AXM-800ML / AXM-D800ML / AXM-1200ML / AXM-D1200ML Series
Electromagnetic Lock Installation Instruction (Indoor Series)
Technical Specification
Specification
Operating Voltage
12/24VDC
500mA/12VDC
Current Draw
270mA/24VDC
Operating
32° to +120.2°F ( 0° to +49°C )
Temperature
800lbs
Holding Force
1200lbs
Lock Surface
Current temperature ± 20°C
Temperature
Humidity
0 to 85% Non-condensing
Magnet Surface : Galvanized
Finish
Housing : Brushed stainless
steel(US32D)
"The products shall not impair the intended operation of an emergency exit or panic hardware mounted on the door."
Dimension & Accessories
AXM-800ML
Series
Mounting Plate
29
Magnet
14
Armature Plate
185
29
14
185
45
14
AXM-D800ML
Series
AXM-800ML
AXM-800MLDS
AXM-800MLTD
AXM-800MLDS-TD
AXM-800ML Series
800lbs x2
AXM-1200ML Series
AXM-D800ML
AXM-D800MLDS
AXM-D800MLTD
AXM-D800MLDS-TD
Anti-tamper Nut
265
52,5
45
Square LED
530
52,5
185
45
Copyright
All rights reserved. P-MU-AM-AXM Published on: 2021.01.21
Model
800lbs
1200lbs
AXM-1200ML
AXM-1200MLDS
AXM-1200MLTD
AXM-1200MLDS-TD
1200lbs x2
AXM-D1200ML
AXM-D1200MLDS
AXM-D1200MLTD
AXM-D1200MLDS-TD
AXM-1200ML
Series
40
16
6
185
40
16
185
61
6
AXM-D1200ML
Series
Type
Notes:
ML:
ML
Bond sensor & Bi-color
square LED indicator
ML,DS
DS: Door status sensor
ML,TD
TD: Relock time delay
DBL: Double
ML,TD,DS
DBL,ML
DBL,ML,DS
DBL,ML,TD
DBL,ML,TD,DS
267
61
533
16
185
61
Unit:mm
6
71,5
6
71,5
