BMW R 18 B 2021 Rider's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
BMW
MOTORRAD
RIDER'S MANUAL
(US MODEL)
R 18 B
MAKE LIFE A RIDE

Advertisement

Table of Contents
loading

Related Manuals for BMW R 18 B 2021

Summary of Contents for BMW R 18 B 2021

  • Page 1 MOTORRAD RIDER'S MANUAL (US MODEL) R 18 B MAKE LIFE A RIDE...
  • Page 2 Vehicle data Model Vehicle identification number Color number First registration License plate Retailer data Contact in Service Ms./Mr. Phone number Retailer's address/Phone (company stamp)
  • Page 3 If you should decide to sell your BMW one day, please remember to hand over these operat- ing instructions as well. They are an important part of your vehicle.

  • Page 4: Table Of Contents

    GENERAL INSTRUCTIONS TFT DISPLAY Quick & easy reference General notes Abbreviations and symbols Principle Equipment Pure Ride view Technical data Split screen Timeliness of the status of this General settings manual Bluetooth Additional sources of information WiFi Certificates and operating permits My Vehicle Data memory Onboard computer...
  • Page 5 Speakers (vehicle-specific) Clutch Tires Rims SERVICE Wheels Light sources Reporting safety defects Jump-starting BMW Motorrad Service Battery BMW Motorrad Service History Fuses BMW Motorrad Mobility Ser- Diagnostic socket vices Maintenance work Maintenance schedule ACCESSORIES Maintenance confirmations Service confirmations General notes...
  • Page 6 Certificate for Keyless Ride Certificate for tire pressure con- trol IP notice: DAB tuner INDEX...
  • Page 8 GENERAL INSTRUCTIONS...
  • Page 9 QUICK & EASY REFERENCE ABBREVIATIONS AND SYMBOLS EQUIPMENT TECHNICAL DATA TIMELINESS OF THE STATUS OF THIS MANUAL ADDITIONAL SOURCES OF INFORMATION CERTIFICATES AND OPERATING PERMITS DATA MEMORY...

  • Page 10: Equipment

    Non-compli- EQUIPMENT ance can cause damage to the vehicle or accessories and warranty claims may be de- When you ordered your BMW Motorrad mo- nied as a result. torcycle, you chose various items of custom equipment. These operating instructions...

  • Page 11: Timeliness Of The Status Of This

    MANUAL Control units also make comfort and info- tainment functions possible. The high safety and quality level of BMW Information about the stored or exchanged motorcycles are ensured by consistent, data can be obtained from the vehicle man-...
  • Page 12 Operating conditions of system compo- The vehicle owner can have a nents, such as fill levels and tire pressure BMW Motorrad retailer or other qualified Malfunctions and faults in key system service partner or specialist workshop read components, such as lights and brakes...
  • Page 13 The fault memory and event data recorder in This includes for instance position data and the vehicle can be reset by a BMW Motorrad other general vehicle information, depend- retailer or other qualified service partner or...
  • Page 14 GENERAL INSTRUCTIONS secure connection, i.e. with the vehicle man- ufacturer's IT systems which are intended for this purpose. Any collection, processing and use of per- sonal data that goes beyond the provision of services take place only as permitted by law, on the basis of a contractual agreement or as a result of consent.

  • Page 16: Overviews

    OVERVIEWS...
  • Page 17 OVERALL VIEW, LEFT SIDE OVERALL VIEW, RIGHT OVERALL COCKPIT VIEW MULTIFUNCTION SWITCH, LEFT MULTIFUNCTION SWITCH, RIGHT INSTRUMENT CLUSTER...

  • Page 18: Overall View, Left Side

    OVERVIEWS OVERALL VIEW, LEFT SIDE Onboard power socket ( 142) Onboard toolkit (in case) ( 120) Diagnostic socket (behind the side trim panel) ( 138) Reverser ( Nameplate Tire pressure table...

  • Page 19: Overall View, Right

    OVERALL VIEW, RIGHT Brake fluid reservoir for front wheel brake ( 125) Vehicle identification number Engine oil indicator ( 121) Ground support point ( 132) Oil filler opening (under the cylinder head cover) ( 122) Brake fluid reservoir for rear wheel brake ( 126) Jump-start terminal (...

  • Page 20: Overall Cockpit View

    OVERVIEWS OVERALL COCKPIT VIEW USB charging interface (in the storage compartment) ( Fuel filler opening ( 104) Onboard power socket ( 142) Payload table (on the inside of the storage compartment flap)

  • Page 21: Multifunction Switch, Left

    MULTIFUNCTION SWITCH, LEFT High beams and headlight flasher Cruise control ( Hazard warning system ( Riding mode ( Turn signals ( Horn Multi-Controller ( Rocker button MENU ( Distance control (ACC) (...

  • Page 22: Multifunction Switch, Right

    OVERVIEWS MULTIFUNCTION SWITCH, RIGHT Central locking system ( Ignition ( Emergency-off switch ( Starter button ( with reverser Reverser (...

  • Page 23: Instrument Cluster

    INSTRUMENT CLUSTER Fuel gauge Speedometer Rotational-speed sensor Power reserve display ( TFT display (...

  • Page 24: Displays

    DISPLAYS...
  • Page 25 INDICATOR AND WARNING LIGHTS TFT DISPLAY IN PURE RIDE VIEW TFT DISPLAY IN MENU VIEW POWER RESERVE DISPLAY INDICATOR LIGHTS...

  • Page 26: Indicator And Warning Lights

    DISPLAYS INDICATOR AND WARNING LIGHTS Turn signal, left ( High beams ( General warning light ( Turn signal, right ( ASC ( ABS ( Indicator light DWA ( Keyless Ride ( Photodiode (for adjusting brightness of instrument lighting)

  • Page 27: Tft Display In Pure Ride View

    TFT DISPLAY IN PURE RIDE VIEW Speed Limit Info ( Hill Start Control ( Speedometer Cruise control ( Distance control (ACC) ( Rider info. status line ( Riding mode ( Upshift recommendation ( Gear indicator, "N" is displayed while in neutral position. Split screen ( Clock ( Connection status (...

  • Page 28: Tft Display In Menu View

    DISPLAYS TFT DISPLAY IN MENU VIEW Hill Start Control ( Speedometer Cruise control ( Distance control (ACC) ( Rider info. status line ( Riding mode ( Gear indicator, "N" is displayed while in neutral position. Split screen ( Clock ( Connection status ( Operating instructions ( Central locking system (...

  • Page 29: Power Reserve Display

    POWER RESERVE DISPLAY Check Control display The messages in the display are shown dif- The power reserve display indicates the per- ferently in the display. Different colors and centage of the total drivetrain power that is characters are used depending on the prior- additionally available.
  • Page 30 DISPLAYS Color of the icon Green: ( ) current value is optimal. Blue: ( ) current temperature is low. Cold! Yellow: ( ) current value is too Low! High! low or too high. Red: ( ) current temperature Hot! High! or value is too high.
  • Page 31 Overview of warning indicators Indicator and warning Display text Meaning lights is displayed. Outside temperature warning ( lights up yellow. Radio-operated key out- Remote key not in range. side reception range lights up yellow. Keyless Ride failure Keyless Ride failure! lights up yellow.
  • Page 32 DISPLAYS Indicator and warning Display text Meaning lights Drive malfunction Engine! lights up yellow. Engine in emergency- Fault in the engine con- operation mode ( trol. flashes red. Serious fault in the en- Serious fault in the en- gine control ( gine control.
  • Page 33 Indicator and warning Display text Meaning lights lights up. ABS failure ( flashes rapidly. ASC intervention ( flashes slowly. ASC self-diagnosis not completed ( lights up. ASC switched off Off! Traction control deac- tivated. lights up yellow. Limited ASC availability Traction control lim- ited.
  • Page 34 DISPLAYS Indicator and warning Display text Meaning lights Audio system tempera- Audio system Level 3 too ture too high ( Audio system voltage too Audio system voltage is high ( high! Fuel down to reserve Low fuel. volume ( Hazard warning lights flashes in green.
  • Page 35 Limit value for outside temperature ing; the engine will not turn off. Have any faulty radio-operated keys re- placed by a BMW Motorrad retailer. Approx. 37 °F (Approx. 3 °C) The first time the temperature drops below Keyless Ride failure this value, the outside temperature display lights up yellow.
  • Page 36 Have the malfunction corrected as soon as possible at a specialist workshop, prefer- Vehicle voltage critical! ably an authorized BMW Motorrad retailer. Consumers were switched off Check battery condition. Light source defect lights up yellow.
  • Page 37 Adaptive Lights Have the malfunction corrected as soon as The faulty light source is displayed: possible at a specialist workshop, prefer- ably an authorized BMW Motorrad retailer. Active headlamp faulty. Anti-theft alarm battery low charge with anti-theft alarm system (DWA) Anti-theft alarm batt.
  • Page 38 Engine overheating! Come to connected. a safe stop, then stop the en- Contact a specialist workshop, preferably gine. an authorized BMW Motorrad retailer. DWA failure ATTENTION Anti-theft alarm system fail- Riding with overheated engine ure. Have checked by a spe- Engine damage cialist workshop.
  • Page 39 Have the malfunction corrected as soon as shop. possible at a specialist workshop, prefer- ably an authorized BMW Motorrad retailer. Continued driving is possible, however it is WARNING not recommended. Unusual handling when the engine is in...
  • Page 40 Tire Press. Monitor. Loss of eral warning light will blink in red. pressure. Stop immediately! Check tire pressure. For further information about the BMW Motorrad tire pressure control (TPC), WARNING see the Technology in detail ( 116) chapter. Tire pressure is outside the approved tolerance range.
  • Page 41 RDC is only ensured for a limited time. Contact a specialist workshop, preferably " " an authorized BMW Motorrad retailer. Sensor faulty or system fault Possible cause: with tire pressure monitor (TPM) The vehicle has not reached the minimum speed ( 116).
  • Page 42 ( 111). Have the malfunction corrected as soon as possible at a specialist workshop, prefer- Side stand monitoring faulty ably an authorized BMW Motorrad retailer. Onward journey possible. Stop engine when stationary! Have ABS failure checked by workshop. lights up yellow.
  • Page 43 Have the malfunction corrected as soon as Contact a specialist workshop, preferably possible at a specialist workshop, prefer- an authorized BMW Motorrad retailer. ably an authorized BMW Motorrad retailer. ASC switched off ASC error lights up. lights up yellow.
  • Page 44 Brake temperature too high roads. Have the malfunction corrected as soon as lights up yellow. possible at a specialist workshop, prefer- ably an authorized BMW Motorrad retailer. Brake temperature high! Hill Start Control active To cool down, continue riding carefully. Avoid dynamic with Hill Start Control riding.
  • Page 45 Onward journey possible. a specialist workshop, preferably an autho- Testing by workshop required rized BMW Motorrad retailer. Possible cause: Audio system temperature too high The control unit has detected an error. It must be noted that cruise control and Audio system Level 3 too hot distance control (ACC) are not available.
  • Page 46 BMW Motorrad retailer. instrument cluster. This situation can occur if the battery was disconnected. Fuel down to reserve volume Service due Low fuel.

  • Page 48: Operation

    OPERATION...
  • Page 49 IGNITION LIGHTING ANTI-THEFT ALARM SYSTEM (DWA) TIRE PRESSURE CONTROL (TPC) AUTOMATIC STABILITY CONTROL (ASC) RIDING MODE CRUISE CONTROL DISTANCE CONTROL (ACC) HILL START CONTROL REVERSER HEATING STORAGE COMPARTMENT CENTRAL LOCKING SYSTEM CASE SEAT...

  • Page 50: Ignition

    OPERATION Ignition, lights and all electrical circuits IGNITION switched off. Radio-operated key Unlocking the steering lock The indicator light for the radio-oper- Requirement ated key flashes as long as the radio- The steering lock is locked. The radio-oper- operated key is being searched for. ated key is within the reception area.
  • Page 51 The battery of the radio-operated key is Version 2: dead or the radio-operated key is lost Steering lock is engaged, press and hold button 1. Steering lock is unlocked. Parking lights and all function circuits are switched on. Pre-Ride-Check is carried out. ( 100) ABS self-diagnosis is performed.
  • Page 52 Always store ignition keys separately from the ignition key used for starting the vehicle. If you lose an ignition key, you can have it Press button 1. disabled by your authorized BMW Motorrad Key bit folds open. retailer. Press battery cover 2 upward.

  • Page 53: Lighting

    tion keys are part of an integrated safety system, so the retailer is under obligation to check the legitimacy of all applications for spare keys. Emergency-off switch Engine is switched off Operating position The engine can only be started in the operating position.
  • Page 54 OPERATION High-beam headlight and headlight flasher Switching on the ignition ( 44). Immediately after switching off the igni- tion, push button 1 to left and hold it until the parking lights come on. Press switch 1 forward to switch on high Switch ignition on and then off again to beams.

  • Page 55: Anti-Theft Alarm System (Dwa)

    Turn signals ANTI-THEFT ALARM SYSTEM (DWA) Switching on the ignition ( 44). with anti-theft alarm system (DWA) Activation Switching on the ignition ( 44). Adapting DWA ( 51). Switching off the ignition ( 45). If the DWA is activated, the DWA is au- tomatically activated after the ignition is switched off.
  • Page 56 The duration of the alarm signal is approx. 26 seconds. During the alarm, an alarm tone sounds, and the turn signals blink. The type of alarm tone can be set by an authorized BMW Motorrad retailer.

  • Page 57: Tire Pressure Control (Tpc)

    : Confirmation alarm tone af- Arming tone ter activating/deactivating the DWA in addi- tion to flashing turn indicators. : Automatic activation Arm automatically of the alarm function when the ignition is turned off. TIRE PRESSURE CONTROL (TPC) with tire pressure monitor (TPM) Switching setpoint pressure warning on or When the minimum tire pressure is Press button 1 of the radio-operated key...

  • Page 58: Riding Mode

    The guide 4 shows how many riding modes RIDING MODE are available. Use of the riding modes BMW Motorrad has developed riding sce- narios for your vehicle from which you can select the one matching your situation: RAIN: Riding on roads that are slick from rain.
  • Page 59 Slide switch 1 to the right. Briefly push button 1 forward. Button 2 is unlocked. The speed is increased by 1 mph (1.6 km/h) each time the button is Storing speed pressed. Press button 1 forward and hold. The speed is increased in increments of 5 mph (8 km/h).

  • Page 60: Distance Control (Acc)

    OPERATION Deactivating the cruise control Switching off cruise control Actuate the brakes or throttle grip (ease the throttle beyond the default setting) to deactivate the adaptive cruise control. If the clutch remains pulled for more than 1.5 seconds, cruise control is de- activated.
  • Page 61 Safety instructions WARNING WARNING ACC is not functional in certain situa- tions ACC does not release riders from their Risk of accident if there is no control own responsibility takeover request and deceleration Risk of accident due to misjudgment by The field of view of the radar must be the system clear for object detection.
  • Page 62 OPERATION WARNING ATTENTION ACC cannot compensate for excess ACC can misidentify certain objects and speed differences traffic situations Risk of accident Risk of injury due to unexpected brake ACC cannot perform emergency brak- intervention ing. The deceleration and buildup of de- Certain objects and complex traffic sit- celeration are limited.
  • Page 63 As an alternative, press and hold the but- To switch on, briefly press the button 1. ACC is switched on. ton 1. A switchover between cruise control and The set distance is briefly shown in the ACC takes place. display. Note automatic deactivation ( 54).

  • Page 64: Hill Start Control

    OPERATION blinks red. has been turned off. In case of a restart, the following setting is preselected: Medium distance If a warning light appears in the TFT display: Take action to avoid potential danger. HILL START CONTROL Setting distance with Hill Start Control Activating and deactivating theHill Start Control Switching on the ignition (...

  • Page 65: Reverser

    You can find more detailed informa- General information tion regarding Hill Start Control in the The following prerequisites must be fulfilled "Technology in detail" chapter. to use the reverser: Motorcycle is standing. Engine is running. Brake is actuated. Transmission is in idle position. Side stand is retracted.

  • Page 66: Heating

    OPERATION Using reverser Turn the selector level 1 to the position. Gear indicator 2 switches from " " to " ". HEATING Operating heated grips The heated grips option can only be activated when the engine is running. The increase in power consumption caused by the heated grips can drain the battery if you are riding at low engine speeds.

  • Page 67: Storage Compartment

    The selected heating level 1 and the heated The selected heating level 1 and the heated grip icon 2 are shown in the display. grip icon 2 are shown in the display. Operating the seat heating STORAGE COMPARTMENT with seat heating Using the storage compartment Seat heating can be activated only when the engine is running.
  • Page 68 (162 mm x 78 mm x 8.8 mm). For small mobile phones that might not be held securely by the holder, BMW Motorrad recommends the use of a BMW Motorrad smartphone case. Fold bracket 1 upwards. The bracket stays folded up.

  • Page 69: Central Locking System

    Emergency unlocking CENTRAL LOCKING SYSTEM If the central locking system refuses to un- with central locking system lock, the cases can be opened manually: Opening case ( 63). Locking Requirement CASE The radio-operated key is within the recep- tion area. Opening case with central locking system Open the central locking system if...

  • Page 70: Seat

    OPERATION Closing case SEAT Removing the seat Pull release lever 2 all the way up. Close case lid and press down. Make sure Park the vehicle, making sure that the that no objects are jammed. ground is firm and level. The case can also be locked if the lock Remove screw 3 with tool from onboard is in the LOCK position.
  • Page 71 Disconnect the plug connection 2 and re- Thread the grab strap 2 into the seat 1. Insert the seat 1 into the mount 5. move the seat 1. Position the seat 1 in the rear area and Installing the seat install the holder 4 using the screw 3.
  • Page 72 TFT DISPLAY...
  • Page 73 GENERAL NOTES PRINCIPLE PURE RIDE VIEW SPLIT SCREEN GENERAL SETTINGS BLUETOOTH WIFI MY VEHICLE ONBOARD COMPUTER NAVIGATION MEDIA PHONE DISPLAYING SOFTWARE VERSION DISPLAYING LICENSE INFORMATION...

  • Page 74: General Notes

    TFT DISPLAY BMW Motorrad Connected App GENERAL NOTES With the BMW Motorrad Connected App, Warnings you can call up information about the vehicle and usage. To use some features such as navigation, the app must be installed on the WARNING...
  • Page 75 Functions of the Multi-Controller MENU long press up: Turning Multi-Controller upwards: In the Menu view: Open Pure Ride view. Move the mouse pointer up in lists. MENU short press down: Make settings. Change a hierarchy level down. Increase volume. No function when lowest hierarchy level is reached.
  • Page 76 TFT DISPLAY Operating instructions 5: The right end Switching functions on and off has been reached. Operating instructions in submenus In addition to the operating instructions in the main menu, there are additional operat- ing instructions in submenus. Some items are preceded by a box. The box indicates whether the function is turned on or off.
  • Page 77 Changing the display for rider info. status Settings Briefly press the Multi-Controller 1 to the line right repeatedly until the desired menu Show Pure Ride view ( 70). item is highlighted. All of the information necessary for oper- Briefly press button 2 downward. ating the vehicle on public roads is made available from the on-board computer (e.g.

  • Page 78: Pure Ride View

    Riding time 2 Switching Speed Limit Info on or off Break 1 Requirement The vehicle is connected to a compatible mobile end device. The BMW Motorrad Break 2 Connected app is installed on the mobile end device. (average) Speed 1...

  • Page 79: Split Screen

    Upshift recommendation The selected display remains even after the ignition is turned off. Turning off split screen The upshift recommendation in the Pure Ride 1 view or in the status line 2 indicates the best time for an upshift from Show Pure Ride view ( 70).

  • Page 80: Bluetooth

    TFT DISPLAY Setting the clock If the display of the TFT display is faulty, the troubleshooting chart in the Techni- Switching on the ignition ( 44). cal Data chapter may provide assistance. Go to menu Settings System set- 153) tings Date and time Set time Hour...
  • Page 81 The connection is established and the con- On some mobile devices, e.g. with op- nection status is updated. erating system iOS, the BMW Motorrad If the connection cannot be established, Connected App must be called up before us- the troubleshooting chart in the Techni- ing.

  • Page 82: Wifi

    TFT DISPLAY the Technical data chapter may provide assistance. ( 153) Deleting connections Call up menu Settings Connections Select Delete connections To delete an individual connection, select the connection and confirm. To delete all connections, select Delete and confirm. all connections WIFI WiFi connection A WiFi connection is used to transmit the...

  • Page 83: My Vehicle

    MY VEHICLE Start screen Check Control display Layout ( Range ( Odometer Service display ( Rear tire pressure ( Voltage of the vehicle electrical sys- tem ( 133) Front tire pressure (...
  • Page 84 TFT DISPLAY Operating instructions Check-Control messages are dynami- cally added to the menu screens in the menu as additional tabs. My vehicle On-board computer and travel on-board computer ONBOARD COMPUTER TRIP COM- menu windows show the vehicle and PUTER journey data, e.g. average values. Service requirements Operating instructions 1: Tabs that show how far to the left or right you can scroll.

  • Page 85: Onboard Computer

    Calling up the onboard computer ( 79). Scroll to the right until the TRIP COM- The BMW Motorrad Connected App is in- menu panel is displayed. PUTER stalled on the mobile end device. As an alternative, the travel on-board com- puter can also be displayed on the split On some mobile devices, e.g.

  • Page 86: Media

    Route cri- Entering destination address teria The following criteria can be selected: Connecting a mobile end device ( 75). Go to the BMW Motorrad Connected app Route type and start the route guidance. Avoid Select desired Go to the menu.

  • Page 87: Phone

    Making a phone call Go to the menu. Media BMW Motorrad recommends setting the volume for media and conversa- tions via mobile end devices to the maxi- mum before starting a journey. Go to the menu.

  • Page 88: Displaying Software Version

    TFT DISPLAY DISPLAYING SOFTWARE VERSION Call up menu Settings Information Software version DISPLAYING LICENSE INFORMATION Call up menu Settings Information Licenses...
