- Page 1 Operating Instructions Selectiva Li 8 kW 2200 / 4185 8110 Selectiva Li 16 kW 8210 Selectiva Li 18 kW 2320 / 4325 Operating Instructions 42,0426,0310,EN 010-18052022...
-
Page 3: Table Of Contents
Contents Safety rules General Intended use Environmental conditions Mains connection Dangers from mains current and charging current Dangers posed by the battery General information regarding the handling of lithium batteries Protecting yourself and others Safety measures in normal operation EMC Device Classifications EMC measures Data protection Maintenance... - Page 4 Technical data Selectiva 8 kW Li-Ion Selectiva 16 kW Li-Ion Selectiva 18 kW Li-Ion...
-
Page 5: Safety Rules
Safety rules General The device has been manufactured in line with the state of the art and according to recognized safety standards. If used incorrectly or misused, however, it can cause: Serious or fatal injury to the operator or third parties Damage to the device and other material assets belonging to the operating company Inefficient operation of the device... -
Page 6: Mains Connection
Mains connec- Devices with a higher rating may affect the energy quality of the mains due to tion their current consumption. This may affect a number device types in terms of: Connection restrictions Criteria with regard to the maximum permissible mains impedance Criteria with regard to the minimum short-circuit power requirement at the interface with the public grid see "Technical data"... -
Page 7: General Information Regarding The Handling Of Lithium Batteries
To comply with European Directive 2006/66/EC on batteries and its implementa- tion in national law, batteries that have reached the end of their life must be col- lected separately and returned to an approved recycling facility. Be sure to re- turn any used battery to your dealer, or find out about the approved collection and recycling facilities in your area. -
Page 8: Protecting Yourself And Others
Protecting your- While the charger is in operation, keep all persons, especially children, out of the self and others working area. If, however, there are people in the vicinity, warn them about all the dangers (hazardous electrolytes and gases, danger from mains and charging current, etc.), provide suitable protective equipment. -
Page 9: Maintenance
Maintenance Before switching on, always check the mains plug and cable as well as charger leads and charging terminals for any signs of damage. If the surface of the device housing is dirty, clean with a soft cloth and solvent- free cleaning agent only. -
Page 10: Disposal
Disposal Waste electrical and electronic equipment must be collected separately and re- cycled in an environmentally-friendly way, in accordance with the European Dir- ective and national legislation. Used equipment must be returned to the distrib- utor or disposed of via an approved local collection and disposal facility. Correct disposal of used equipment promotes the sustainable recycling of material re- sources. -
Page 11: General Information
General information Explanation of DANGER! safety notices Indicates immediate danger. ▶ If not avoided, death or serious injury will result. WARNING! Indicates a potentially hazardous situation. ▶ If not avoided, death or serious injury may result. CAUTION! Indicates a situation where damage or injury could occur. ▶... -
Page 12: Mains Connection
WARNING! Danger due to trailing charging leads. This could result in injury due to getting caught or tripping on loose cables. ▶ Lay the charging leads so that no one can trip over or become entangled in them. WARNING! Danger due to charging plug being pulled out during charging. This may result in serious injury and damage to property. -
Page 13: Correct Installation Of The Mains/Charging Cables
Correct installa- CAUTION! tion of the mains/charging Danger due to overheating caused by laying the mains/charging cables incor- cables rectly. Risk of damage to the components. ▶ Lay mains/charging cable without loops. ▶ Do not cover mains/charging cable. ▶ Charging cables longer than 5 m (16 ft. 4.85 in.) Lay cables individually (no bundling). -
Page 14: Warning Notices On The Device
¡Utilizar exclusivamente baterías de iones de litio homologadas! Interrompere sempre la carica prima di scollegare il cavo di carica! Utilizzare solo con la batteria agli ioni di litio approvata! 42,0409,0420 Selectiva xxxx Li xxkW Fronius International GmbH Part No.: 4,010,xxx,876 Froniusstraße 1 A-4643 Pettenbach Ser.No.:... -
Page 15: Warning Notices Inside The Device
Warning notices WARNING! inside the device Danger from electric current. This can result in serious injury or death. ▶ The housing must never be opened by anyone other than a trained service technician. ▶ The device must be disconnected from the mains before starting any work with the housing open. -
Page 16: Setup Regulations
Setup regula- WARNING! tions Danger from machines falling or toppling over. This may result in serious injury and damage to property. ▶ Make sure that all system components are securely in position when setting them up. ▶ If using a floor bracket or wall bracket, always make sure that all the fasten- ings are secure. -
Page 17: Wall Bracket
Danger due to objects falling or toppling over. This may result in serious injury and damage to property. ▶ Ensure that all screw connections are secure. ▶ Only use with a Fronius Selectiva 8/-18 kW charger. ▶ Ensure the device is level when mounting. - Page 18 8 kW mm (in.) 193 (7.6) 633 (24.92) 180 (7.09) (.51) 595,5 (23.44) 179 (7.05)
- Page 19 16 kW mm (in.) 267 (10.51) 647 (25.47) 247 (9.72) (.79) 241 (9.49) 585 (23.03) 8 kW / 16 kW mm (in.) 500 (19.69) 492 (19.37) 450 (17.72) 400 (15.75) 300 (11.81) 200 (7.87) (.33) 20 (.79) 7 (.28) (.24) (.79) 342 (13.46) (.24)
- Page 20 18 kW mm (in.) 267 (10.51) 247 (9.72 785 (30.91) (.79) 500 (19.69) 570 (22.44) 241 (9.49) 646 (25.43) 723 (28.46) Weight of wall bracket: 8 kW 1.80 kg (3.97 lb) 16 kW 3.15 kg (6.49 lb) 18 kW 4.30 kg (9.48 lb)
-
Page 21: Control Elements And Connections
Control elements and connections Controls and connections Function (11) (+) Charging lead (-) Charging lead Free position Position for the remote control system or 12 V charging lights options (10) Function USB port The USB port allows a USB flash drive to be used to update the device and also to log the charging parameters while charging is in progress. - Page 22 (10) Control panel (11) Optional LED strip Lights up in different colours depending on the state of charge, as ex- plained in the "Control panel" section * The CAN connection area can only be accessed by removing the connection plate on the front of the device. The following warning notices must be obeyed: WARNING! Danger from electric current.
-
Page 23: Control Panel
Detect - white CAN High - green CAN Low - yellow CAN GND - brown Control panel Function Display Displays the current charging parameters Displays settings "Menu" key Selects the desired menu Selects the appropriate symbol to return to the previous display... - Page 24 "Up/Down" keys Selects the desired menu item Sets the desired value "Stop/Start" key For interrupting and resuming the charging process Confirms a menu item or setting "State of charge"/"Battery cooled down" indicator (blue) Depending on the setting, it signals the following battery conditions, ac- cording to the "Display"...
-
Page 25: Charging The Battery
The display appears in standard mode. The display shows the charger paramet- ers: Type of battery (Li-Ion) Charging characteristic, e.g. Fronius Li-Ion Charger voltage range, alternates with the maximum output current, or only the battery nominal voltage if a battery is connected... - Page 26 chapter. Ensure that the battery to be charged matches the configuration of the battery charging system. Plug in the charging plug The charger detects that the battery is connected and starts charging. If start-up delay is activated, then charging will start at the end of the set delay time. For more information, see "Configuration mode"...
-
Page 27: Interrupting Charging
The green "Battery charged" in- dicator is on The battery is always ready to The battery can remain connec- ted to the charger for as long as required Interrupting To interrupt the charging process: charging Press the "Stop/Start" key While the charging progress is interrupted: The "Charge"... -
Page 28: Stopping Charging
Stopping char- WARNING! ging Danger when disconnecting the charging cables. This can result in severe personal injury and damage to property due to sparking. ▶ Before disconnecting the charging plug, first stop the charging process by pressing the "Stop / Start" key. As soon as the battery is fully charged, the following indicator lights up: "Battery charged"... -
Page 29: Display
Display Overview of dis- The device has the following display modes: play modes Function Standard mode In standard mode the display shows the charging parameters. Statistics mode Visualises the frequency of the device operating modes and shows the total number of charging actions. Also shows an overview of the total and average Ah produced and energy consumed per charge. -
Page 30: Menu Selection
In standard mode, the display shows the following charger parameters: Type of battery (Li-Ion) Charging characteristic, Fronius Li-Ion (CAN) Charger voltage range, alternates with the maximum output current, or only the battery nominal voltage if a battery is connected Connection status:... -
Page 31: History Mode
Use the "Up/Down" keys to toggle between page 1/2 and page 2/2 Page 2/2 shows the following values: Total number of charges Total Ah output Average Ah output per charge Total energy consumed (kWh) Average energy consumed (kWh) per charge The consumed energy display is a standard value and can deviate by up to 5% from the actual amount of energy. -
Page 32: Configuration Mode
Symbols shown Exclamation mark with number: Warning has been output with the corresponding status code. More information can be found in the "Status codes" section. Symbol with number: Error has been output with the corresponding status code. More information can be found in the "Status codes" section. Key symbol with a tick: Charging was stopped properly using the "Stop/Start"... - Page 33 The "Up/Down" keys can be used to retrieve the following information: Serial number of the charger plus serial number and version of the configuration memory PC board for controller/power electronics: hardware version and serial number Software: main software, secondary software, primary software and characteristic block version The procedure for opening the configuration menu is as follows: Press the "Stop/Start"...
-
Page 34: Charging Settings
You will now be prompted to select one of the main menu items for the configur- ation mode: When you select a menu item you may be presented with a symbol prompting you to read the Operating Instructions. Confirm this prompt by pressing the "Stop/Start"... - Page 35 Select the "Charging settings" menu item A list appears with the following selection options: "Delay" "Charge start delay" Delay time (minutes) between the activation time of the charge start and the actual charge start. “Charge end delay” Delay time (minutes) between the signaled end of charge (e.g. green indicat- or) and the actual end of charge.
- Page 36 To activate the calendar function, select and confirm the "ON" set- ting The following settings are possible within the calendar function: "Day setting 1-7": The day settings allow up to 7 differ- ent charging phase time profiles to be defined. "Charge": Time window within which charging should start...
- Page 37 Please note! The efficiency of the device can be negatively influenced by a set power limit. "Week setting": It is possible to configure 3 differ- ent week settings. Each day of the week can be assigned one of the previously created day set- tings.
-
Page 38: Additional Functions
Additional func- The following section provides a detailed explanation of the "Additional func- tions tions" menu item in configuration mode. Navigation is carried out as described in the "Configuration mode" section. Select the "Additional functions" menu item A list appears with the following selection options: "Blue LED": Setting for the "Blue LED"... - Page 39 Normal Start ON: Charging starts when an external switch is closed and a battery is detected or when the charging plug is connected by closing the auxiliary contacts and a battery is detected. Start OFF: Charging starts when a battery is connected. Stop ON: Charging is interrupted when an external switch is opened or when the charging plug is disconnected by opening the auxiliary contacts.
- Page 40 The "CAN" menu item allows you to set the CAN protocol used. This depends on the respective application. In the "Status" area, a check mark symbol appears as soon as the CAN connec- tion has been successfully established. Otherwise an "x" is displayed. Call up the protocol version number: Press the "Stop/Start"...
-
Page 41: General Settings
General settings Detailed explanation of the "general options" menu item in configuration mode. Select the "general options" menu item. A list appears with the following selection options: Language Display settings Contrast LED brightness Show Ah at charge end ON/OFF Time and Date daylight saving time / normal time Predefined time zones... - Page 42 The minimum and maximum values differ depending on the different device classes. The minimum value is approx. 25% of the maximum nominal current of the charger. Temperature: Temperature in °C / °F Code: Code entry required / not required to access configuration mode ("Code ON / OFF") USB Logging Time: Time interval (s) for recording...
-
Page 43: Reset Settings
The I-SPoT VIEWER software supports the visualisation and evaluation of data on the USB flash drive. The I-SPoT VIEWER software can be found online at the following address: http://www.fronius.com/i-spot. Only insert the USB flash drive when charging is not in progress or if the charging process has been interrupted. - Page 44 The logged data is saved in the same way as for the "Download" function, but is saved not in the I-SPoT VIEWER format, but as ".csv" files (Automatically created folder structure for the .csv files: * Fronius\<device serial number>\Charges\<yyyymmdd>\<hhmmss.csv> Save events Events are saved to the USB flash drive.
-
Page 45: Status Codes
Status codes If a fault occurs during operation, specific status codes may be displayed. Faults can result from the following: Battery fault The voltage of the connected battery is unsuitable. The device has overheated. There is a software or hardware fault. Battery fault: If the battery signals a fault, the battery charger displays this fault as a battery fault including the corresponding fault number for the battery. - Page 46 (26) Cell fault detected (27) Battery not supported (28) Battery heavily discharged - safety charging is being carried out (29) Battery is connected with reverse polarity (30) Thermal runaway Status codes in the event of a CAN fault (battery) Cause / Remedy (51) Battery not responding (52)
- Page 47 Status codes in the event of a fault in the primary circuit Cause / Remedy (500) Module 1 (top) temperature sensor faulty (501) Module 2 (bottom) temperature sensor faulty (502) PCB temperature sensor faulty (503) Primary overtemperature (504) Fan blocked/faulty (505) Intermediate circuit over/undervoltage (506) Intermediate circuit imbalance (507) Primary supply voltage outside the tolerance...
- Page 48 (537) Voltage measurement faulty (570) Secondary relay cannot be switched (571) ADC/SPI error Status codes in the event of a fault in the controller Cause / Remedy (540) Configuration memory chip missing/faulty (541) No secondary communication (542) Secondary initialisation failed (543) Program/memory fault in characteristic control (544) Program/memory fault in characteristic control (545) Primary initialisation failed...
-
Page 49: Options
Options Safety In order to connect optional components, it may be necessary to open the hous- ing. The following warning notices must be obeyed: WARNING! Danger from electric shocks. This can result in serious injury or death. ▶ The housing must never be opened by anyone other than a service technician trained by the manufacturer. -
Page 50: Charging Lights
Charging lights RCS 3.0 Lights GREEN YELLOW BLUE Ext. Start/Stop ( - ) Ext. Start/Stop WARNING Hazardous Voltage Kondensator Entladezeit < 2 min. Capacitor discharge time < 2 min. Décharge de condensateur < 2 min. Condensador tiempo de descarga < 2 min. Condensatore tempo di scaricamento <... -
Page 51: Floor Bracket
Floor bracket The robust floor bracket ensures safe fitting on site. More information can be found in the corresponding Installation Instructions. LED strip The LED strip acts as a status indicator and lights up in the same colours as the display elements on the control panel. - Page 52 Technical data Selectiva 8 kW WARNING! Li-Ion An electric shock due to a fault current can be fatal. Nothing other than a type B residual current circuit breaker should ever be used for connecting the device to the mains. 3~ NPE 400 V / 50/60 Hz Mains voltage (-10% / +10%) 3~ PE 400 V / 50/60 Hz Optional:...
- Page 53 Device-specific data Device Max. AC cur- Max. AC Nominal Max. char- rent power voltage ging current Selectiva 2200 11.4 A 6640 W 24 V 200 A Selectiva 15.7 A 9940 W 48 V 185 A 4185 Selectiva 8110 15 A 9680 W 80 V 110 A...
- Page 54 Selectiva 16 kW WARNING! Li-Ion An electric shock due to a fault current can be fatal. Nothing other than a type B residual current circuit breaker should ever be used for connecting the device to the mains. 3~ NPE 400 V / 50/60 Hz Mains voltage (-10% / +10%) 3~ PE 400 V / 50/60 Hz Optional:...
- Page 55 Selectiva 18 kW WARNING! Li-Ion An electric shock due to a fault current can be fatal. Nothing other than a type B residual current circuit breaker should ever be used for connecting the device to the mains. 3~ NPE 400 V / 50/60 Hz Mains voltage (-10% / +10%) 3~ PE 400 V / 50/60 Hz Optional:...
- Page 56 Device-specific data Device Max. AC Max. AC Nominal Max. char- current power voltage ging cur- rent Selectiva 15.1 A 9820 W 24 V 320 A None 2320 Selectiva 31 A 19,530 W 48 V 325 A 4325 mOhm...
