Sonance Landscape Series RK63 User Manual

I N S T R U C T I O N M A N U A L
S O N A N C E ® L A N D S C A P E S E R I E S
R K 8 3 , R K 6 3

Introduction

Thank you for purchasing Sonance Rock Speakers. When properly
installed, these speakers will provide you with years of outdoor
entertainment pleasure. To get the most out of your new speakers,
please read this manual thoroughly before you begin installation.

Box Contents

Sonance Rock Speaker boxes contain two (2) Rock Speakers.

Connecting the Speakers

1. Determine the locations for the speakers and estimate the
length of additional wire you will need for each speaker.
(Sonance Rock Speakers feature a wide angle of coverage —
only a few speakers are needed to cover a large area with
sound.)
N : W
OTE HEN PURCHASING ADDITIONAL WIRE
STRONGLY RECOMMENDS USING DIRECT BURIAL GRADE WIRE
2. Dig a 4" – 5" deep trench to run the speaker wires in.
3. Run the wire through the trench from your amplifier to the
speaker locations. Do not connect the wires to the amplifier
at this time.
4. Connect the speaker wires you ran from your amplifier to
the wires that came attached to the speakers (see Figure 1).
Sonance recommends
(not included) to secure the wires.
From Speaker
F 1: C
IGURE ONNECTING THE
IMPORTANT: B
E SURE NOT TO LET ANY STRAY
STRANDS TOUCH EACH OTHER
-
A SHORT CIRCUIT THAT COULD DAMAGE YOUR AMPLIFIER
5. After you have made the above connections, connect the
wires to your amplifier.
N : C
OTE ONFIRM THAT YOU HAVE CONNECTED SPEAKER
"+"
AMPLIFIER AND SPEAKER
6
. Turn your amplifier on and test the system with your favorite
music. If the speakers are operating properly, refill the wire
trench and enjoy your new speakers.
R O C K
S P E A K E R S
, S
using waterproof wire
Waterproof
Wire Nuts
Twist
Wires
Together
To Amplifier
R S
OCK PEAKERS
'+'
. T
OUCHING STRANDS CAN CAUSE
"–" "–".
TO AMPLIFIER

Specifications

R K 8 3
Tweeter:
Woofer:
Frequency Response:
Impedance:
Power Handling:
Sensitivity:
Available Finishes:
Dimensions (WxHxD):
Shipping Weight:
ONANCE
.
R K 6 3
Tweeter:
Woofer:
Frequency Response:
nuts Impedance:
Power Handling:
Sensitivity:
Available Finishes:
Dimensions (WxHxD):
Shipping Weight:
'–'
AND
.
"+"
TO
1" (25mm) polyurethane
ferrofluid-cooled
8" (203mm) polypropylene cone with
a Santoprene™ surround
40Hz – 20 kHz ±3dB
8 ohms nominal; 6 ohms minimum
5 watts minimum; 150 watts maximum
90dB SPL (2.83V/1 meter)
Granite; brown
5
14 " x 14¼" x 17¾"
/
8
(372mm x 362mm x 451mm)
35 lbs (15.8kg) pair
1" (25mm) polyurethane
ferrofluid-cooled
6½" (165mm) polypropylene cone
with a Santoprene™ surround
50Hz – 20 kHz ±3dB
8 ohms nominal; 6 ohms minimum
5 watts minimum; 100 watts maximum
89dB SPL (2.83V/1 meter)
Granite; brown
11" x 10½" x 14"
(279mm x 267mm x 356mm)
28 lbs (12.6kg) pair
dome,
dome,
