- Page 1 Operating Instructions OPT/i TWIN SyncBox EN-US Operating instructions 42,0426,0286,EA 004-02022023...
-
Page 3: Table Of Contents
Table of contents General Safety Scope of Supply Environmental Conditions Technical Data Notes on the function of the OPT/i TWIN SyncBox Indications on OPT/i TWIN SyncBox Indications on OPT/i TWIN SyncBox Application example Application Example Installation Installation... -
Page 4: General
WARNING! Danger due to unplanned signal transmission. This can result in serious personal injury and damage to property. ▶ Under no circumstances may safety-related signals be transmitted via the OPT/i TWIN SyncBox. Scope of Supply Environmental CAUTION! Conditions A risk is posed by prohibited environmental conditions. -
Page 5: Technical Data
Firmware update: The OPT/i TWIN SyncBox uses its own firmware (not identical with the firmware of the power source). Always update the OPT/i TWIN SyncBox firmware separ-... -
Page 6: Indications On Opt/I Twin Syncbox
Indications on OPT/i TWIN SyncBox Indications on LED Heartbeat OPT/i TWIN Staus Meaning SyncBox Offline; no supply voltage Flashing green The PC board operating system is working properly LED Synchronisation Staus Bedeutung Lights up green power sources are synchronized Lights up red... -
Page 7: Application Example
Application example Application Ex- ample... -
Page 8: Installation
Set Process Parameters/Components & Monitoring/Components/Cool- ing Unit Operating Mode to ON Switch off power sources Connect power sources of OPT/i Twin SyncBox and wirefeeder as shown in the application example TWIN welding characteristics are now activated and the welding process...
