ID Lock 202 Multi User Manual

ID Lock 202 Multi
Z-Wave Module (FW 1.6)
English User Manual
1: Place the module in the tray (A) «Remote
Module» when batteries are removed.
•
Open the door
•
Remove batteries from the lock
•
Place the module in the tray for "Remote
Control" (see illustration 1)
•
Insert batteries
•
Activate "Add node" in the gateway app
Follow the instructions in the gateway manual
•
Hold key button (3 secs) to activate panel
•
Enter [Master PIN], followed by [*]
o Master PIN is created upon setup
•
Enter digit [9], followed by [*]
•
Enter digit [1]
•
Open the door
•
Activate "Remove node" in the gateway app
Follow the instructions for your gateway
•
Hold key button (3 secs) to activate panel
•
Enter [Master PIN], followed by [*]
o Master PIN is created upon setup
•
Enter digit [9], followed by [*]
•
Enter digit [1]
Reset the module (Z-Wave Local Reset)
•
Open the door
•
Hold key button (3 secs) to activate panel
•
Enter [Master PIN], followed by [*]
o Master PIN is created upon setup
•
Enter digit [9], followed by [*]
•
Enter digit [0]
NB! If the module resets while it is included with a
gateway, the door lock will factory reset. To prevent
this, remove (exclude) the lock first (see: "Remove
the lock").
Technical specs for the Z-Wave module is listed on the
next page.
Correct communication mode is activated when
batteries are inserted (v1.6 only).
The batteries must be removed before the Z-Wave
Module is inserted or removed. Failing to do so can
cause damage on the module and/or the lock.
idlock.no/zwave
Adding the lock (Inclusion)
Remove the lock (Exclusion)
Technical details
Warning!
