6. Click Edit.
7. Enter the same IP address you assigned to the dedicated interface (in our example, LAN4).
8. Click Apply

VLANs

To create/edit a tag based VLAN:
You can create a new VLAN only if you have at least one physical interface that is not part of an existing
network (switch or bridge).
Note - For more information on the maximum number of VLANs that you can configure for each
appliance, refer to
Configure the fields in the tabs:
The 'Configuration' tab
VLAN ID - Enter a number that is the virtual identifier.
n
Assigned to - Select the physical interface where the new virtual network is created.
n
n IP address
Subnet mask
n
Use Hotspot - Select this checkbox to redirect users to the Hotspot portal before allowing access
n
from this interface.
You define the Hotspot configuration in the
DHCP Server settings
n
Select one of the options:
Enabled - Enter the IP address range and if necessary the IP address exclude range. The
l
appliance's own IP address is automatically excluded from this range. You can also exclude or
reserve specific IP addresses by defining network objects in the
Objects page. Reserving specific IP addresses requires the MAC address of the device.
Relay - Enter the DHCP server IP address.
l
Disabled
l

Alias IP

With an alias IP, you can associate more than one IP address to a network interface.
A single network device can have multiple connections to a network.
n
A specific port is used by more than one network.
n
All devices are on the same network, even though they show different IPs. For example, LAN4 and LAN4:1
have different IP addresses, but are on the same network. LAN4:1 is the alias.
You can also have an alias IP for VLAN and a switch.
Quantum Spark 1500, 1600, and 1800 Appliances R81.10.X Locally Managed Administration Guide | 91
sk113247
Device > Hotspot page.
Configuring the Local Network
Users & Objects > Network
