Step 1: Install the Latest FinishLynx Software
NOTE: IdentiLynx requires
FinishLynx.
a. Open FinishLynx on your computer. Go to
About and write down your FinishLynx Serial
Number if you do not already have it stored
somewhere. Also, record the serial numbers for any
FinishLynx software plug-ins.
Step 2: Set Up the IdentiLynx Camera
a. Place the camera on the tripod, about chest high and
in a safe location. Aim it at the finish line facing in the
direction of the oncoming runners.
b. Plug the Power-over-Ethernet power supply into the
power source or UPS battery backup.
c. Connect the first Ethernet cable (10') from the
FinishLynx PC or Hub/Switch to the
IdentiLynx power supply.
d. Connect the Ethernet cable (100') to the
the IdentiLynx power supply.
e. Do not connect the other end of the second Ethernet
cable to the RJ45 port on the back of the IdentiLynx
camera until FinishLynx is ready to boot the cameras.
NOTE: The IdentiLynx camera gets Power-over-
Ethernet (POE).
Step 3: Boot Cameras
a. Open FinishLynx.
b. Power on the FinishLynx cameras first, before the
IdentiLynx camera.
c. Check that each FinishLynx camera has appeared in
the Hardware Control window in FinishLynx.
d. Once they have appeared, connect the Ethernet cable
from the OUT port on the power injector to the
XLR/RJ45 port on the back of the IdentiLynx camera.
Step 4: Align the IdentiLynx Camera
The IdentiLynx is a full-frame video camera, so the image
during alignment mode will show a normal 2-D video in
the Image Zone.
a. Have someone stand on the finish line to determine
the focus point.
b. Select the IdentiLynx camera in the Hardware Control
window and click the
IdentiLynx camera into Alignment mode.
IdentiLynx SR/HRS Quick Start Guide
the latest version
Help
In port of the
Out port on
Red Stop Sign to put the
of b. If accessible, insert the supplied Lynx flash drive into
your computer's USB port and install FinishLynx.
| OR: Download the latest FinishLynx software online:
www.finishlynx.com/product/software/finishlynx-
results-software/
c. Enter the serial number.
NOTE: Booting the IdentiLynx camera at the end of the
order will eliminate
communication if you turn off or lose connection with the
IdentiLynx camera at some point and require re-booting
of the FinishLynx cameras.
c. Once your line of sight is
correct, use the
Zoom and Auto Focus
function in the FinishLynx
screen to adjust the camera
until you have
image.
IdentiLynx SR/HRS
Quick Start Guide
any interruption in
Remote
desired
