lynx System Developers IdentiLynx SR Quick Start Manual page 4

Step 7: IdentiLynx Image Toolbar
a. Open a new Blank Event in
b. Get a start for the system and have someone run
across the finish line as you capture (All Cameras).
c. Click the icons on the Image Toolbar to zoom in
and out of the image.
d. The Full Screen icon
image.
e. The Cropping tools and
applicable to the IdentiLynx image.
f. In the IdentiLynx image, right-click, hold, and drag to
draw a small box. Choose
when the mouse is released. Click the
icon to bring the image back to its original state.
g. Click on the Play icon and see the images change
(you should see the time advance to the left of the play
icon). Click it again to stop playback
Step 8: Time Tracking With IdentiLynx
NOTE: The Red hash line does not appear on the IdentiLynx image unless you click on the image frame. Time
cannot be read from the IdentiLynx image.
a. Using the same Blank Event, explore the time
tracking between the FinishLynx and IdentiLynx
cameras.
b. Click on a competitor in the FinishLynx image and the
IdentiLynx image will jump to that frame (time
reference) in the sequence.
Step 9: Camera Care and Tips
The new IdentiLynx cameras are a different design from the older models. The Ethernet port in the back of the
supports XLR to RJ-45 connectors for weatherproof connection. Failure to use this connector may lead to water
infiltration which could damage the camera.
To learn how to install the connector on your Ethernet cable, go to:
the Assembly Instructions.
NOTE: When adding the IdentiLynx SR/HRS
for congestion. Add one camera at a time and increase the Resolution, or Frame Rate, in increments. We recommend
the use of a Gigabit Network Switch. Use the same methodology when adding a second IdentiLynx camera to your
FinishLynx network. From a results-production standpoint, it is rarely necessary to go over 10fps in Cross Country or
Road Races.
Download a copy:
IdentiLynx SR/HRS Quick Start Guide
FinishLynx.
will show the full screen
Find Next Object are not
Enhance from the menu
Restore Image
camera to your network, be sure to monitor Ethernet traffic and watch
IdentiLynx SR/HRS
h. Click the Forward or
frame at a time in either direction (you should see the
time advance with each frame).
i. Hitting the Reverse button at full-speed forward
playback goes to ½ speed playback. Hitting it again
goes to ½ speed reverse playback, and again goes to
full-speed reverse. It works the same going forward in
playback.
j. Clicking the Play button in slow or fast mode brings it
to full-speed, and clicking the
playback.
k. The Play speeds aren't displayed in the image
toolbar. If you hold
you'll go to the first or last frame. If you
Backwards,
hold Shift and click Play, the image playback will loop
back to the beginning when the end is reached.
l. Images can be printed from the
cropped and saved as a .jpg, similar to FinishLynx
images.
c. Click the Play button for the IdentiLynx images and
then click in the FinishLynx image. The IdentiLynx
image will jump to that location and continue to play
from that point forward.
www.neutrik.com/en/product/ne8mx-b
Contact Technical Support:
Email: support@finishlynx.com
Phone: 978-556-9780
Join Us Online:
Timer's Group: facebook.com/groups/finishlynx
Facebook: facebook.com/finishlynx
Instagram: @finishlynx
Quick Start Guide
Reverse icons to move one
Stop button will stop
Ctrl and click Forward or
Image Toolbar
and find
Page 4 of 4
or
