Supporting pole
The supporting pole is used to enable the assessment of the wireless link quality in high locations.
It can be used, also, for assessing lower locations and areas for possible interference caused by wireless fading.
1. Assemble the pole as per picture 6.
2. Fix the survey detector probe at one end of the pole (picture 6).
Picture 6
Dongle interface device - battery power supply
1. Extract the battery cover from the back of the Dongle device.
2. Insert both LR6 AA batteries into their housing.
Batteries polarities must match the indicated polarity on the device.
3. Reinsert the battery cover.
4. Switch on the Dongle device (On / Off switch on the device; check picture 8).
Dongle's LED performs some green-red blinking, then stops: the device is now powered on.
Picture 7
ARGUS SECURITY S.R.L. - Via del Canneto, 14 - 34015 - Muggia (TS) - Italy
Picture 8
OFF ON
LED
