lynx System Developers IdentiLynx SR Quick Start Manual

IdentiLynx SR & HRS Full-Frame Video Cameras
Verify that your IdentiLynx Full-Frame video system contains the components pictured below.
If not, or if you need additional help, please call: USA 978 556 9780 or email support@finishlynx.com.
Item Description
IdentiLynx Camera
and Tripod
Protective Case
10' (3 meter)
Ethernet Cable
Weatherproof
XLR-RJ45
connector
Items not included
•
Computer (laptop recommended) running Microsoft Windows. Your computer needs: one available serial port, or USB
port, and one available Ethernet port.
•
(Recommended) PoE+ Gigabit Hub/Switch
•
(Recommended) UPS Battery Backup
Introduction
In this quick start guide, you will learn how to set up and configure the IdentiLynx camera with your FinishLynx timing system
and play back full-frame video captured at the finish line.
NOTE: Lynx recommends a
IdentiLynx camera to your timing system.
IdentiLynx SR/HRS Quick Start Guide
Quick Start Guide
ID
IdentiLynx SR/HRS
CP102
C10BT-10
N/A
PoE+ Gigabit hub/switch and a
Lynx System Developers, Inc.
Item
Gigabit network card as a minimum when adding the
Description ID
Power Injector
for Power- IDL-PoE
over-Ethernet
Power-over-
Ethernet Included with
Power Supply IDL-PoE
Connector
100' (33 meter)
Ethernet Cable
C10BT-100
with XLR-RJ45
connector
