InfraRed Thermometer
Built‐in UV Refrigerant Leak Detector and Flashlight
Model IR300UV

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IR300UV and is the answer not in the manual?

Questions and answers

Summary of Contents for Extech Instruments IR300UV

  • Page 1 USER MANUAL    Visit us at www.TestEquipmentDepot.com InfraRed Thermometer  Built‐in UV Refrigerant Leak Detector and Flashlight  Model IR300UV ...
  • Page 2: International Safety Symbols

    EXTECH INSTRUMENTS  Introduction  Congratulations on your purchase of the IR300UV IR Thermometer. This thermometer makes  non‐contact (infrared) temperature measurements at the touch of a button. The built‐in coaxial  laser pointer increases target accuracy while the backlit LCD and handy multi‐switch combine for  convenient, ergonomic operation. The UV light source is convenient for locating leaks such as  refrigerants. This device is shipped fully tested and calibrated and, with proper use, will provide  years of reliable service. Features   Measures non‐contact surface temperature up to 500°C (932°F)  12:1 Distance to Spot Ratio (Field of View)  Area and Single‐point laser targeting  Display MAX, MIN, AVG or MAX‐MIN Difference   Automatic Data Hold when trigger is released   Display Backlight  Selectable temperature units (°F / °C)  Adjustable emissivity  Audible and visible alarm indication for High and Low Temperature Alarm  UV leak detector with 5 UV/Blue LEDs  Bright flashlight with 5 White LEDs Safety  International Safety Symbols  This  symbol,  adjacent  to  another  symbol  or ...
  • Page 3: Meter Description

    EXTECH INSTRUMENTS  Description    Meter Description  1. LCD Display  2. Multi‐Switch control  3. Battery Compartment  4. Laser pointer  5. White/Blue LEDs  6. IR sensor  7. Lens cover control  8. Measurement Scan Trigger  Display Description  Laser pointer active icon    Hold mode (displayed temperature freezes with trigger release)    Maximum/Minimum/Average temperature icons    Battery capacity indicator     White LEDs active    Temperature units (°F /°C)    Temperature Alarm icons     UV LEDs active  Emissivity setting                                                IR300UV‐en‐GB_V1.0   1/16 ...
  • Page 4: Operation

    The  Settings  switch  has  five  positions  to  select  a  parameter,  turn  a  parameter ON or OFF, and to adjust parameter values.   Press and release the Measurement Trigger.   Press  the    button  left  to  enter  the  Setting  Mode.  The  parameter selected will appear in the display.   Press the   button right to advance to the next parameter.   Press the up   or down   buttons to change a parameter status or adjust a parameter  value.   Press the   button to store parameter changes and advance to the next parameter.   Press the   button left to exit the Settings mode and return to Measurement mode.  Note: If no button is pressed within the APO time the meter will shut down. It may be helpful  to extend the APO time when making adjustments in the Settings mode.                                                IR300UV‐en‐GB_V1.0   1/16 ...
  • Page 5  for ON or OFF. Press   to store the setting  If ON was selected, Press up    or down   to adjust the limit.   Press   to store the setting  Alarm LO Setting  Enter the Setting mode. Advance until the Alarm LO icon flashes.   Press up    or down   for ON or OFF. Press    to store the setting  If ON was selected, Press up    or down   to adjust the limit.   Press   to store the setting  Backlight Setting  Enter the Setting mode. Advance until the LItE icon flashes.   Press up    or down    for ON or OFF. Press    to store the setting  10. Auto Power OFF Setting  Enter the Setting mode. Advance until the APO icon flashes.   Press up   or down    to adjust the setting. Press   to store the setting                                                IR300UV‐en‐GB_V1.0   1/16 ...
  • Page 6: Surface Temperature Measurements

    3. Hold the meter by its Handle Grip and point it toward  the surface to be measured.   4. Pull and hold the Trigger to turn the meter on and  begin testing in Scan mode. The display will light if the  batteries are good. Replace the batteries if the display  does not light.  5. Release the Trigger; the reading will HOLD for the time  set in the APO setting. The backlight will turn off after approximately 4 seconds.  6. The meter defaults to the programmed conditions in use when the meter was last switched  OFF.   Laser Pointer  The  laser  pointer  circle  identifies  the  area  being  measured. The size of the area is determined by the  distance to spot ratio. Objects outside the circle are  not measured. The spot measured should always be  larger than the circle for accurate measurements.  MAX, MIN, AVERAGE and MAX‐MIN  In the MAX MIN AVG mode the meter will record the Maximum value scanned, Minimum value  scanned, the Average of the scanned values and the Difference between the Max and Min value.  1. Turn Max Min ON in the settings mode  2. Press and hold the trigger to scan an area. Max, Min, Avg or Max‐Min  will be displayed in the lower right display. Press the up    button to  select the parameter to be displayed. The values will be continuously  updated for the length of the scan.                                                  IR300UV‐en‐GB_V1.0   1/16 ...
  • Page 7   Distance to Spot Ratio (Field of View)  The meter’s field of view is 12:1 (distance to spot ratio). For example, if the meter is 60cm (24  inches) from the target (spot), the diameter of the target must be at least 5cm (2 inches). Other  distances are shown below in the field of view diagram.  Note  that  measurements  should  normally  be  made  further  than  60cm  (24  inches)  from  the  target. The meter can measure from further distances but the measurement may be affected by  external sources of light. In addition, the spot size may be so large that it encompasses surface  areas not intended to be measured.      2.5cm @ 30cm  5cm @ 60cm  10cm @ 120cm  1” @ 12”  2” @ 24”  4” @ 48”    It is necessary to ensure that the size of the target is larger than the spot size. The smaller the  target, the closer the distance should be.                                                             IR300UV‐en‐GB_V1.0   1/16 ...
  • Page 8: High Low Limits

    EXTECH INSTRUMENTS  Emissivity  Emissivity represents the energy reflectivity of a material. Most organic materials and painted  or oxidized surfaces have an emissivity of approximately 0.95. If possible, masking tape or flat  black paint should be applied to cover the measured surface.  Wait a period of time to allow the tape or paint to reach thermal equilibrium with the surface  of the covered object. Measure the temperature of the surface covered with tape or paint only  after equilibrium has been achieved.  High Low Limits  The HI / LO limits provide an alarm when a preset temperature is exceeded.  Lens Cover  The lens cover protects the lens from dust when the meter is not in use. Always close the cover  when storing the meter.  Measurement Notes  1. The object under test should be larger than the spot (target) size calculated by the field of  view diagram.  2. If the surface of the object under test is covered with frost, oil, grime, etc., clean before  taking measurements.  3. If an object's surface is highly reflective apply masking tape or flat black paint to the surface  before measuring.  4. The meter may not make accurate measurements through transparent surfaces such as  glass.  5. Steam, dust, smoke, etc. can obscure measurements.  6. The meter compensates for deviations in ambient temperature. It can, however, take up to  30 minutes for the meter to adjust to extremely wide ambient temperature changes.  7. To find a hot spot, aim the meter outside the area of interest then scan across (in an up and  down motion) until the hot spot is located.  8. When the meter is held at the optimum distance from the target, the single laser dot will  appear at the top of the circular laser target.  As long as the single laser dot is within the  circular laser target, the meter will make an accurate measurement.                                                IR300UV‐en‐GB_V1.0   1/16 ...
  • Page 9: Maintenance

    EXTECH INSTRUMENTS  Maintenance  Cleaning  To clean the lens use compressed air to clear dust and other particles, then carefully clean with a  wet cotton swab. The cotton swab should be moistened with clean water.  To clean the meter housing, wipe with a damp, soft cloth. Do not use solvents or abrasives. Do  not immerse the IR300UV in water or other liquid.  Replacing Batteries  When the battery icon indicates a low battery, or when the meter  doesn’t switch ON, replace the batteries.  The battery compartment lid is located on the rear of the handle.  Remove the one Philips head screw and lift the lid off.  Replace the three 1.5V AA batteries following correct polarity and then  replace and secure the battery compartment lid.  Battery Safety Notes: Please dispose of batteries responsibly; never dispose of  batteries in a fire, batteries may explode or leak. If the meter is not to be used  for 60 days or more, remove the battery and store separately. Do not mix  battery types or freshness levels; please use batteries of the same type and of the same freshness level.  Never dispose of used batteries or rechargeable batteries in household waste.  As consumers, users are legally required to take used batteries to appropriate collection sites, the  retail store where the batteries were purchased, or wherever batteries are sold.  Disposal: Do not dispose of this instrument in household waste. The user is obligated to take end‐of‐life  devices to a designated collection point for the disposal of electrical and electronic equipment.   Specifications  Infrared Thermometer Specifications  Range / Resolution  ‐30~500 C (‐22~932 F)   0°C:   ±1.5°C or 1.5% of reading (whichever is greater)  Accuracy   32°F:   ±3°F or 1.5% of reading (whichever is greater)   ‐10°C to 0°C:   ±2°C  14° to 32°F:   ±4°F  Note: Accuracy is specified for the ambient temperature range:  21~25°C (70~77°F)  500ms (95% of reading)  Response Time  Repeatability (% of reading)  ±8% of reading or ±1.0°C (1.8°F) whichever is greater ...
  • Page 10: General Specifications

    2000m (7000 ft.) above sea level  Storage Altitude  12,000m (40,000 ft.) above sea level  Drop Proof  1.2m (4 ft.)  Power Supply  3x1.5V AA IEC LR06 batteries  Automatic Power Off  Adjustable  1 to 60 seconds  Weight        300g (10.6 oz.)  Dimensions  185 x 54 x 104mm (7.3 x 2.1 x 4.1”)  Vibration and Shock  IEC 60068‐2‐6 2,5g, 10Hz to 200Hz  IEC 60068‐2‐27 50g, 11ms  EMC  EN61326‐1:2006 EN61326‐2:2006  Compliance  EN/IEC 61010‐1  Copyright © 2016 FLIR Systems, Inc.   All rights reserved including the right of reproduction in whole or in part in any form    ISO‐9001 Certified  Test Equipment Depot - 800.517.8431 - 99 Washington Street Melrose, MA 02176 TestEquipmentDepot.com                    IR300UV‐en‐GB_V1.0   1/16 ...
