OPERATION MANUAL
MODEL:
* Please write down the model name.
(Refer to the rating label.)
* Bitte schreiben Sie den Modellnamen auf.
(Siehe Typenschild)
* Veuillez écrire le nom du modèle.
(Consultez l'étiquette des spécifi cations.)
* Anote el nombre de modelo.
(Consulte la etiqueta de califi cación).
* Annotare il nome del modello.
(Fare riferimento all'etichetta delle specifi che).
* Καταγράψτε το όνομα μοντέλου.
(Ανατρέξτε στην ετικέτα τεχνικών στοιχείων.)
* Registe o nome de modelo.
(Consulte a etiqueta de classifi cação.)
* Запишите название модели.
(См. на паспортной табличке.)
* Lütfen model adını not ediniz.
(Derece etiketine bakınız.)
PART No. 9387858099-02
AIR CONDITIONER (Wall Mounted type)
Before using this product, read these instructions thoroughly
and keep this manual for future reference.
BEDIENUNGSANLEITUNG
KLIMAANLAGE (Wandmontierter Typ)
Bevor Sie dieses Produkt verwenden, lesen Sie diese
Anweisungen sorgfältig durch und bewahren Sie diese
Anleitung für späteres Nachschlagen auf.
CLIMATISEUR (Type à montage mural)
Avant d'utiliser ce produit, veuillez lire attentivement ces
instructions. Conservez ce manuel pour référence future.
MANUAL DE FUNCIONAMIENTO
ACONDICIONADOR DE AIRE (Tipo montado en pared)
Antes de utilizar el producto, lea estas instrucciones detenida-
mente y conserve este manual para consultarlo en el futuro.
CONDIZIONATORE D'ARIA (Tipo montato a parete)
Prima di utilizzare l'apparecchio, leggere attentamente
le presenti istruzioni e conservare il manuale per poterlo
ΚΛΙΜΑΤΙΣΤΙΚΟ (Επιτοίχιος τύπος)
Προτού χρησιμοποιήσετε το προϊόν, διαβάστε προσεκτικά τις
παρούσες οδηγίες και φυλάξτε το παρόν εγχειρίδιο, ώστε να
μπορείτε να ανατρέχετε σε αυτό στο μέλλον.
MANUAL DE FUNCIONAMENTO
AR CONDICIONADO (Tipo mural)
Antes de utilizar este produto, leia atentamente estas instruções
e guarde este manual para referência futura.
РУКОВОДСТВО ПО ЭКСПЛУАТАЦИИ
КОНДИЦИОНЕР ВОЗДУХА (Настенного типа)
Перед эксплуатацией устройства внимательно
ознакомьтесь с данным руководством и сохраняйте его для
Bu ürünü kullanmadan önce verilen talimatları dikkatlice okuyun
ve daha sonra tekrar faydalanmak üzere saklayın.
OPERATION MANUAL
MODE D'EMPLOI
MANUALE DI ISTRUZIONI
consultare il futuro.
ΕΓΧΕΙΡΙΔΙΟ ΛΕΙΤΟΥΡΓΙΑΣ
использования в будущем.
KULLANIM KILAVUZU
KLİMA (Duvara Monte tip)
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Fujitsu ASF07MI-KE
Summary of Contents for Fujitsu ASF07MI-KE
- Page 1 OPERATION MANUAL OPERATION MANUAL AIR CONDITIONER (Wall Mounted type) Before using this product, read these instructions thoroughly and keep this manual for future reference. BEDIENUNGSANLEITUNG KLIMAANLAGE (Wandmontierter Typ) Bevor Sie dieses Produkt verwenden, lesen Sie diese Anweisungen sorgfältig durch und bewahren Sie diese Anleitung für späteres Nachschlagen auf.
-
Page 2: Table Of Contents
[Original Instructions] Contents CAUTION This symbol shows that the operating manual should 1. SAFETY PRECAUTIONS .......... 1 be read carefully. CAUTION 2. PREPARATION ............2 This symbol shows that a service personnel should 3. NAME OF PARTS ............. 3 be handling this equipment with reference to the 3.1. -
Page 3: Preparation
WARNING CAUTION • This product is not intended for use by persons • Do not touch the aluminum fi ns of heat exchanger (including children) with reduced physical, sensory built-in this product to avoid personal injury when you or mental capabilities, or lack of experience and maintain the unit. -
Page 4: Name Of Parts
3.2. Remote controller 3. NAME OF PARTS When you use the optional remote controller, the appearance and the operation procedure may differ. CAUTION For details, please refer to the operating manual of each remote controller. For appropriate signal transmission between the remote controller and the indoor unit, keep the signal receiver : The setting must be done while the setting screen is displayed away from the following items:... - Page 5 CAUTION • To prevent malfunction or damage of the remote controller: - Place remote controller at where will not be exposed to direct sunlight or excessive heat. - Remove batteries if the product is not going to be used for an extended period. •...
-
Page 6: Inserting Batteries
3.3. Inserting batteries 4. BASIC OPERATIONS Battery type: R03/LR03/AAA x 2 3 steps to start operation 1. Press to start or stop the operation. 2. Press to select the operation mode. The operation mode changes as follows. AUTO COOL HEAT 3. -
Page 7: Timer Operations
Horizontal airfl ow direction setting 5. Press to complete the timer setting. Be close to the indoor unit. CAUTION • To cancel the timer setting during the procedure, press Before you adjust the horizontal airfl ow direction, make again. sure that the vertical airfl... -
Page 8: On Timer Or Off Timer
• You cannot the Weekly timer and the other timers simultaneously. During the Sleep timer operation, the setting temperature changes as the following fi gure. If you use the On/Off timer, the Program timer, or the Sleep timer while the Weekly timer is activated, the Weekly timer will be In Heating mode In Cooling or Dry mode deactivated. -
Page 9: Outdoor Unit Low Noise Operation
8.2. Outdoor Unit Low Noise operation • To change the air conditioner custom code, contact an authorized service personnel (initially set to A). • If you do not press any buttons for 30 seconds after the custom The Outdoor Unit Low Noise operation lowers noise from the outdoor code is displayed, the display returns to the clock display. - Page 10 7. Set the new or washed air cleaning fi lters into the air Cleaning air fi lter cleaning fi lter holders. 1. Open the intake grille until it snaps. NOTES: Use the Apple-catechin fi lter as soon as possible after opening the package.
-
Page 11: General Information
Indoor unit temperature and humidity range After extended non-use of the unit Permissible ranges of temperature and humidity are as follows: If you have shut down the indoor unit for 1 month or more, perform the Indoor temperature Cooling/Dry [°C] 18 to 32 Fan mode operation for half a day to dry the internal parts thoroughly... - Page 12 Google Play is a registered trademark of Google Inc. Step 4. Air conditioner registration (pairing of WLAN adapter) App Store is a service mark of Apple Inc., registered in the U.S. and other countries. NOTES: • Before starting this setting, reconnect the power supply of the air Setting to use WLAN control conditioner and wait for 60 seconds or more.
-
Page 13: Multi-Split Type Air Conditioner
Temporary deactivation of WLAN 12.4. Multi-split type air conditioner NOTES: If you do not press any buttons of the remote controller for 60 This indoor unit can be connected to a multi-split type outdoor seconds, the remote controller display will return to the original unit. - Page 14 Does not operate at all. Mist or steam is emitted from the unit. □ Has there been a power outage? □ <In the Cooling or Dry mode> A thin mist may be generated by In this case, the unit restarts automatically after the power supply condensation formed with sudden cooling process.
- Page 15 State of indicator lamps : The instruction is relating to the WLAN control (optional). Lighting pattern: Blinking, Any state State Causes and solutions page Automatic defrosting operation ⇒ Please wait until fi nishing the defrosting (maximum of 15 minutes). Filter indicator ⇒...
