Summary of Contents for SIMPLIHOME ACADIAN
- Page 1 SIMP HOME ® L I F E B Y D E S I G N ACADIAN / NORMANDY / BRUNSWICK LADDER SHELF MODEL # AXCACA10-LGB 1/14...
- Page 2 SIMP HOME ® L I F E B Y D E S I G N Questions, problems, assembly help, missing parts? No need to return the product, we will gladly help and ship your replacement parts free of charge Please call Customer Service at 1-866-518-0120 ext. 262 Monday to Friday between 9 am –...
-
Page 3: Safety Information
IMPORTANT : Please read this manual carefully before beginning assembly of this product. Keep this manual for future reference. SAFETY INFORMATION CAUTION: Injuries and damage can occur from furniture tip over if product is not properly anchored to the wall. Use the Furniture Anti-Tipping Restraint provided with the product. -
Page 4: Care And Maintenance
IMPORTANT : Please read this manual carefully before beginning assembly of this product. Keep this manual for future reference. CARE and MAINTENANCE Perhaps the greatest environmental damage to wood furniture comes from wide swings in relative humidity (RH) in our homes. Wood absorbs and desorbs water as relative humidity rises and falls, and in doing so it swells and shrinks. -
Page 5: Pre-Assembly Information
PRE-ASSEMBLY INFORMATION MODEL # AXCACA10-LGB PARTS DESCRIPTION LEFT SIDE RIGHT SIDE QTY 1 QTY 1 BACK BAR SHELF SHELF QTY 6 QTY 1 QTY 1 SHELF SHELF SHELF QTY 1 QTY 1 QTY 1 NEED HELP? For help with assembly or if you are missing a part, Please call customer service at 1-866-518-0120 ext. -
Page 6: Hardware Description
PRE-ASSEMBLY INFORMATION MODEL # AXCACA10-LGB HARDWARE DESCRIPTION CAM LOCK PIN PHILLIPS SCREW WOOD DOWEL CAM LOCK M4 X 30mm Ø8 X 30mm QTY 20 SETS QTY 24 QTY 2 M4 X 25 - QTY 2 1 is extra M4 X 15 - QTY 1 M4 X 25 - QTY 1 PHILLIPS SCREW ROUND HEAD... - Page 7 COMPONENTS – KEY DIAGRAM MODEL # AXCACA10-LGB 7/14...
- Page 8 ASSEMBLY MODEL # AXCACA10-LGB STEP 1 1. Insert one Dowel 3 into pre-drilled hole on Shelf C . 2. Use rubber mallet to tap Dowel 3 into bottom of holes securely. 1/2 length of Dowels should be exposed. 3. Attach Cam Lock Pins 1 to Left Side AL using guide holes. 4.
- Page 9 ASSEMBLY MODEL # AXCACA10-LGB STEP 2 1. To attach Right Side AR to Shelfs C D E F G , repeat step 1. 9/14...
- Page 10 ASSEMBLY MODEL # AXCACA10-LGB STEP 3 NOTE: The screwdriver is not included in the hardware pack. 1. Attach Brackets 4 to bottom corner of Shelfs C E G and Sides AL , AR using Phillips Screw Round Heads 5 . 2.
- Page 11 ASSEMBLY MODEL # AXCACA10-LGB STEP 4 NOTE: The screwdriver is not included in the hardware pack. 1. Attach Back Bars B to back of Sides AL , AR using Phillips Screws 2 into pre-drilled holes. 2. Use phillips screwdriver to tighten Screws. 11/14...
- Page 12 FURNITURE TIP OVER RESTRAINT ASSEMBLY WARNING Serious or fatal crushing injuries can occur from furniture tip-over. If the furniture tip over restraint kit is not in the box, please contact our customer service department in order to obtain another kit before using the furniture. STEP 5 NOTE: The screwdriver is not included in the hardware pack.
- Page 13 FURNITURE TIP OVER RESTRAINT ASSEMBLY Furniture Tip Over Restraint Instructions: Attach one of the mounting brackets securely to the back edge of the furniture. Use the shorter screw. Determine where furniture is to be placed and mark location on the wall for mounting bracket screw hole approximately 2 inches below the bracket mounted to the furniture.
-
Page 14: Warranty
SIMP HOME ® L I F E B Y D E S I G N WARRANTY Thank you for purchasing a Simpli Home – Wyndenhall – Brooklyn + Max product. These products have been made to demanding, high-quality standards and are guaranteed for domestic use against manufacturing faults for a period of 12 months from the date of purchase.
