- Page 1 Kitchener / Waterloo / Providence Tall TV Media Stand Model # AXCKIT17-GR...
- Page 2 Great quality is a right. Thank you for shopping with Simpli Home, America's top brand for high-value furniture. It's time to register your product warranty. It's quick and easy. And you'll be happy you did. ü Ac vate your 1-year warranty ü...
- Page 3 Review your product and collect rewards! Thank you for your purchase! We hope you enjoy it. We’d love your feedback. Please share a review and get instant rewards! simpli-home.com/product-review Share photos and get your cash back! Send us images or share them on social and qualify for instant rewards. You may even receive store credit on your en re purchase! simpli-home.com/share-images...
- Page 4 For Fastest Customer Service: Open your phone’s camera. Point your phone’s camera at the QR code to scan. Click on the pop up. You’ll be taken to our customer service page. Fill the form with your order informa on and issue. Submit form.
-
Page 5: Safety Information
IMPORTANT: Please read this manual carefully before beginning assembly of this product. Keep this manual for future reference. Safety Information CAUTION: Injuries and damage can occur from furniture tip over if product is not properly anchored to the wall. Use the Furniture Anti-Tipping Restraint provided with the product. -
Page 6: Care And Maintenance
Care & Maintenance This furniture is designed for indoor use. Perhaps the greatest environmental damage to wood furniture comes from wide swings in relative humidity (RH) in our homes. Wood absorbs and desorbs water as relative humidity rises and falls, and in doing so it swells and shrinks. Making matters worse, it expands and contracts unequally along different grain directions. - Page 7 WARNING The maximum diagonal CRT television screen size is 25 inch to 27 inch (63.50 cm to 68.58 cm). For use with televisions weighing 200 lbs or less. Using larger or heavier televisions may cause instability or tip over which can lead to serious injury or even death. The recommended maximum width of the television intended for use is 60 inch (152.4 cm).
- Page 8 Pre-Assembly Information Model # AXCKIT17-GR Part Description LEFT SIDE RIGHT SIDE QTY 1 QTY 1 QTY 1 BOTTOM SHELF LEFT DIVIDER 1 RIGHT DIVIDER 1 QTY 1 QTY 1 QTY 1 CABINET SHELF DIVIDER 2 CENTRE SHELF QTY 2 QTY 1 QTY 1...
- Page 9 Pre-Assembly Information Model # AXCKIT17-GR Part Description BACK PANEL BACK PANEL LEFT BACK PANEL QTY 1 QTY 1 QTY 1 RIGHT BACK PANEL DOOR (L&R Same) DRAWER FRONT QTY 1 QTY 2 QTY 3 DRAWER BACK LEFT DRAWER SIDE RIGHT DRAWER SIDE QTY 3 QTY 3 QTY 3...
- Page 10 Pre-Assembly Information Model # AXCKIT17-GR Hardware Description WOOD DOWEL ALLEN KEY SCREW CAM LOCK PIN Ø8 X 30 mm M6 X 30 mm CAM LOCK QTY 11 QTY 27 QTY 30 SETS PHILLIPS SCREW ROUND HEAD ALLEN KEY M4 X 15 mm SHELF SUPPORT QTY 1 QTY 34...
- Page 11 Components - Key Diagram Model # AXCKIT17-GR...
- Page 12 Assembly Model # AXCKIT17-GR Step 1 1. Attach four Cam Lock Pins 2 to back of Drawer Front L . 2. Align Cam Lock Pins with guide holes and attach Drawer Sides ML , MR . 3. Insert two Cam Locks 2 into guide holes on each Drawer Side ML , MR . 4.
- Page 13 Assembly Model # AXCKIT17-GR Step 3 1. Align Drawer Back N with Drawer Bottom O and press firmly into slot . 2. Attach Back N using two Allen Key Screws 1 through guide holes on each side ML , MR. 3.
- Page 14 Assembly Model # AXCKIT17-GR Step 5 1. Insert two Wood Dowels 3 into each Divider 1 DL , DR . 2. Use rubber mallet to tap Dowels 3 into bottom of holes securely. 1/2 length of Dowels should be exposed. 3.
- Page 15 Assembly Model # AXCKIT17-GR Step 6 1. Insert three Wood Dowels 3 into Divider 2 E . 2. Use rubber mallet to tap Dowels 3 into bottom of holes securely. 1/2 length of Dowels should be exposed. 3. Align Wood Dowels 3 with guide holes of Centre Shelf F . 4.
- Page 16 Assembly Model # AXCKIT17-GR Step 7 1. Insert two Dowels 3 into top corners of each Side BL , BR . 2. Use rubber mallet to tap Dowels 3 into bottom of holes securely. 1/2 length of Dowels should be exposed. 3.
- Page 17 Assembly Model # AXCKIT17-GR Step 8 1. Attach Bottom Support Leg P to Bottom Shelf C using 4 Phillips Screws 11 . 2. Use Phillips screwdriver to tighten screws. Do not over-tighten. Step 9 1. Attach Back Panels H I JL JR to back of TV Stand using Phillips Screws Round Head 5 into guide holes.
- Page 18 Assembly Model # AXCKIT17-GR Last Step ( after adjust the door ) First Step Step 10 1. Attach hinges on Large Doors K to Sides BL , BR using Phillips Screws 7 into pre-drill holes: - Using Phillips screwdriver to attach Screws 7 at middle hole of hinges for both top & bottom hinges.
- Page 19 Assembly Model # AXCKIT17-GR Step 11 shelf level 1 shelf support anti - tipping shelf level 2 shelf level 3 1. Use four Shelf Supports 6 for each Shelf Cabinet G in desired location. 2. Two Shelf Supports 6 may be used on back top of each shelf cabinet G as a tipping restraint.
- Page 20 Assembly Model # AXCKIT17-GR Step 12 1. Insert assembled drawers into glides on assembled TV Stand.
- Page 21 Furniture Tip Over Restraint Assembly WARNING Serious or fatal crushing injuries can occur from furniture tip-over. If the furniture tip over restraint kit is not in the box, please contact our customer service department in order to obtain another kit before using the furniture. Step 13 NOTE: The screwdriver is not included in the hardware pack.
- Page 22 Furniture Anti-Tipping Restraint Instructions Attach one of the mounting brackets securely to the back edge of the furniture. Use the shorter screw. Determine where furniture is to be placed and mark location on the wall for mounting bracket screw hole approximately 2 inches below the bracket mounted to the furniture.
