High-performance platform for two PCI-
Express Graphics Cards
Do you always want more than everyone else? Then choose this
Mini-PC for professional Multi-Monitoring for up to four screens or
as a high-end games PC with two PCI-E 2.0 Crossfire linked
graphics cards. Meet every performance wish with Intel's pio-
neering Core 2 Processors or up to 8 GB DDR2 memories. Hold all
your data on up to three hard disks and enjoy your Mini-PC to the
full. The effective 450 watt power supply speaks a clear language.
As a guarantor for the best sound the SX38P2 delivers Pro 8-ch HD-
Audio with Dolby Digital Live! and DTS Connect. For more security
this Mini-PC-Barebone has an integrated fingerprint scanner. The
I.C.E. Cooling System with the additional OASIS Module
consistently ensures the optimum cooling of the entire PC System.
Feature Highlight
Black aluminum chassis
P2 chassis
Drive bays: 1x 5.25", 3x 3.5"
Chipset
Intel X38 Express + ICH9R
Socket 775
Supports Core 2 Quad QX6xxx,
Core 2 Duo E6xxx / E4xxx, Pentium Dual-
Core 2xxx
CPU
Supports 1333, 1066 and 800MHz FSB
Shuttle 3 zones heat-pipe cooling system
2x PCI-Express 2.0 (x16), ATI CrossFire
Slots
1x Mini-PCIe (supports Turbo Memory)
Supports 4x DDR2-667/800
DDR2-1066 in overclocking mode*
Memory
Up to 8 GBytes total size
4x SATA (internal) + 2x eSATA (external)
Drive
supports RAID 0, 1, 5, 10 and JBOD
connectors
1x IDE ATA 100, 1x floppy disk drive
Fingerprint recognition technology
Pro-Features
Speed-Link (connects 2 PCs via USB)
8-ch HD-audio, SPDIF in/out
Dolby® Digital Live! and DTS™ Connect
Other
2x Firewire, GigaBit LAN
connectors
USB 2.0 (2x front, 6x rear, 4x onboard)
Power supply
450 Watt ATX power supply (80 PLUS)
Application
Gaming
Prduct ID:
SX38P2 Pro
UPC (see bar code)
www.shuttleshop.com
Product Specification
SX38P2
Note: optical drive sold
separately. Images for
illustration purposes only.
DigiteQ B.V. h.o. Shuttleshop.COM
Graafstroomstraat 75
3044 AP Rotterdam The
Netherlands
Barebone
Pro
T el: +31 88 3088 088
Fax: +31 88 3088 089
sales@digiteq.nl
Advertisement
Table of Contents
Related Manuals for Shuttle SX38P2
Summary of Contents for Shuttle SX38P2
-
Page 1: Product Specification
Mini-PC to the full. The effective 450 watt power supply speaks a clear language. As a guarantor for the best sound the SX38P2 delivers Pro 8-ch HD- Audio with Dolby Digital Live! and DTS Connect. For more security this Mini-PC-Barebone has an integrated fingerprint scanner. - Page 2 The 80 PLUS® performance specification requires power supplies in computers and servers to be 80% or greater energy-efficient. The SX38P2 Pro is in fact the first Shuttle XPC Barebone which has a powerful 450W power supply built in as standard.
- Page 3 Overclocking may affect your system stability or even cause damage of the components and devices of your system. It is done at your own risk and expense. Shuttle cannot be held responsible for possible damage caused by overclocking. www.shuttleshop.com...
- Page 4 32.5 x 22 x 21 cm (LWH) weight: 4.2 kg net / 6.0 kg gross Shuttle FX38, Shuttle form factor, proprietary design for XPC SX38P2 Pro Chipset: Intel X38 Express (MCH) + ICH9R (I/O Conroller Hub) Solid Capacitors for excellent heat resistance for enhanced system durability...
- Page 5 2x PCI-Express x16 Version 2.0 expansion slots for x16 graphics cards (full 16 lanes each slot) Supports Dual Graphics card by ATI CrossFire™ Technology. Two graphics cards can be used to enable 4-monitor-operating or ATI CrossFire™ mode PCI-Express- for leading-edge gaming performance. Expansion Supports two single-slot or one double-width graphics card.
- Page 6 Overclocking may affect your system stability or even cause damage of the components and devices of your system. It is done at your own risk and expense. Shuttle cannot be held responsible for possible damage caused by overclocking.
