Toto EGO II TX467SEL Quick Start Manual

SPECIFICATIONS

120 120
Ø54
Ø54
G½

OPERATING CONDITIONS

1. Water supply pressure : 0.05 ~ 0.75 MPa.
2. Ensure that water supply is clean ( No Sand, Dirt, Etc. )
ATTENTION
1. Don t use abrasive cleaners or solvents on faucets and
fittings.
2. As the product model is constantly updated, the actual
product may not look the same as it shown in the diagram,
but the basic installation principles are the same.

MAINTENANCE

All Finishes : Clean the finish with mild soap and warm water.
Wipe entire surface completely dry with clean soft cloth. Many
cleaners may contain chemicals, such as ammonia, chlorine,
toilet cleaner etc. which could adversely affect the finish and
are not recommended for cleaning
S06308NN
"EGO II" LEVER HANDLE BATH FILLER & MIXER TX467SEL

INSTALLATION

1
Ø 35
Ø 30
240
Ø 35
3
* The red han dle for left po sition
and the blue han dle for righ t
position.
**Tighten the handle ba se by h and
2
Body
Spout
Packing
Packing
Hole Ø30
Packing
Lock Nut
Connector
4
Handle *
Handle
Base**
Lock Nut
Ceramic
Head Work
Hot
Water
Packing
Supply
Lock Nut
Cold
Water
Supply
Body
Flexible Hose

TROUBLESHOOTING

CHECK
PROBLEM
POINT
Flow rate unsatisfactory 1
2
Water leaks around the handle
1. AERATOR
SOLUTION
Remove and clean
Tighten
2. CERAMIC
HEAD WORK
R7
