OUT Blau CN13 CN12 Blau Schwarz (Blau) Gelb CN6-1 CN10 1(L) 2(N) S L Fig. 53: Electrical drawings RVT 524-684 DC AT A: Control board Fan motor (optional) Supply line to the indoor unit Transformer Power supply Compressor...

  • Page 48: Connection Of A Superordinate Controller Provided By The Customer

    REMKO Series RVT-ARCTIC 8.6 Connection of a superordinate The multifunction board is slid into the mount previ- ously fitted for this purpose. controller provided by the cus- tomer Units of type RVT can be switched on and off by a superordinate controller.
  • Page 49 The multifunction board is equipped with a total of 3 terminals (see Fig. 57), with which the following func- tions can be realised: Fig. 57: Terminals 1: On/Off contact CN 46 / 2: KFB-W contact CN 44 3: Rotary switch addressing / 4: DIP switch F1 5: DIP switch F2 / 6: Alarm contact CN 45 ON/OFF1 terminals (CN 46): Potential-free contact for switching the unit off externally.
  • Page 50 REMKO Series RVT-ARCTIC Electrical wiring for optional KFB-R redundancy controller BUS connection Output 1 Output 2 Output 3 ERR = Contact Input 1 Input 2 Input 3 OK = Contact CN46 CN45 CN46 CN45 Start/Stop Start/Stop Alarm Alarm RVT indoor unit (A)

  • Page 51: Before Commissioning

    Before commissioning Commissioning After leak testing has been successfully com- pleted, connect the vacuum pump via the pressure NOTICE! gauge station to the valve connections on the out- door unit (see chapter "Leak testing") and create a Commissioning should only be performed by vacuum.
  • Page 52 REMKO Series RVT-ARCTIC Function test of the cooling and heating modes Remove the protective caps from the valves. Start the commissioning procedure by briefly opening the shut-off valves on the outdoor unit until the pressure gauge indicates a pressure of approx. 2 bar.

  • Page 53: Trouble-Shooting, Fault Analysis And Customer Service

    Trouble-shooting, fault analysis and customer service 11.1 Störungsbeseitigung und Kundendienst Die Geräte und Komponenten werden mit modernsten Fertigungsmethoden hergestellt und mehrfach auf fehlerfreie Funktion geprüft. Sollten dennoch Funktionsstörungen auftreten, so überprüfen Sie bitte die Funk- tion nach unterstehende Liste. Bei Anlagen mit Innengerät und Außenteil ist auch das Kapitel „Störungsbe- seitigung und Kundendienst“...
  • Page 54 REMKO Series RVT-ARCTIC Störung Mögliche Ursachen Überprüfung Abhilfe Fenster und Türen geöf- Gibt es eine bauliche / Fenster und Türen fnet. Wärme-/ bzw. Kälte- anwendungsmäßige schließen / zusätzliche last wurde erhöht Veränderung? Anlagen montieren Kein Kühlbetrieb einges- Ist das Kühlsymbol in der Einstellung des Gerätes...

  • Page 55: Fehleranalyse Innengerät

    Fehleranzeige am Innengerät Anzeige Fehlerbeschreibung EEPROM Fehler Innengerät Kommunikationsfehler zwischen Innengerät und Außenteil Drehzahlregelung Ventilator Innengerät außer Funktion Raumtemperatursensor T1 defekt Temperatursensor Verdampfer T2 defekt Überstromschutz Temperatursensor Lufteintritt Außenteil T4 defekt Temperatursensor Verflüssigeraustritt T3 defekt Temperatursensor Heißgasleitung T5 defekt EEPROM Fehler Außenteil Drehzahlregelung Verflüssigerventilator außer Funktion Fehler Kompressoransteuerung Über- bzw.
  • Page 56 REMKO Series RVT-ARCTIC Fehlercode: Grund: Das Innengerät empfängt innerhalb 110 Sekunden keine Signale vom Außenteil. Die Über- prüfung erfolgt 4 mal hintereinander, dann erscheint Fehler E1. Ursache: Elektrische Verbindung nicht korrekt ausgeführt Steuerplatine Außenteil oder Innengerät defekt Spannung wegschalten, 2 Minuten später wieder zuschalten.
  • Page 57 Fehlercode: E3 / F5 Grund: Sollte die Ventilatorgeschwindigkeit des Innengerätes/Außenteils unter 300 U/min fallen, schaltet das Gerät ab und das Display zeigt Fehlercode E3 bzw. F5 Ursache: Elektrische Verbindung fehlerhaft Verdampferventilatorrad defekt Verdampferventilatormotor defekt Steuerplatine fehlerhaft Spannung wegschalten, 2 Minuten später wieder zuschalten.
  • Page 58 REMKO Series RVT-ARCTIC Vorgehensweise Gleichstromventilatormotor des Innengeräts (Steuerchip ist im Motor verbaut): Schalten Sie die Spannung des Gerätes ein. Messen Sie im Standby Modus des Gerätes zwischen den Klemmen 1-3 und 4-3 des Verbindungssteckers. Überprüfen Sie die gemessenen Werte mit denen in der unten aufgeführten Tabelle.
  • Page 59 Fehlercode: Grund: Der Verdampfersensor T2 misst beim Kompressorstart den aktuellen Wert und nimmt diesen als Referenzwert T . Sollte 8 Minuten nach Kompressorstart der Wert T nicht Start Start für mindestens 4 Sekunden um 2 °C gefallen sein, geht das System von einem Kältemittel- mangel aus.
  • Page 60 REMKO Series RVT-ARCTIC Fehlercode: E4 / E5 / F1 / F2 / F3 Grund: Ist die Überprüfungsspannung der Sensoren niedriger als 0,06 V oder höher als 4,94 V, zeigt das Display den Fehlercode des entsprechenden Sensors an. Ursache: Elektrische Verbindung fehlerhaft...
  • Page 61 Fehlercode: Grund: Sicherheitsabschaltung aufgrund zu hoher Stromaufnahme einzelner Gerätekomponenten Ursache: Fehlerhafte Netzzuleitung Kältekreislauf blockiert Fehlerhafte Steuerplatine Elektrische Verbindungen fehlerhaft Kompressor defekt Überprüfen Sie die Versorgungsspannung. Ist Schalten Sie das Gerät aus und sorgen Sie für diese korrekt? korrekte Versorgungsspannung. Überprüfen Sie den Kältekreislauf auf even- Entfernen Sie die Blockade (Absperrhähne tuelle Blockaden.
  • Page 62 REMKO Series RVT-ARCTIC Fehlercode: Grund: Ist die Spannungsversorgung zur Kompressorregelung fehlerhaft zeigt das Display den Fehlercode "P0" und das Gerät schaltet sich aus Ursache: Elektrische Verbindung fehlerhaft Fehlerhafte Steuerplatine Verflüssigerventilatormotor defekt oder blockiert Kompressor defekt Überprüfen Sie die Verbindungskabel zwischen...
  • Page 63 Fehlercode: Grund: Über- oder Unterspannungsschutz hat angesprochen Ursache: Fehlerhafte Versorgungsspannung Kältemittelmangel oder Kältekreislauf blockiert Fehlerhafte Steuerplatine Überprüfen Sie die Netzzuleitung. Ist die Ver- Schalten Sie das Gerät aus und lassen Sie die sorgungsspannung korrekt? Netzzuleitung überprüfen/korrigieren. Überprüfen Sie die elektrischen Verbindungen. Erneuern Sie die elektrischen Verbindungen.
  • Page 64 REMKO Series RVT-ARCTIC Fehlercode: P2 (bei Geräten mit Thermokontakt) Grund: Liegt die Überprüfungsspannung des Thermokontaktes nicht bei 5V zeigt das Display Feh- lermeldung "P2" Ursache: Fehlerhafte Versorgungsspannung Kältemittelmangel oder Kältekreislauf blockiert Fehlerhafte Steuerplatine Überprüfen Sie die Luftvolumenströme des Außenteils Reinigen Sie die Filter bzw. die Wärmetauscher und sorgen Sie für ausrei- sowie des Innenger- chenden Luftvolumenstrom.
  • Page 65 Fehlercode: Grund: Sicherheitsabschaltung Inverterregelung. Systeminterne Überwachung angesprochen (z.B. Kommunikationsproblem zwischen Platine und Kompressor, Drehzahl Kompressor nicht in Ordnung) Ursache: Fehlerhafte elektrische Verbindungen Inverterregelung auf Platine defekt Verflüssigerventilatormotor defekt Kompressor defekt Steuerplatine defekt Überprüfen Sie die elektrische Verbindung zwi- schen der Steuerplatine und dem Kompressor. Stellen Sie eine korrekte Verbindung her.
  • Page 66 REMKO Series RVT-ARCTIC Widerstandswerte der Sensoren T1, T2, T3 und T4 K Ohm K Ohm K Ohm K Ohm...
  • Page 67 Widerstandswerte des Sensors T5 K Ohm K Ohm K Ohm K Ohm...

  • Page 68: Care And Maintenance

    REMKO Series RVT-ARCTIC Care and maintenance Maintenance It is recommended that you take out a mainte- Regular care and observation of some basic points nance contract with an annual service from an will ensure trouble-free operation and a long appropriate specialist firm.
  • Page 69 Cleaning the housing Clean the filter with a commercially available vacuum cleaner. To do so, turn the dirty side Disconnect the power supply to the unit. so it is facing upwards. Open and fold the air inlet grill on the front side upwards.

  • Page 70: Shutdown

    Ensure that units and components are disposed of in accordance with local regulations, e.g. through authorised disposal and recycling specialists or at collection points. REMKO GmbH & Co. KG or your contractual partner will be pleased to provide a list of certified firms in your area.

  • Page 71: Exploded View And Spare Parts Lists

    Exploded view and spare parts lists 14.1 Exploded view - Indoor unit RVT 264-684 DC IT Fig. 62: Exploded view of the unit RVT 264-684 DC IT We reserve the right to modify the dimensions and design as part of the ongoing technical development process.

  • Page 72: Spare Parts List - Indoor Unit Rvt 264-684 Dc It

    REMKO Series RVT-ARCTIC 14.2 Spare parts list - Indoor unit RVT 264-684 DC IT IMPORTANT! To ensure the correct delivery of spare parts, please always the device type with the corresponding serial number (see type plate) No. Designation Air outlet flap, horizontal...

  • Page 73: Exploded View - Outdoor Unit Rvt 264-354 Dc At

    14.3 Exploded view - Outdoor unit RVT 264-354 DC AT Fig. 63: Exploded view of the unit RVT 264-354 DC AT We reserve the right to modify the dimensions and design as part of the ongoing technical development process.

  • Page 74: Spare Parts List - Outdoor Unit Rvt 264-354 Dc At

    REMKO Series RVT-ARCTIC 14.4 Spare parts list - Outdoor unit RVT 264-354 DC AT IMPORTANT! To ensure the correct delivery of spare parts, please always the device type with the corresponding serial number (see type plate) No. Designation Condenser protection grille...

  • Page 75: Exploded View - Outdoor Unit Rvt 524 Dc At

    14.5 Exploded view - Outdoor unit RVT 524 DC AT Fig. 64: Exploded view of the unit RVT 524 DC AT We reserve the right to modify the dimensions and design as part of the ongoing technical development process.

  • Page 76: Spare Parts List - Outdoor Unit Rvt 524 Dc At

    REMKO Series RVT-ARCTIC 14.6 Spare parts list - Outdoor unit RVT 524 DC AT IMPORTANT! To ensure the correct delivery of spare parts, please always the device type with the corresponding serial number (see type plate) No. Designation Condenser protection grille...

  • Page 77: Exploded View - Outdoor Unit Rvt 684 Dc At

    14.7 Exploded view - Outdoor unit RVT 684 DC AT Fig. 65: Exploded view of the unit RVT 684 DC AT We reserve the right to modify the dimensions and design as part of the ongoing technical development process.

  • Page 78: Spare Parts List - Outdoor Unit Rvt 684 Dc At

    REMKO Series RVT-ARCTIC 14.8 Spare parts list - Outdoor unit RVT 684 DC AT IMPORTANT! To ensure the correct delivery of spare parts, please always the device type with the corresponding serial number (see type plate) No. Designation Condenser protection grille...

  • Page 79: Index

    Index Ordering spare parts ... . 72, 74, 76, 78 Assembly Strip foundation ..... . 39 Performance charts Cooling .
  • Page 80 SFlb Customer Service Our equipment operates precisely and reliably. However, in the event of a fault, REMKO customer service is quickly at the scene. Our comprehensive network of experienced dealers always guarantees quick and REMKO GmbH & Co. KG reliable service.
