- Page 1 MEMO S-Seek ..MENU DISP BAND P-Tune SC-FM1 Universal FM Modulated SIRIUS Satellite Radio Tuner Installation Guide...
-
Page 2: Package Contents
Package Contents SC-FM1 Tuner DC Power Harness RCA Type Audio Cables L/R Mounting Screws for Tuner (6) FM Relay Switch Ultra Low Profile Mobile Antenna Rubber Antenna Cable Cover/Tail & Adhesive Strip Alcohol Swab SC-FM1 Installation Guide... - Page 3 Extension Cable for Display Control Unit Velcro ® Strips (2) ® SIRIUS and the SIRIUS Dog Logo are registered trademarks of SIRIUS Satellite Radio, Inc. ® Velcro is a registered trademark of Velcro Industries B.V. SC-FM1 Installation Guide MEMO Display Control Unit S-Seek ...
-
Page 4: Important Pre-Installation Notes
When replacing blown fuses, replace the fuses with fuses of the same type, rating, and amperage. • Do not cut any of the wires and cables provided with the SC-FM1 system. Excess cable or wire length should be neatly coiled and secured in a hidden location. - Page 5 When the Tuner is mounted, the cables and wires connected to the Tuner should be free of kinks and crimps, and securely connected to the Tuner. Extra cable or wire lengths should be coiled and secured with wire ties or electrical tape to the existing wiring harnesses in the vehicle. SC-FM1 Installation Guide...
- Page 6 Specifications section in this manual for the power requirements of the SC-FM1 system.) Do not replace the fuse of the electrical circuit with a larger fuse in order to accommodate the SC-FM1 system. Doing so could result in a circuit overload, which could cause an electrical fire.
- Page 7 SC-FM1 System Wiring Diagram ANTENNA FROM VEHICLE AM/FM ANTENNA FM RELAY SWITCH SC-FM1 Installation Guide TUNER OPTIONAL TO VEHICLE SPEAKERS L/R TO VEHICLE AM/FM RADIO TO VEHICLE BATTERY +12V (YELLOW) TO SWITCHED IGNITION +12V (RED) TO GROUND -12V (BLACK) DISPLAY...
- Page 8 It is important to avoid any obstructions that will block the SIRIUS signal, obstructions such as a roof rack, a sunroof, roof mounted cargo containers, or other antennas. For convertible vehicles, the antenna should be installed on the trunk lid.
- Page 9 Route the antenna cable through the wire channel in the rubber antenna cable cover/tail. SC-FM1 Installation Guide Pickup Truck: Mount the antenna along the rear centerline of the cab roof, located at the rear of the roof near the rear window.
- Page 10 (68 degrees), maximum adhesion usually occurs within 72 hours. During this period, avoid car washes and other contact with the antenna and rubber antenna cable cover/tail. ANTENNA CABLE ADHESIVE STRIP RUBBER ANTENNA CABLE COVER/TAIL ANTENNA (UNDERSIDE) SC-FM1 Installation Guide...
- Page 11 The Display Control Unit may be mounted using the included Velcro strips to adhere the unit to the vehicle’s interior surface, or mounted using a mobile phone type mounting system by using the included mobile phone mounting clip which attaches to the Display Control Unit. SC-FM1 Installation Guide...
-
Page 12: Specifications
Audio Interface ... 2 RCA Type Connectors (R/L) Remote Control Dimensions (Width x Length x Height) ... 41mm x 104mm x 15mm Remote Control Battery Requirements ... CR2025 (4.49” x 1.58” x .73”) (4.98” x 4.95” x 1.37”) (1.61” x 4.09” x .59”) SC-FM1 Installation Guide... - Page 13 Please record the SIRIUS ID in the space provided below: SIRIUS ID: SIRIUS Customer Service: 1-888-539-7474 SIRIUS Product Support: 1-800-869-5590 customercare@sirius-radio.com SC-FM1 Installation Guide...
- Page 14 Notes: SC-FM1 Installation Guide...
- Page 15 Notes: SC-FM1 Installation Guide...
- Page 16 SIRIUS Satellite Radio Inc. 1221 Avenue of the Americas New York, NY 10020 1-888-539-7474 www.sirius.com SC-FM1 (Rev. 1, December 2004) © 2004 SIRIUS Satellite Radio Inc.
