Monitoring the
Battery-System Charge
Level
Refer to the main information screen in the InfoCenter
to determine the battery-system charge level.
•
Low battery: When the battery level reaches a
low percentage, a low-battery advisory appears
on the InfoCenter.
Finish mowing, then transport the machine to a
designated battery-charging area and charge the
batteries.
•
Limp mode: If the battery level drops below the
set limp-mode battery percentage, an advisory
appears on the InfoCenter, and the mower blades
will disengage and cannot be engaged.
Transport your machine to a designated
battery-charging area and charge the batteries.
•
Ultra-limp mode: If the battery level becomes too
low during limp mode, an advisory appears on
the InfoCenter and traction speed automatically
decreases.
Transport your machine to a designated
battery-charging area and charge the batteries.
Refer to Charging the Lithium-Ion Batteries (page
Adjusting the Battery Percentage
for Limp Mode
Note:
The InfoCenter displays only 2 items at a time;
however, the following figures show the full menus
for context.
1. Park the machine on a level surface, disengage
the PTO, and move the motion-control levers
outward to the P
2. In the M
AIN MENU
press the
3. In the S
ERVICE
and adjust the percentage using the – and +
buttons.
35).

After Operation

After Operation Safety

•
Disengage the PTO whenever you are transporting
or not using the machine.
•
Use full-width ramps for loading the machine into
a trailer or truck.
•
Tie the machine down securely using straps,
chains, cable, or ropes. Both front and rear straps
should be directed down and outward from the
machine.
•
Replace all worn, damaged, or missing parts and
decals. Keep all fasteners tight to ensure that the
machine is working properly.
30
position.
ARK
, scroll down to S
ERVICE
button.
Figure 44
menu, scroll down to L
Figure 45
and
g376300
M
IMP ODE
g377943
