- Page 1 User Manual BC182 Series Version: CH-V0.3...
-
Page 2: Table Of Contents
Shenzhen Digitech Co., Ltd. BC182 Manual Table of contents ◼ Appearance and Size ..................3 ⚫ Size Specification .................. 3 ◼ Features Introduction .................. 4 ⚫ Features & Parameters ................4 ⚫ Button Description .................. 4 ◼ Operation ....................5 ⚫... -
Page 3: Appearance And Size
Shenzhen Digitech Co., Ltd. BC182 Manual ◼ Appearance and Size Display Appearance Drawing ⚫ Size Specification Display Size Specification Shenzhen Digitech Co., Ltd. www.riding-evolved.com... -
Page 4: Features Introduction
Shenzhen Digitech Co., Ltd. BC182 Manual ◼ Features Introduction ⚫ Features & Parameters BC182 offers display function about common cycling data and statistical result, as well as some practical functions. ◆ Current Speed, Max Speed, Average Speed ◆ Current Motor Power ◆... -
Page 5: Operation
Shenzhen Digitech Co., Ltd. BC182 Manual ◼ Operation ⚫ Power on/off Under power off status, long press 【Power】 to enter logo interface with power-on interface after 1s and cycling interface after 2s. In any working interfaces, long press 【Power】to switch off. -
Page 6: Gears Shift
Shenzhen Digitech Co., Ltd. BC182 Manual ⚫ Gears Shifts Click on 【+】/【-】button to shift gears; Long press 【-】for 2S to start 6km/h push assist mode and release 【-】to exit push assist mode. ⚫ Turn on/off lights Long press【+】for 2s to turn on/off the lights during E-bike is running. -
Page 7: User Menu
Shenzhen Digitech Co., Ltd. BC182 Manual Common Error Codes (the error codes are related with E-bike’s fitting part (please refer to the information below): KM5S Protocol Error Code Error Code Meanning (hexadecimal) Overcurrent Error Throttle Hall Error Motor Phase Error... - Page 8 Shenzhen Digitech Co., Ltd. BC182 Manual 2、 Backlight Brightness setting Selecting menu “Brightness”, click on 【+】/【-】to shift brightness setting, the adjustment range is Auto 1-5. Clicking on 【Power】 to confirm and save, then shift to “OK” interface, it returns to setting menu automatically after 2s standstill.
-
Page 9: Ota Upgrade (Bluetooth Version Only)
Shenzhen Digitech Co., Ltd. BC182 Manual User can search and connect by APP. After operation is finished successfully, the icon “Bluetooth” stops flickering but lights constantly. After downloading APP and registering, user need scan the QR code on Bickwise Pro, the Bikewise pro download link is below: ⚫... -
Page 10: Advanced Menu
Shenzhen Digitech Co., Ltd. BC182 Manual ◼ Advanced Menu BC182 provides advanced menu for E-bike manufacturer, which could adjust the E-bike configuration and the following parameters: ◆ Wheel Diameter ◆ Battery Voltage ◆ Speed Sensor ⚫ Enter Advanced Menu When the display is in a shutdown status, long press 【Power】 for 6s, it runs and the advanced menu interface displays Click on 【+】/【-】to adjust flickering parts and click on 【Power】to change flickering part... -
Page 11: Power Voltage
Shenzhen Digitech Co., Ltd. BC182 Manual ⚫ Power Voltage Select menu “Battery Voltage”, click on 【+】 / 【-】 to shift battery voltage (in volt), the range: 36V/48V/52V, click on 【Power】to confirm and save, then switch to next interface. ⚫ Exit 1. -
Page 12: Attentions
Shenzhen Digitech Co., Ltd. BC182 Manual ◼ Attentions 1. Please make sure to turn off the power before the device is connected, otherwise it causes device damaged permanently; 2. Please make sure to fix the inner hexagon screws with maximum torsion value less than 1Nm, otherwise it causes device damaged;...
