INTRODUCTION
Thank you for choosing this De'Longhi product. Please take a few
minutes to read these instructions. This will prevent running any
risks or damaging the appliance.
DESCRIPTION
Description of the appliance (see page 2 - A)
A1 Air outlet grille
A2 Control panel
A3 Handles
A4 Wheels
A5 Filter
A6 Air intake grille
A7 Air exhaust hose housing
A8 Air intake grille
A9 Power supply cable
A10 Upper drainage hose with cap
A11 Lower drainage hose with cap
A12 Remote control signal receiver
A13 Remote control compartment
Description of accessories (See page 2 - B
B1 Air exhaust hose
B2 Hose adapter
B3 Adapter for extendable window bracket/window
B4 Extendable window bracket and locking pin
B5 Drainage tube
B6 Self adhesive strip foam
B7 Remote control
ELECTRICAL CONNECTION
Before plugging into the mains, check the following:
• the mains voltage is the same as that indicated on the plate
on the back of the appliance;
• the socket and electrical line are sized to support the load
required;
• the socket is the proper type for the plug, otherwise, re-
place the socket;
• the socket is connected to an efficient earthing system. The
manufacturer is not responsible in the event of non-com-
pliance with these injury prevention standards.
• The power cable must only be replaced by special-
ised technicians.
USE
The instructions below will enable you to prepare your air con-
ditioner for operation as efficiently as possible. Before use, make
sure the air intake and outlet grilles are unobstructed.
Maintain a minimum distance of 60 cm from walls and obsta-
cles. (Fig. 7).
In conditioning and dehumidification the air exhaust hose (B1)
must be applied (Fig. 1).
Please note: This appliance is provided with an auto-evapora-
tion feature for condensate removal during cooling and dehu-
midifying mode.
AIR CONDITIONING WITHOUT INSTALLATION
CASEMENT WINDOW
If you have a casement window proceed as follows:
• Fit the air exhaust hose (B1) in the relevant housing located
on the rear side of the appliance (Fig. 1).
• Position the air exhaust hose (B1) with the window adapter
(B3) outside the window to let the hot air out (Fig. 2).
)
DOUBLE-HUNG WINDOW
Depending on the need, place the self adhesive strip foam on the
window as shown in figure 3.
• Cut the adhesive strip foam to the desired length and place
it on the window.
• Position the extendable window bracket on the window sill
and fully extend the extendable window bracket inside the
window frame (Fig.4)
• Adjust the extendable window bracket by fixing the length
with two locking pin (Fig. 5) (If the extendable window
bracket is too large, it is possible to cut the plastic using a
saw. This operation must be carried out by a qualified pro-
fessional).
• Hook the adapter for extendable window (B3) to the win-
dow bracket as shown in Fig. 6.
