Quest 150 Dual
Quest Dry
Installation, Operation and Maintenance Instructions
Installation, Operation and Maintenance Instructions
– Read and Save These Instructions –
This manual is provided to acquaint you with the dehumidi-
fier so that installation, operation and maintenance can
proceed successfully. Ultimate satisfaction depends on the
quality of installation and a thorough understanding of this
equipment. The dehumidifier is built around tested engi-
neering principles and has passed a thorough inspection for
quality of workmanship and function.
Providing 150 pints of water removal per day at standard
rating conditions (80ºF/60%RH), the Quest 150 Dual will
effectively control humidity while using only 11.0 amps/115V.
Features:
•
High capacity
•
High efficiency
•
Environmentally friendly
•
Patent pending dual-air distribution
Patent Pending Dual-Air Distribution
Specifications subject to change without notice.
Water Removal Rates (Pints/Day)
150 pints
4201 Lien Rd
Madison, WI 53704
www.QuestHydro.com
1
80˚F, 60% (AHAM)
Phone 608-237-8400
Toll-Free 1-877-420-1330
info@QuestHydro.com
TS-880
01/17 Rev. D
