User Manual FWF 71243W CONTENTS Safety information........2 Settings.............14 Safety instructions........4 Before first use......... 14 Product description........6 Daily use...........15 EASY START..........7 Hints and tips..........19 Programme Chart........9 Care and cleaning........20 Consumption values......... 12 Troubleshooting........23 Options............. 13 Technical Data..........26... -
Page 2: Safety Information
SAFETY INFORMATION Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible for any injuries or damages that are the result of incorrect installation or usage. Always keep the instructions in a safe and accessible location for future reference. - Page 3 SAFETY INFORMATION The appliance must be connected to the water mains using • the new supplied hose sets, or other new hose sets supplied by the Authorised Service Centre. Old hose sets must not be reused. • If the mains power supply cable is damaged, it must be •...
-
Page 4: Safety Instructions
SAFETY INSTRUCTIONS • Connect the mains plug to the mains Installation socket only at the end of the installation. • Remove all the packaging and the transit Make sure that there is access to the bolts. mains plug after the installation. •... - Page 5 SAFETY INSTRUCTIONS • Disconnect the appliance from the mains electrical and water supplies. • Cut off the mains electrical cable close to the appliance and dispose of it. • Remove the door catch to prevent children or pets from becoming trapped in the drum.
-
Page 6: Product Description
PRODUCT DESCRIPTION Appliance overview Worktop Detergent dispenser Control panel Door handle Rating plate Feet for levelling the appliance Child safety This device prevents children or pets to be closed in the drum. • Turn the device clockwise, until the groove is horizontal. You cannot close the door. -
Page 7: Easy Start
EASY START Control panel description Programme knob quick button Display rinse hold button delay start button spin reduction button door locked indicator temp button start/pause button extra rinse button Display The display shows: The indicator comes on the display when the related option is set. A. - Page 8 EASY START Refer to the chapter – You change the programme 'Troubleshooting' . while it operates. • The display shows the message for some seconds if: – You set a option that is not suitable for the programme.
-
Page 9: Programme Chart
PROGRAMME CHART MAXIMUM PROGRAMME LOAD PROGRAMME DESCRIPTION TEMPERATURE MAXIMUM (TYPE OF LOAD AND SOIL LEVEL) RANGE SPIN SPEED White cotton and coloured cotton. Normal soil cotton 7 kg 90°C - cold 1200 rpm and light soil. White cotton and fast-coloured cotton. Normal 7 kg 1200 rpm soil. - Page 10 PROGRAMME CHART MAXIMUM PROGRAMME LOAD PROGRAMME DESCRIPTION TEMPERATURE MAXIMUM (TYPE OF LOAD AND SOIL LEVEL) RANGE SPIN SPEED Items in denim and jersey. Normal soil. jeans 3 kg 60°C - cold 1200 rpm A short cycle for synthetic and delicate items with 30'@ 30°...
- Page 11 PROGRAMME CHART PROGRAMME ■ ■ ■ jeans ■ 30'@ 30° 1) When you set the quick option, we recommend that you decrease the quantity of the laundry. It is possible to keep the full load but the washing results can be unsatisfactory. Recommended load: cotton: 3,5 kg, synthetics and delicates: 1,5 kg.
-
Page 12: Consumption Values
CONSUMPTION VALUES The data in this table are approximate. Different variables can affect the data: the quantity and type of laundry, the water and ambient temperature. At the start of the programme, the display shows the programme duration for the maximum load capacity. -
Page 13: Options
OPTIONS temp door locked indicator With this option you can change the default The indicator shows when the door can temperature. be opened: • The indicator is on: the door cannot be Indicator = cold water. opened. • The indicator flashes: the door is The indicator of the set temperature comes opening in some minutes. -
Page 14: Settings
SETTINGS Child Lock With this option you can prevent that the children play with the control panel. • To activate/deactivate this option, press temp and spin at the same time until the indicator comes on/goes off. You can activate this option: •... -
Page 15: Daily Use
DAILY USE Using detergent and additives WARNING! Refer to Safety chapters. Loading the laundry Open the water tap. Connect the mains plug to the mains socket. 1. Pull the door handle to open the appliance door. 2. Put the laundry in the drum, one item at a time. - Page 16 DAILY USE Liquid or powder detergent 2. Adjust the flap in position B. 3. Put back the drawer in the recess. The default position of the flap is A (powder detergent). When you use the liquid detergent: • Do not use gelatinous or thick liquid detergents.
-
Page 17: Setting A Programme
DAILY USE Setting a programme 1. Turn the programme knob to switch the You can cancel or change the set of appliance on and set the programme: the delay start option before you press • The indicator of the button start/ the button start/pause. -
Page 18: Opening The Door
DAILY USE • The door lock indicator is on. The Opening the door indicator of button start/pause is off. The While a programme or the delay start door stays locked. operates, the appliance door is locked. The • You must drain the water to open the indicator is on. -
Page 19: Hints And Tips
HINTS AND TIPS – powder detergents for delicate The laundry load fabrics (40 °C max) and woollens, • Divide the laundry in: white, coloured, – liquid detergents, preferably for low synthetics, delicates and wool. temperature wash programmes (60 • Obey the washing instructions that are °C max) for all types of fabric, or on the laundry care labels. -
Page 20: Care And Cleaning
CARE AND CLEANING Regularly examine the seal and remove all WARNING! objects from the inner part. Refer to Safety chapters. Cleaning the detergent dispenser External cleaning Clean the appliance with soap and warm water only. Fully dry all the surfaces. CAUTION! Do not use alcohol, solvents or chemical products. -
Page 21: Frost Precautions
CARE AND CLEANING Cleaning the inlet hose and the valve filter 45° 20° Frost precautions If the appliance is installed in an area where the temperature can be less than 0 °C, remove the remaining water from the inlet hose and the drain pump. Do this procedure also when you want to do the emergency drain. - Page 22 CARE AND CLEANING WARNING! Make sure that the temperature is more than 0°C before you use the appliance again. The manufacturer is not responsible for damages caused by low temperatures.
-
Page 23: Troubleshooting
TROUBLESHOOTING • - The appliance does not fill with WARNING! water properly. Refer to Safety chapters. • - The appliance does not drain the water. Introduction • - The appliance door is open or not The appliance does not start or it stops closed correctly. - Page 24 TROUBLESHOOTING PROBLEM POSSIBLE SOLUTION • Make sure that the sink spigot is not clogged. The appliance does not • Make sure that the drain hose has no kinks or bends. drain the water. • Make sure that the connection of the drain hose is correct. •...
- Page 25 TROUBLESHOOTING PROBLEM POSSIBLE SOLUTION • Make sure that you press only the wanted button(s). You cannot set an op- tion. After the check, activate the appliance. The programme continues from the point of interruption. If the problem occurs again, contact the Authorised Service Centre.
-
Page 26: Technical Data
TECHNICAL DATA Dimension Width/ Height/ Depth/ 600 mm/ 850 mm/ 559 mm/ 578 Total depth Electrical connection Voltage 230-240 V Overall power 2200 W Fuse 13 A Frequency 50 Hz Level of protection against ingress of solid particles IPX4 and moisture ensured by the protective cover, ex- cept where the low voltage equipment has no pro- tection against moisture Water supply pressure... -
Page 27: Environmental Concerns
ENVIRONMENTAL CONCERNS dispose appliances marked with the symbol Recycle the materials with the symbol with the household waste. Return the Put the packaging in applicable containers product to your local recycling facility or to recycle it. Help protect the environment contact your municipal office.
