SERVICE MANUAL
SERVICE MANUAL
BLU-RAY DISC PLAYER
DBS-30.2(B)CDD1N
MODEL
Black model
B CDD1N
SAFETY-RELATED COMPONENT
WARNING!!
COMPONENTS IDENTIFIED BY MARK
SCH E MATIC DIAGRAM AND IN TH E PARTS LIST ARE
CRITICAL FOR RISK OF FIRE AND ELECTRIC SH O CK .
REPLACE TH E SE COMPONENTS WITH ONK Y O
PARTS WH O SE PART NUMBERS APPEAR AS SH O WN
IN TH I S MANUAL.
MAK E LEAK A GE-CURRENT OR RESISTANCE
MEASUREMENTS TO DETERMINE TH A T EX P OSED
PARTS ARE ACCEPTABLY INSULATED FROM TH E
SUPPLY CIRCUIT BEFORE RETURNING TH E
APPLIANCE TO TH E CUSTOMER.
120V AC, 60Hz
ON TH E
DBS-30.2(US)
Ref. No. 4232
July, 2010 (US)
RC-794DV
