Sima SVS-4D Specifications

Audio/Video Switcher Audio/Video Switcher
Audio/Video Switcher Audio/Video Switcher
with Auto Input Sensing, Volume Stabilization and Digital Audio
SVS- - - - 4D SVS 4D
SVS SVS 4D 4D

1. Auto Input Sensing

2. Video Signal Conversion

4 Key Features

Auto Input Sensing really simplifies usage of your A/V system. The auto input sensing feature detects the current
unit in use and automatically connects to that input, without you having to push any buttons! For example, turn on your
VCR and the SVS-4D selects the VCR input and feeds it to your TV. Now, turn on your DVD unit and it will
automatically select the DVD input. Of course, you can select any input using the I/R Remote or the front panel buttons.
Volume Stabilization allows you to increase or decrease the dynamic range of the audio output. You can increase
the dynamic range (loud becomes louder, soft becomes softer) when you want to get the full impact from an audio track.
You can also decrease the dynamic range (loud becomes softer and soft becomes louder) to achieve a more balanced
sound. You set it and the SVS-4D does the rest.
Digital Audio Conversion can take the digital coaxial output from a DVD player and the digital optical output
from a CD player and feed either a single optical or coaxial signal to your receiver.
Video Signal Conversion converts standard video signals (RCA style jacks) to S-Video signals. This is useful
when your TV is receiving a combination of standard video signals and S-Video signals and you don't want to keep re-
setting it. Leave your TV set to S-Video and select any source. The SVS-4D will automatically feed the appropriate
signal.
Key Features

A/V inputs

A/V outputs

Auto Input Sensing: On / off
Volume compression and
expansion

Accessories included

Size

An exceptional A/V switcher with uncommonly good sense! The
Model SVS-4D Audio/Video Switcher from Sima Products
provides the necessary A/V inputs for adding components to your
TV and home theater system. The Model SVS-4D has four
Audio/Video inputs including S-Video and dual outputs to feed your
TV and either a receiver or VCR for recording. Four key features
makes the SVS-4D outstanding:
3. Volume Stabilization (compression/expansion)
4. Digital audio with optical/coaxial conversion
Audio: stereo (4), 200 mv, 50K, 20 to 20K +/- 3 db
Video: Composite (4) and S-Video(4): 75 ohm, 1 v
Digital Audio: Coaxial (2), Optical (2)
Audio: stereo (2), 200 mv, 100 ohms
Video: Composite (2) and S-Video (2): 75 ohm, 1v
Digital Audio: Coaxial (1), Optical (1)
On or off
User adjustable from 10: 1 to 1:2
Bypass: On or Off
IR remote control with batteries, A/V RCA cable (3'),
AC wall adapter, Instruction Manual
13" x 8" x 2.25"
Model SVS-4D
