WT sensor PCT007 Quick Start Manual

PCT007 Axial Bimetal Temperature Sensor
Features
Temperature
■
measurement range
Easy installation
■
High temperature
■
measurement accuracy
Long-term stability
■
Long life cycle
■
Applications
Electric power, aerospace
■
industry
Temperature measurement in
■
textile, food and other fields
Atomic energy, petroleum,
■
chemical
Note:
Notes:
1 Do not touch the diaphragm with
hard objects, which may cause
damage to the diaphragm.
2 Please read the Instruction
Manual of the product carefully
before installation and check the
relevant information
product.
3 Strictly follow the wiring method
for wiring, otherwise it may cause
product damage or other potential
faults.
4 Misuse of the product may
cause danger or personal injury.
Product overview
The bimetal temperature sensor integrates bimetal
thermometer and thermal resistance (couple) to meet the
requirements of on-site temperature measurement and
long-distance transmission. It can directly measure
liquid, steam and gas media in the range of -80 ~ 500
degrees Celsius during various production processes
and the temperature on solid surfaces.
Notes:
1 Please read the product instruction manual carefully before
installation and check the relevant information of the product.
2 Wire strictly according to the wiring method, otherwise it will
cause product damage and other potential failures.
3 Incorrect use can cause danger and personal injury.
of the
