The following table gives the key to symbols that are used in the Survey app.
Icon Description
Survey detector probe's primary battery low
Survey detector probe's secondary battery low
No wireless link between survey detector probe and the SGWE
Dongle interface device's batteries low
Wireless link quality level between the Dongle and the SGWE
Numerical indication of the survey's link quality level on the primary antenna
Numerical indication of the survey's link quality level on the secondary antenna
Survey's link quality level is indicated in decibel units
Survey's link quality level is indicated in RSSI units
Selected emulated device type indication
Survey system parameter details and operating channel selection
Table 2
