GENERAL DESCRIPTION

The TW-CP-R-01 call point permits the manual activation of a fire alarm. After its use, the call point can be reset with its proper key, making it
immediately ready for reactivation.
TW-CP-R-01 is battery powered and doesn't need any system cabling installation.
Device
block
Operable front
window
Reset key
Picture 1

DEPLOYMENT PROCEDURE

1) Select a location for the call point. See LOCATION SELECTION.
2) Unbox the call point from its packaging.
3) Power up the call point. See POWERING UP - FIRST TIME USE / POWERING UP - RECOVERY.
4) Link the call point to the system. See LINKING - WAKE-UP / LINKING - ONE-BY-ONE.
5) Install the back box. See FIXING THE BACK BOX.
6) Install the device block onto the back box. See DEVICE BLOCK INSTALLATION / DEINSTALLATION.
7) Test the call point. See TESTING.
8) Remove the "NOT IN USE LABEL" when the call point is in operation.

LOCATION SELECTION

Select a location for the call point that conforms to your local applicable safety standards and that is in a good position for sending / receiving
wireless signals to / from the father TW-MTI-01, TW-MEC-01 or TW-ME-01 network device.
Mount the call point as far as possible from metal objects, metal doors, metal window openings, etc. as well as cable conductors, cables
(especially from computers), otherwise the operating distance may greatly drop.
The TW-CP-R-01 must NOT be installed near electronic devices and computer equipment that can interfere with its wireless communication
quality.
ARGUS SECURITY S.R.L. - Via del Canneto, 14 - 34015 - Muggia (TS) - Italy
LED indicator
Latch release
pins
It is advisable to use the TW-SK-01 survey kit to
locate a good wireless installation location.
TW-CP-R-01
Wireless Resettable Call Point
Back box
Fixing holes
Battery A
housing
Tamper
switch
Device block
latch
Activation
release
Always remove the "NOT IN USE" label
when the call point comes in operation.
www.argussecurity.it
1
Link program
switch
Battery B
housing

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Taurus TW-CP-R-01 and is the answer not in the manual?

Questions and answers

Related Manuals for Argus Security Taurus TW-CP-R-01

Summary of Contents for Argus Security Taurus TW-CP-R-01

  • Page 1 (especially from computers), otherwise the operating distance may greatly drop. The TW-CP-R-01 must NOT be installed near electronic devices and computer equipment that can interfere with its wireless communication quality. ARGUS SECURITY S.R.L. - Via del Canneto, 14 - 34015 - Muggia (TS) - Italy www.argussecurity.it...
  • Page 2 LED INDICATOR STATUS MESSAGES Please mind that LED signalling burns out battery power, therefore reducing batteries The LED indicator communicates to the final user the status of the TW-CP-R-01. lifespan. Device status LEDs indication Power up (DIP on “ON”) Blinks red 4 times Power up (DIP opposite “ON”) Blinks green 4 times Entering wake-up mode...
  • Page 3 1) Insert the reset key into the activation release hole. 2) Turn the key clockwise until you hear a snap sound. Picture 4 Picture 5 ARGUS SECURITY S.R.L. - Via del Canneto, 14 - 34015 - Muggia (TS) - Italy www.argussecurity.it...
  • Page 4 Refer to and follow national codes of practice and other internationally recognized fire engineering standards. Appropriate risk assessment should be carried out initially to determine correct design criteria and updat- ARGUS SECURITY S.R.L. ed periodically. Via del Canneto, 14...
