Washing Machine
OWNER'S MANUAL
FW712
Read This Manual
Use all instructions and explanations of
the installation before use. Follow the
instructions carefully. Keep the operation
instructions handy for later use. If the
application is sold or passed on then ensure
that the new owner always receives those
operation instructions.
Advertisement
Table of Contents
Related Manuals for Frigidaire FW712
Summary of Contents for Frigidaire FW712
- Page 1 Washing Machine OWNER’S MANUAL FW712 Read This Manual Use all instructions and explanations of the installation before use. Follow the instructions carefully. Keep the operation instructions handy for later use. If the application is sold or passed on then ensure that the new owner always receives those operation instructions.
-
Page 2: Table Of Contents
CONTENTS SAFETY INSTRUCTIONS Safet y Inst ruct ions ..........INSTALLATION Product Descript ion ..........I nst allat ion ............OPERATIONS Quick St art .............. Before Each Washing ..........Det ergent Dispenser ..........Cont rol Panel ............Opt ion ..............Ot her Funct ions . -
Page 3: Safety Instructions
SAFETY INSTRUCTIONS Safety Instructions For your safety,the information in this manual must be followed to minimize the risk of fire or explosion, electric shock, or to prevent property damage, personal injury or loss of life. Explanation of the symbols: ！ Warning! This combination of symbol and signal word indicates a potentially dangerous situation which may result in... - Page 4 SAFETY INSTRUCTIONS • The new h ose-set s supplied w it h t he appliance are t o be u sed and t hat o ld hose-set s should not b e reused. • Before any maint enance t he device, unplug t he a ppliance from t he mains.
- Page 5 SAFETY INSTRUCTIONS • Glass door may be very hot during the operation. Keep kids and pets far away from the machine during the operation very wet rooms as well as in the rooms with explosive or caustic gas. • Remove all packages and transport bolts before using the appliance.
- Page 6 SAFETY INSTRUCTIONS • Remove all packages and transport bolts before using the appliance. Otherwise, serious damage may result. Risk of damaging appliance! • Your product is only for home use and is only designed for the textiles suitable for machine washing. •...
- Page 7 SAFETY INSTRUCTIONS • Make sure that all pockets are emptied. Sharp and rigid items such as coin,brooch,nail,screw or stone etc. may cause serious damages to this machine. • Please check whether the water inside the drum has been drained before opening its door.Please do not open the door if there is any water visible.
-
Page 8: Product Description
INSTALLATION Product Description Top cover Water supply hose Control panel Power supply cord Detergent dispenser Drum Door Service filter Drain hose Note! • The product line chart is for reference only, please refer to real product as standard. Accessories Transport Drain hose support Owner’s manual... -
Page 9: Installation
INSTALLATION Installation Installation area ！ Warning! • Stability is important to prevent the product from wandering! • Make sure that the product should not stand on the power cord. W> 20mm Before installing the machine, the location characterized follows shall be selected: 1.Rigid, dry, and level surface 2.Avoid direct sunlight 3.Sufficient ventilation... - Page 10 INSTALLATION Levelling the washing machine ！ Warning! • The lock nuts on all four feet must be screwed tightly against the housing. Check if the legs are closely attached to the cabinet. If not, please turn them to their original positions tighten the nuts. 2.Loosen the lock nut turn the feet until it closely contacts with the floor.
- Page 11 INSTALLATION Connect the other end of inlet pipe to the inlet valve at the backside of product and fasten the pipe tightly clockwise. water supply hose water Inlet valve Drain Hose ！ ！ Warning! Warning! • Do not kink or protract the drain hose. •...
-
Page 12: Operations
OPERATIONS Quick Start Caution! • Before washing, please make sure it’s installed properly. • Before washing at first time, the washing machine shall be operated in one round of the whole procedures without clothes in as follows. 1. Before Washing Main wash Softener... -
Page 13: Before Each Washing
OPERATIONS Before Each Washing • The working condition of the washer should be(0-40)°C.If used under 0°C,the inlet valve and draining system may be damaged. If the machine is placed under condition of 0°C or less, then it should be transferred to normal ambient temperature to ensure the water supply hose and drain hose are not frozen before use. -
Page 14: Detergent Dispenser
OPERATIONS Detergent Dispenser Prewash detergent Main wash detergent Softener Dam-board Dam-board Liquid detergent Powder detergent Pull out the dispenser Caution! • Detergent only need to be added in "case I “after selecting pre-washing for machines with this function. Programme Programme Spin Only Cotton Eco 40 °C Cotton Eco 60 °C... -
Page 15: Control Panel
OPERATIONS Control Panel Spin Delay Speed Drum Clean Note! • The chart is for reference only, Please refer to real product as standard. Start/Pause Product is switched off. Press the button to start or pause the washing cycle. Programmes Option Available according to the laundry type. - Page 16 O P E R A T I O N S Option Ext ra Rinse: The laundry w ill u ndergo ext ra rinse once aft er you select i t . Delay: Delay f unct ion can b e set wit h t his but t on, t he delaying t ime is 0-24H. Spin Speed: It c an b e set the spin speed t o p ress the but t on r epeat edly 10 15...
-
Page 17: Other Functions
O P E R A T I O N S Programme O ption Programme Option xtra Rinse xtra Rinse Drain Only Cotton Eco 40 °C Cotton Eco 60 °C Rinse&Spin Cotton Delicate 30 °C Delicate Cotton 20 °C M ix 60 °C Cotton 30 °C M ix 40 °C Cotton 40 °C... - Page 18 O P E R A T I O N S Child Lock To avoid mis operation by children. Spin Ext ra speed Rinse Start Press [ Ext ra Rinse] and Choose the Programme [ Spin Speed] 3 sec. t ill buzzer beep. Caut ion! •...
-
Page 19: Programmes
O P E R A T I O N S Programmes Programmes are available according t o t he laundry t ype. Programmes Cotton/ Normal Hard-w earing textiles, heat-resistant textiles made of cotton or linen. Synthetic Wash synt het ic art icles, for example: shirt s, coat s, blending. While w ashing t he knit t ing t ext iles, det ergent q uant it y shall b e reduced due t o i t s loose st ring const ruct ion and easily forming bubbles. -
Page 20: Washing Programmes Table
O P E R A T I O N S Programme Default Time Load(kg) Temp.(℃) Default 1200 3:34 Cotton Eco 40 °C 3:53 Cotton Eco 60 °C 1:35 Cold Cotton 1:19 Cotton 20 °C 1:20 Cotton 30 °C 1:40 Cotton 40 °C 1:45 Cotton 60 °C 2:40... -
Page 21: Maintenances
MAINTENANCES Cleaning And Care ！ Warning! • Before your maintenance starts, please unplug the machine and close the tap. Cleaning The Cabinet Proper maintenance on the washing machine can extend its working life. The surface can be cleaned with diluted non-abrasive neutral detergents when necessary. - Page 22 MAINTENANCES Cleaning The Inlet Filter Note! • Inlet filter must be cleaned if there is less water. Washing the filter in the tap 1.Close the tap. 2.Remove the water supply hose from the tap. 3.clean the filter. 4.Reconnect the water supply hose Washing the filter in washing machine: Screw off the inlet pipe from the backside of the machine.
- Page 23 MAINTENANCES Cleaning The Drain Pump Filter ！ Warning! • Be careful of the hot water! • Allow detergent solution to cool down. • Unplug the machine to avoid electrical shock before washing. • Drain pump filter can filter the yarns and small foreign matters from the washing.
-
Page 24: Trouble Shooting
MAINTENANCES Trouble Shooting The start of the appliance does not work or it stops during operation. First try to find a solution to the problem, If not, contact the service centre. Description Reason Solution Washing machine Restart after the door is closed Door is not closed properly cannot start up Check if the clothes is stuck... - Page 25 MAINTENANCES Description Reason Solution Restart after the door is closed Door is not closed properly Check if the clothes is stuck Check if the water pressure is Water injecting too low problem while Straighten the water pipe washing Check if the inlet valve filter is blocked Overtime water draining Check if the drain hose is blocked Water overflow...
-
Page 26: Technical Specifications
MAINTENANCES Technical Specifications Power Supply 220-240V~,50Hz MAX.Current 0.05MPa~1MPa Standard Water Pressure Washing Dimension Net Weight Rated Power Model Capacity (W*D*Hmm) 7.0kg 595*495*850 61kg 1950W(220V) FW712 10 25...
