Unpack the machine and check the components
Toner Cartridge and Drum Unit
1
Remove the packing materials and re-install the toner cartridge and drum unit assembly
2
Load paper in the paper tray
3
Connect the power cord and turn the machine on
Back
Quick Setup Guide
HL-L5210DN / HL-L5210DW / HL-L6210DW / HL-L6410DN / HL-L6415DW
Read the Product Safety Guide first, then read this Quick Setup Guide for the correct installation procedure.
Not all models are available in all countries.
Video setup instructions:
support.brother.com/videos
Assembly
(Installed in the machine)
Quick Setup Guide
Discard the silica
gel pack.
Adjust the paper
guides.
Power button location may vary depending
on the model.
Front
NOTE:
• The components included in the box may differ depending on your
• The available connection interfaces vary depending on the model.
AC Power Cord
USB Port Cover
(Not included in all models)
• The illustrations in this Quick Setup Guide show the HL-L6415DW.
Product Safety Guide
Do not exceed this mark.
The latest manuals are available at the Brother support website:
support.brother.com/manuals
country.
You must purchase the correct interface cable if you require one.
• USB cable
We recommend using a USB 2.0 cable (Type A/B) that is no more
than 2 metres long.
• Network cable
Use a straight-through Category 5 (or greater) twisted-pair cable.
Remove the orange part.
