- Page 1 Handling Grapple (GHG) Models GHG 75 - GHG 125 SAFETY & OPERATOR’S MANUAL...
-
Page 2: Contact Information
Central America & Colombia Cra 13A #89-38 / Ofi 613 Bogota, Colombia Phone: +57 1 610 8160 / 795 8747 E-mail: contact@themsagroup.com View and download all manuals: genesisattachments.com/manuals Patents: genesisattachments.com/products/patents Genesis GHG 75-125 Handling Grapple © 2023 Genesis Attachments, LLC... -
Page 3: Preface
To ensure years of safe, dependable service, only trained and authorized persons should operate and service your Genesis attachment. It is the responsibility of the product’s owner to ensure the operator is trained in the safe operation of the product and has available this manual for review. -
Page 4: Table Of Contents
MAINTENANCE SAFETY Pinch Points & Crush Points Performing Maintenance MAINTENANCE SCHEDULE Four-Hour Checklist Eight-Hour Checklist Long-term Maintenance LUBRICATION POINTS BOLT TORQUE SPECS GENERAL WELDING GUIDELINES Welding Ground Clamp Welding Rules Genesis GHG 75-125 Handling Grapple © 2023 Genesis Attachments, LLC... - Page 5 Parts Orders Should Include Placing Orders Part Numbers Shipping Invoices Returns Return Goods Authorization PARTS ORDER FORM CONTACT INFORMATION NOTICE For bolt torque specs, see the Genesis Fastener Manual. genesisattachments.com/manuals © 2023 Genesis Attachments, LLC Genesis GHG 75-125 Handling Grapple...
-
Page 6: Safety Statements
This statement is used where minor or moderate injury could result if the instructions are not followed properly. NOTICE This statement is used where property damage could result if the instructions are not followed properly. Genesis GHG 75-125 Handling Grapple © 2023 Genesis Attachments, LLC... -
Page 7: Operational Safety
3 Be properly seated in the operator’s seat. 3 Do not attempt to operate until you have read and fully understand this manual and the OEM manual for the carrier. © 2023 Genesis Attachments, LLC Genesis GHG 75-125 Handling Grapple... -
Page 8: Check The Equipment
Stability Your Genesis attachment is sized for carrier stability. However, improper operation, faulty maintenance or unauthorized modifications may cause instability. 3 Know the working ranges and capacities of the carrier to avoid tipping. -
Page 9: Know The Work Area
3 Slowly operate all functions to check for proper operation and to bleed air from the hydraulic system. To shut down: 3 Return your Genesis attachment to a rest position on the ground. 3 Shut off the carrier engine. 3 Work controls in all directions to relieve hydraulic pressure, per excavator manufacturer’s instructions. -
Page 10: Safely Operate Equipment
3 A heavy load can cause equipment instability. Use extreme care during travel. Slow down on turns and watch out for bumps. The equipment may need additional counter-weights to counterbalance the weight of the attachment. Genesis GHG 75-125 Handling Grapple © 2023 Genesis Attachments, LLC... -
Page 11: Transporting The Attachment
Current in high voltage lines may arc some distance from the wire to a nearby ground. Keep all parts of the machine at least 50 feet (16m) away from power lines. © 2023 Genesis Attachments, LLC Genesis GHG 75-125 Handling Grapple 11... -
Page 12: Use Care With Hydraulic Fluid Pressure
Allow hydraulic components to cool before working on them. Use appropriate protective clothing and safety equipment. If burned, seek immediate medical attention. Genesis GHG 75-125 Handling Grapple © 2023 Genesis Attachments, LLC... -
Page 13: Prioritized Oil Flow
It is recommended to use dust suppression (such as water) or dust collection (such as a vacuum) along with personal protective equipment if necessary during the operation of any attachment that may cause high levels of silica dust. © 2023 Genesis Attachments, LLC Genesis GHG 75-125 Handling Grapple 13... -
Page 14: Process Material Safely
Failure to do so may cause serious injury or death. • Use your Genesis attachment only as directed in this manual. Do not use the attachment to lift and move other objects. Doing so may cause instability and tipping. -
Page 15: Attachment Markings
ATTACHMENT MARKINGS Product Model Serial Number (Weld On) Logo © 2023 Genesis Attachments, LLC Genesis GHG 75-125 Handling Grapple 15... -
Page 16: Maintenance Safety
Do not exceed bolt torque specifications. See the Genesis Fastener Manual. Do not weld on structural components without consulting Genesis. Doing so may cause structural failure and void the warranty. Do not operate an attachment without the case-drain line properly installed if the attachment uses a rotation system that requires a case drain. - Page 17 Never substitute pins or bolts. Use factory supplied pins. Replace all bolts with the same size and grade. Failure to do so may cause serious injury or death. © 2023 Genesis Attachments, LLC Genesis GHG 75-125 Handling Grapple 17...
-
Page 18: Maintenance Schedule
Performing scheduled maintenance will promote safe, reliable operation of your attachment. Use maintenance procedures described in this manual. If you are not able to safely and competently perform these procedures, have a Genesis dealer perform them. NOTICE Extreme operating conditions may require shortened maintenance intervals. -
Page 19: Lubrication Points
2. Stick pin - not shown 3. Attachment cylinder rod 4. Attachment cylinder butt 5. Pivot pins 6. Rotation bearing (four locations) 7. Rotation bearing gear teeth 8. Drag link pins © 2023 Genesis Attachments, LLC Genesis GHG 75-125 Handling Grapple 19... -
Page 20: Bolt Torque Specs
BOLT TORQUE SPECS Bolt torque specs and thread treatment procedures can be found in the Genesis Fastener Manual. genesisattachments.com/manuals Genesis GHG 75-125 Handling Grapple © 2023 Genesis Attachments, LLC... -
Page 21: General Welding Guidelines
Cover the area with a heat blanket and allow it to cool slowly, approximately eight hours. • Do not put the attachment into operation until the welds have been allowed to cool. © 2023 Genesis Attachments, LLC Genesis GHG 75-125 Handling Grapple 21... -
Page 22: Build-Up And Hard-Surfacing
Hard-surfacing patterns are indicated by red lines in the drawings. Crosshatch may be used in place of straight stringers on any flat areas of the jaws and on the outside of the upper jaw. Follow hard-surfacing instructions on the following page. Grain Grain Genesis GHG 75-125 Handling Grapple © 2023 Genesis Attachments, LLC... -
Page 23: Hard-Surfacing
1” to 1-1/2” (25 - 38 mm) to the parent material. 1/4” from edge See the previous page for hard-surfacing illustrations and instructions specific to each area of the jaws. © 2023 Genesis Attachments, LLC Genesis GHG 75-125 Handling Grapple 23... -
Page 24: Hydraulic/Rotation Maintenance
This is the crossover relief setting. Increase supply pressure to achieve approved crossover relief value. Repeat procedure in counter-clockwise direction. Then lower supply pressure back to approved value. Genesis GHG 75-125 Handling Grapple © 2023 Genesis Attachments, LLC... -
Page 25: Slewing Ring Maintenance
® grease, PN 6302601, is recommended for all temperature conditions. DANGER Stand clear when the attachment is being rotated. Always stay in clear view of the operator. © 2023 Genesis Attachments, LLC Genesis GHG 75-125 Handling Grapple 25... -
Page 26: Rotation Circuit
2500 PSI is reached. • Repeat steps 6 and 7 for setting the crossover reliefs. If you have questions regarding setting your rotation circuit, please contact the Genesis Service Department. Genesis GHG 75-125 Handling Grapple © 2023 Genesis Attachments, LLC... -
Page 27: Blade Maintenance
Exchange to the other end of the tine to use corner 4. Rotate one final time to use edge 2. The center blade can only be rotated once. This blade typically does not wear as quickly as the two end blades. 7/8” 1/2” © 2023 Genesis Attachments, LLC Genesis GHG 75-125 Handling Grapple 27... -
Page 28: Grapple Installation
GRAPPLE INSTALLATION Preparation of the excavator prior to attachment delivery will make installation safer and easier. Contact Genesis or your Genesis dealer for assistance. Installation Procedure The attachment is usually shipped in an upright position. Extreme care must be used when positioning the attachment for installation. -
Page 29: Rotator Installation
The rotator requires an additional hydraulic circuit. These diagrams show the installation of the additional circuit. Refer to the Hydraulic/Rotation Maintenance section of this manual for valve descriptions, functions and settings. © 2023 Genesis Attachments, LLC Genesis GHG 75-125 Handling Grapple 29... -
Page 30: Rotation Circuit - Gear Pump Type
Three-position, tandem center, spring-centered, with anti-cavi- tation checks. Flow Relief Setting: 1950 (mounted Controls on excavator) Inside Upper Head Gear Pump Required Mount Valves in Excavator Mount Valves in Excavator Genesis GHG 75-125 Handling Grapple © 2023 Genesis Attachments, LLC... -
Page 31: Rotation Circuit - Auxiliary Valve On Machine
Use 1/2” 3000 PSI rated hose Rotate Valve: Closed- center, three-position, spring-centered, with Flow anti-cavitation checks. Controls Relief valve setting: 1,950 PSI (mounted on excavator) Inside Upper Head Mount Valves in Excavator © 2023 Genesis Attachments, LLC Genesis GHG 75-125 Handling Grapple 31... -
Page 32: General Operation Instructions
More efficient processing will extend the life of the attachment. Genesis GHG 75-125 Handling Grapple © 2023 Genesis Attachments, LLC... -
Page 33: Hydraulic Start-Up
HYDRAULIC START-UP Genesis grapples are designed to operate under full excavator pressure or up to 5000 PSI. Due to these high pressures, it is important that air is bled from the cylinder after installation. Failure to follow these procedures could result in cylinder seal damage and/or excavator hydraulic system damage. -
Page 34: Hydraulic / Rotation Maintenance
This may result in serious personal injury and damage to equipment. Improper torques will also cause uneven wear on the slewing ring. See the Genesis Fastener Manual for proper bolt torque specifications. Grease Slewing Ring Rotating components must be greased daily. -
Page 35: Trouble-Shooting Guide
Hydraulic motor is worn Replace hydraulic motor Flow from excavator is too slow Check excavator hydraulic system flow Grapple rotation is slow Worn hydraulic motor Replace the hydraulic motor © 2023 Genesis Attachments, LLC Genesis GHG 75-125 Handling Grapple 35... - Page 36 TROUBLE-SHOOTING GUIDE Symptom Possible Causes/Solutions Isolate attachment from excavator and check excavator pressures at boom tip or arm Low power Possible cylinder, swivel or bypass (contact Genesis Service Department for procedures) Slow jaw open with Check for damaged seals low power...
-
Page 37: Warranty
Digital pictures are very helpful for diagnosing problems and recommending repairs. Contact the Genesis Service Department before making alterations, changes or repairs to any component that is going to be considered for warranty. Not doing so will void all Genesis warranty consideration. -
Page 38: Parts Order Policy And Procedure
Items shipped without an RGA may be returned to sender. Warranty Returns All parts returned to Genesis for warranty consideration must be returned with a completed RGA (Return Goods Authorization) provided by the Genesis Service Department. The form needs to be completed in its entirety, including any additional information requested by the Service Department. -
Page 39: Parts Order Form
Contact: Shipping Address: E-mail: Billing Address: Purchase Order: Shipping Method: Model: Serial Number: Quantity Part Number Description Price E-mail to the Genesis Parts Department: genesisparts@genesisattachments.com For assistance, call 715-395-5252 © 2023 Genesis Attachments, LLC Genesis GHG 75-125 Handling Grapple 39... -
Page 40: Contact Information
CONTACT INFORMATION Genesis Attachments Europe/Africa/Middle East Genesis GmbH 1000 Genesis Drive Superior, WI 54880 USA Teramostrasse 23 87700 Memmingen, Germany Toll Free: 888-SHEAR-IT (888-743-2748) Phone: +49 83 31 9 25 98 0 Fax: +49 83 31 9 25 98 80 Phone: 715.395.5252...
