- Page 1 USER’S MANUAL SMART APP SINEWAVE UPS SERIES PR750RT2U PR750RTXL2U PR1000RT2U PR1000RTXL2U PR1500RT2U PR1500RTXL2U PR2000RT2U PR2000RTXL2U PR2200RT2U PR2200RTXL2U PR3000RT2U PR3000RTXL2U K01-0000638-02...
-
Page 2: Product Registration
Thank you for purchasing a CyberPower product. Please take a few minutes to register your product at www.cyberpowersystems.com/registration. Registration certifies your product's warranty, confirms your ownership in the event of a product loss or theft and entitles you to free technical support. Register your product now to receive the benefits of CyberPower ownership. INTRODUCTIONS... -
Page 3: Important Safety Instructions
CAUTION! Do not unplug the unit from AC Power during operation, as this will invalidate the protective ground insulation. CAUTION! To reduce the risk of fire, connect only to a circuit provided with 20 amperes maximum branch circuit overcurrent protection in accordance with the National Electric Code, ANSI/NFPA 70. (PR750RT2U/ PR1000RT2U/ PR1500RT2U/ PR2000RT2U/ PR750RTXL2U/ PR1000RTXL2U/ PR1500RTXL2U/ PR2000RTXL2U) CAUTION! To reduce the risk of fire, connect only to a circuit provided with 30 amperes maximum branch circuit overcurrent protection in accordance with the National Electric Code, ANSI/NFPA 70. - Page 4 UNPACKING When you receive the unit, the package should contain the following items: UPS Unit Faceplate Rail Kit CP2RAIL02 (14) M5 Pan Head Screw (8) Plastic Washers Note: It is available for PR3000RT2U/ PR1500RTXL2U/ PR2000RTXL2U/ PR2200RTXL2U/ PR3000RTXL2U. Management Cable (1) USB Cable (1) Serial Cable (1) EPO Cable User’s Manual...
-
Page 5: Product Overview
AC Inlet Wiring Fault Indicator Extended Battery Module Connector Socket BM/ENV Port BM/ENV Port Connection port for built-in battery management module on extended battery module. The port also supports the CyberPower environment sensor. PR750RT2U / PR1000RT2U / PR1500RT2U PR2000RT2U PR2200RT2U PR3000RT2U... -
Page 6: Installation
BASIC CONFIGURATION (continued) PR2000RTXL2U PR2200RTXL2U PR3000RTXL2U INSTALLATION The product is designed for tower installation and rack installation for 2-post rack and 4-post rack. Read and follow the procedures thoroughly before and during your installation of the product. The installation videos are available online. Scan the QR code below for detailed information. Preparation CAUTION! It is strongly recommended to have an additional person assist this installation process if the product is heavy. -
Page 7: Basic Operation
Press the power switch on LCD module once. The LCD screen will light up and show “UPS On/Off” on the first line. Use the Up/Down button to select “On” or “Delay On” and then press the Enter button to turn on the UPS. The LCD screen will show CyberPower in the first line and the UPS model in the second line. -
Page 8: Cleaning And Maintenance
Up/Down button to select “On” or “Delay On” and then press the Enter button to turn on the UPS. The LCD screen will show CyberPower in the first line and the UPS model in the second line. Then the Online or On Battery Indicator on the LCD module lights up, indicating the UPS is operating from utility or battery. -
Page 9: Data Line Protection
Note: USB and Serial port cannot be used simultaneously. Serial port will be disabled if the USB port is used. Additionally, if you would like to control the UPS from a remote location, a CyberPower Remote Management Card (RMCARD) is required. For... - Page 10 PRODUCT ADVANCED SETTING LCD OPERATION GUIDE Display Interface Power Switch/Power on Indicator Online Indicator Fault/Warning Indicator On Battery Indicator Night Mode Indicator Display Screen Menu Button Esc Button Up Button Down Button Enter Button Basic Operation Press Up/Down Button to scroll through the UPS status. Press Esc button to go back to top. Menu Item ...
- Page 12 LCD OPERATION GUIDE (continued) Menu / Basic Setup In order to better supply power to the connected equipment, it is recommended to check settings in this menu before you start using your UPS. Item Default Option Description Select the voltage quality of the input utility power. ...
- Page 13 LCD OPERATION GUIDE (continued) Item Default Option Description If On is selected, the LED indicators work normally. If Off is selected, the LED indicators will turn off after a few Night Mode LED Switch seconds except for Fault Indicator. Pressing any button will activate the LED Indicators.
- Page 14 LCD OPERATION GUIDE (continued) Menu / Test This menu provides basic tests and calibration for users to check the current performance of the UPS. Item Default Option Description Select Yes to order the UPS to quickly test the backup Self Test function by entering to battery mode, checking if it works.
- Page 15 LCD OPERATION GUIDE (continued) Item Default Option Description Never After 10 seconds After this amount of time with no activity, UPS will start Cycling Display Never cycling the status information on LCD screen. After 20 seconds After 30 seconds The UPS will emit an audible alarm, as a reminder that ...
- Page 16 E27-Fan Fail(FR): Contact CyberPower for repair. Warning! E27-Fan Fail(FL): Contact CyberPower for repair. Warning! E29-Fan Fail (B): Contact CyberPower for repair. Warning! Battery Missing: Check battery wiring and condition. Beeps once every 2 seconds for a period of 30 seconds...
- Page 17 EPO AND ROO CONFIGURATION The Emergency Power Off (EPO) port is a safety feature that can be used to immediately shut down the UPS and cut off its power supply to connected equipment. It is necessary to manually press the power switch on the LCD module to restart the UPS and reapply power to connected equipment.
-
Page 18: Dry Contact
DRY CONTACT This UPS offers users the solution for UPS status monitoring via two output relays. Refer to Network Operation in this manual, verifying the UPS is connected to a computer with PowerPanel® Business software installed or is equipped with RMCARD. Follow below circuit to wire your dry contact port and choose your preferred monitoring status via those interfaces. -
Page 19: Battery Replacement
BATTERY REPLACEMENT Read and follow the important safety instructions before servicing the batteries. Visit CyberPower official website www.cyberpowersystems.com or contact your dealer for more information on replacement batteries. The battery replacement video is available online. Scan the QR code below for detailed information. -
Page 20: Technical Specifications
TECHNICAL SPECIFICATIONS Model PR750RT2U PR1000RT2U PR1500RT2U PR2000RT2U PR2200RT2U PR3000RT2U General UPS Topology Line-interactive Energy Saving GreenPower UPS Bypass Technology Input Nominal Input 100/110/120/125V 100/110/120V Voltage For 110/120V systems: 75V – 155V; For 100V Input Voltage Range For 110/120/125V systems: 75V – 155V; For 100V systems: 70V – 129V systems: 70V –... - Page 21 TECHNICAL SPECIFICATIONS (continued) Model PR750RTXL2U PR1000RTXL2U PR1500RTXL2U PR2000RTXL2U PR2200RTXL2U PR3000RTXL2U General UPS Topology Line-interactive Energy Saving GreenPower UPS Bypass Technology Input Nominal Input 100/110/120/125V 100/110/120V Voltage For 110/120V systems: 75V – 155V; For 100V Input Voltage Range For 110/120/125V systems: 75V – 155V; For 100V systems: 70V – 129V systems: 70V –...
-
Page 22: Troubleshooting
Menu and disable the function. Batteries are not fully charged. Recharge the batteries by leaving the UPS plugged in. Batteries are degraded. Contact CyberPower about replacement batteries. UPS does not perform expected runtime. Adjust the setting of Extended Battery Module Quantity on your UPS does not recognize the correct UPS to correct numbers via LCD module, PowerPanel®... - Page 23 TROUBLESHOOTING (continued) Problem Possible Cause Solution The continuous generator capacity rating must be at least twice the total load, including the UPS and all other devices attached to the The size of generator is not suitable for generator; otherwise, the generator may not be able to hold the current load.
-
Page 24: Battery Disposal
DISPOSAL The Waste Electrical and Electronic Equipment (WEEE) Directive aims to contribute to sustainable production and consumption by contributing to the efficient use of resources and the retrieval of secondary raw materials through re-use, recycling and other forms of recovery. The symbol on this product and/or its packaging indicates that the product must be disposed of separately from ordinary household wastes at its end of life. -
Page 25: Regulatory Compliance
REGULATORY COMPLIANCE FCC Compliance Statement (PR750RT2U/ PR1000RT2U/ PR1500RT2U/ PR2000RT2U/ PR750RTXL2U/ PR1000RTXL2U/ PR1500RTXL2U/ PR2000RTXL2U) This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. - Page 26 REGULATORY COMPLIANCE (continued) DOE Compliance Statement This device complies with Energy Conservation Standards of the Energy Conservation Program issued by the U.S. Department of Energy in accordance with 10 CFR Parts 429, 430 and 431, as appropriate, and the Energy Policy and Conservation Act, as amended, under the setup as described below.
-
Page 27: Technical Support
Our online, self-service resources are available 24/7. CyberPower also offers assistance from our expert team of sales, technical, and product support associates. Our Technical Support team will be happy help you with technical questions during business hours.
