Owner's Guide and Installation Manual
Attach sales receipt to this card and retain as your proof of purchase
DATE OF PURCHASE:
MODEL NUMBER:
To register your fixture, please visit our website www.montecarlofans.com
3TTHR44XXXD Series Fan
CUL Model NO. : 3TTHR44XXD
RETAILER NAME:
RETAILER ADDRESS:
6.28 kg
13.8 lbs
Total fan weight with light
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Monte Carlo Fan Company 3TTHR44 D Series
Summary of Contents for Monte Carlo Fan Company 3TTHR44 D Series
- Page 1 Owner’s Guide and Installation Manual 3TTHR44XXXD Series Fan CUL Model NO. : 3TTHR44XXD Attach sales receipt to this card and retain as your proof of purchase DATE OF PURCHASE: RETAILER NAME: RETAILER ADDRESS: MODEL NUMBER: To register your fixture, please visit our website www.montecarlofans.com 6.28 kg 13.8 lbs Total fan weight with light...
-
Page 2: Cautions And Warnings
Cautions and Warnings WARNING: TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS, OBSERVE THE FOLLOWING READ AND SAVE THESE INSTRUCTIONS Installation work and electrical wiring must be done by qualified person(s) in accordance with applicable codes and standards (ANSI/NFPA 70) including fire-rated construction. - Page 3 Outlet box Before you begin installing the fan, Switch Before installing this fan make sure the Use metal outlet box suitable for fan power off at Service panel and lock outlet box is properly installed to the support and use only the screws provided service disconnecting means to prevent house structure.
- Page 4 SAFETY CABLE INSTALLATION White Wall switch Black Hook Drawing 7 Power source Green/Ground Green/Ground Black Lag screw White Black Safety cable Washer Lock washer Hang motor assembly onto the hook on For Canadian installation and for USA fan Make wiring connections as indicates mounting plate for hands-free wiring and above, using wire connectors provided.
- Page 5 Light fixture Plate on motor Light pan Loosen 2 and remove 1 preassembled Loosen 2 and remove 1 preassembled Connect white wire from fan to white wire from LED light fixture and then connect blue (or screw from the plate on motor. Save screw from light pan.
-
Page 6: Learn Mode
Remote Controller Operation Remove the battery cover from the remote control transmitter and install batteries. Replace the cover. This remote uses 2 1.5V/AAA batteries. Note: If not using for long periods of time, remove the batteries to prevent damage to DIM (D) remote controller, and store the remote controller away from excess heat or humidity. - Page 7 Install Transmitter wall mount cradle with 2 screws provided. Useful tips: The remote transmitter can be removed by pressing it upward from the lower half. The remote transmitter can be held on magnetic metal materials by a magnet built in the transmitter. Wall mount cradle User Tips 1.
-
Page 8: Troubleshooting
Troubleshooting or wiring. In some cases, these installation errors may be mistaken for defects. If you experience any faults, installation, please call our Customer Service Center at the number printed on your parts list insert sheet. Warning and lock the service panel to prevent the power from being switched back on accidentally. If the service panel cannot be locked to prevent the power from being switched on accidentally, securely fasten a warning sign to the service panel. - Page 9 Aug.2022...
