Summary of Contents for ID Lock 202 MULTI
- Page 1 INSTALLATION MANUAL INSTALLATION MANUAL INSTALLATION FILM...
-
Page 2: Parts List
ID Lock 202 Multi Installation manual Figure 1 – Contents Parts list Allen wrench Outside handle Inside handle Strike plate Strike plate adapter Outside unit Inside backplate Inside unit Battery cover Thumb turn protective cover Cuttable screws Mortise lock Inside unit screws... -
Page 3: Table Of Contents
ID Lock 202 Multi Installation manual Table of contents Parts list ....................................1 Introduction ..................................3 Terms and conditions ..............................3 Precautions ..................................3 Preparations ..................................4 Latch and mortise lock ..............................4 Mounting ..................................... 4 Remove your old lock ..............................4 Mounting the strike plate ............................ -
Page 4: Introduction
ID Lock 202 Multi must be used with Alkaline batteries only. Use 4 or 8 batteries of the same brand. Replace all batteries at the same time. ID Lock 202 Multi is rated 6 VDC. Replacement of a battery with an incorrect type can defeat a safeguard. -
Page 5: Preparations
ID Lock 202 Multi Installation manual Preparations Latch and mortise lock Use a screw driver to adjust the latch on the mortise lock so it is in the same direction as the one you removed from your door. The adjustment is shown in figure 2. -
Page 6: Assembly Of Mortise Lock And Outside Unit
ID Lock 202 Multi Installation manual Assembly of mortise lock and outside unit Insert the mortise lock halfway into the door. Gently pull the cable towards the inside through the topmost opening (see figure 4). Figure 4 – Mortise lock placement The cable from the outside unit is gently pulled towards the inside and on the top side of the mortise lock. -
Page 7: Mounting The Backplate And Inside Unit
ID Lock 202 Multi Installation manual Mounting the backplate and inside unit Inside backplate The back plate is fitted to the outside unit as shown in figure 8. The 4 cutting screws are cut to the correct thickness according to the thickness of the door. Use medium-sized pliers or a hacksaw to cut the screws. -
Page 8: Door Handle
ID Lock 202 Multi Installation manual Door handle Outside door handle The outside unit has a square pin attached. The door handle is inserted through the outside unit, through the mortise lock, and the inside unit. Figure 12 – Attach outside handle Inside door handle Your inside door handle can now be attached. -
Page 9: Mechanical Function Test
ID Lock 202 Multi Installation manual Mechanical function test Perform a functional test of the moving parts of the lock with the door open. Do both door handles move when using the outside and inside handle? b. Does the dead bolt slide in and out without friction whilst using the thumb turn knob? -
Page 10: Configuration
ID Lock 202 Multi Installation manual Configuration Important Make sure you an alternate entrance or someone on the inside when configuring your lock. Alternatively, the door can always be left open while you test and you can "simulate" the door closes by holding down the sensor latch (see figure 16 on the previous page). -
Page 11: Setup And Pin Codes
ID Lock 202 Multi Installation manual Setup and PIN codes Set Master PIN After the batteries have been inserted and the lock has started up, a Master PIN must be programmed, this is done as follows: Activate the outside unit by waking the panel (the door must be open and unlocked) - Page 12 ID Lock 202 Multi Installation manual 2022-11-30...
-
Page 13: Factory Reset
Daily use How to lock There are two different locking modes on ID Lock 202 Multi: Automatic locking mode When automatic locking mode is activated (as it is with factory settings), the lock will simply lock itself 3 seconds after the door is closed. - Page 14 ID Lock 202 Multi Installation manual Figure overview Figure 1 – Contents ..........................1 Figure 2 – Adjusting the latch......................4 Figure 3 – Mounting the strike plate ....................4 Figure 4 – Mortise lock placement ...................... 5 Figure 5 – Handle and outside unit ..................... 5 Figure 6 –...
-
Page 15: Definitions
ID Lock will lock automatically when you close the door (3 seconds delay). Relock: ID Lock will relock if the door is not opened within 15 seconds after unlocking. Manual locking: When automatic locking is deactivated, you need to manually lock your door with the key button or by activating the touch panel. - Page 16 ID Lock 202 Multi Installation manual 2022-11-30...
