Step 5: Auto-Iris & Remote Zoom and Auto-Focus Control
Our latest IdentiLynx camera is the first equipped with
auto-iris as well as remote-control lens which offers
complete control over the zoom and focus settings from
within the FinishLynx software. It's as simple as clicking
the icons in the remote-control panel of the Hardware
Control window.
a. Auto-Iris: always on and managed automatically by
the camera (cannot be manually adjusted). To change
exposure, adjust the brightness value or lower the
shutter speed.
b. Zoom Steps: 4 step sizes are available. Use the
mouse to click the Zoom
Step 6: Camera Settings
NOTE: Only the Setup, Parameters
settings are grayed out as they do not apply to the IdentiLynx functions.
a. Click the Camera settings
b. Click the Setup tab and name the camera based on
location or function.
c. Click the Parameters
Rate/Height and shutter speed to your preference.
IdentiLynx SR & HRS Quick Start Guide
icons for the smallest
and Capture tabs will apply to settings for the IdentiLynx camera. The other
icon.
tab and set the Frame
IdentiLynx SR/HRS
change. Try to Shift-click, Ctrl-click or Ctrl-Shift-click
(full range in two steps) for increasingly bigger steps.
c. Auto Focus: Ctrl-Shift-click the Focus Near or
Focus Far icon to activate the camera's Automatic
focus function. The focus icons will change when in
auto focus.
Normal Focus Mode
d. Manual Focus Steps:
Use a simple click, Shift-click or Ctrl-click on the
Focus Near or Focus Far icons to manually change
the focus in increasingly bigger steps.
•
Click the Capture tab and make sure you select
the preferred capture method.
d. In File | Options | Image, make sure that
Tracking is set to All Cameras.
Quick Start Guide
Auto Focus Mode
3 step sizes are available.
