Important Safety Instructions

1.
Please read these instructions thoroughly.
2.
Please keep this guide for future use.
3.
Please disconnect the device from the main supply before cleaning. Do not use any liquid or
aerosol spray cleaners. The best for cleaning is a piece of cloth dampened with water.
4.
To avoid damage of the device, you should only use accessory parts permitted by the
manufacturer.
5.
The device must be protected against moisture.
6.
To setup the device, it must be put in a stable stand position. Tipping it over or dropping it may
cause injuries. Only use safety setup locations and follow the setup instructions of the
manufacturer.
7.
The ventilation openings are used for air circulation which protect the device against
overheating.
8.
To connect the device, follow the connected load values of the main supply.
9.
Due to electrical safety, the wall socket must be equipped with a non-fused earthed conductor
contact.
10. The power cable must be laid in a way that nobody may trip over it. There should also nothing
be resting on the cable.
11. All instructions and warning remarks on the device must be followed.
12. If the device will not be used for a long period of time, you should disconnect it from the main
supply to avoid overvoltage damage.
13. Any objects or liquid should never enter the device via its openings for air circulation. This
could cause a fire or an electric shock.
14. Do not open the device ever. For electrical safety, the device shall be opened by authorized
technical service personnel only.
15. If following conditions occur, the device must be disconnected from the main supply, and it
must be checked by a qualified service center:
a-
Power cable or power plug are damaged;
b-
Liquid has entered the device;
c-
The device was exposed to moisture;
d-
The device does not operate according to the user's guide, or you do not achieve any
improvement with the aid of this guide;
e-
The device has dropped and/or the casing is damaged;
f-
The device shows obvious signs of a defect.
16. For repair, only original spare parts or parts in accordance with the original parts may be used.
Use of unsuitable spare parts can cause more damage.
17. Please turn to your service center for all questions concerning service and repair to guarantee the
device's performance reliability.
18. The socket outlet must be installed near the equipment to be easily accessible.
— i —

Advertisement

Table of Contents
loading

Summary of Contents for Sceptre D40

  • Page 1: Important Safety Instructions

    Important Safety Instructions Please read these instructions thoroughly. Please keep this guide for future use. Please disconnect the device from the main supply before cleaning. Do not use any liquid or aerosol spray cleaners. The best for cleaning is a piece of cloth dampened with water. To avoid damage of the device, you should only use accessory parts permitted by the manufacturer.
  • Page 2: Federal Communications Commission

    FEDERAL COMMUNICATIONS COMMISSION (FCC STATEMENT) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 3: Table Of Contents

    Table of Contents Chapter 1 _________________________________________ 1 Introduction _____________________________________________ 1 Unpacking __________________________________________ 1 Connecting the Monitor and Stand________________________ 2 Choosing a Workstation________________________________ 2 The AC Connection ___________________________________ 3 The Signal Cable Connection____________________________ 4 Monitor Adjustments __________________________________ 5 Chapter 2 _________________________________________ 6...
  • Page 5: Chapter 1

    Introduction Congratulations on your purchase of the new high performance 15" Monitor. Much consideration has gone into the design of the monitor in order to meet your requirements for full compatibility and versatility as well as quality. Using state-of-the-art electronics, the monitor can support a resolution of 1280x1024, and the on-screen display allows you to customize the display settings to suit your individual needs.
  • Page 6: Connecting The Monitor And Stand

    Connecting the Monitor and Stand Connecting the Monitor and Stand Align the stand’s four tabs with the slots on the bottom of the monitor. Insert the tabs into the slots. Slide the stand towards the front of the monitor. Figure 1: Monitor and Stand Connection...
  • Page 7: The Ac Connection

    The AC Connection The AC Connection Locate the AC port on the rear of the monitor. Plug the female end of the AC cord into the AC port. Plug the male end into the power supply. Figure 3: Connecting the Power Cord...
  • Page 8: The Signal Cable Connection

    The Signal Cable Connection The Signal Cable Connection Locate the ON/OFF power switch. See Figure 4. Make sure that the Monitor power switch is in the OFF position. The OFF position is indicated with a circular icon. Figure 4: ON/OFF Power Switch Locate the VGA port on the rear of the PC.
  • Page 9: Monitor Adjustments

    The monitor is capable of both tilt and swivel adjustments. Figure 5: Tilt Adjustment With the tilt feature, the monitor is capable of vertical adjustments of +15 to -5 . The swivel feature allows for horizontal monitor adjustments of +45 to -45 .
  • Page 10: Chapter 2

    VERTICAL HEIGHT CONTROL PINCUSHION CONTROL TRAPEZOID CONTROL A recall function shall be present on the monitor to recall the factory preset. All this functions as shown in the drawing below: When the highest or lowest possible setting for a particular display control has been reached, its corresponding LED will flash.
  • Page 11: Icon Descriptions

    Icon Descriptions Icon Description Contrast: This control allows you to adjust the display contrast level to accommodate the ambient lighting conditions of your working environment. Brightness: This control allows you to fine tune the display brightness level. H-Width: This control allows you to stretch or squeeze the display area horizontally.
  • Page 12: Troubleshooting

    Troubleshooting This section will try to anticipate potential problems that you may encounter in the day-to-day use of your monitor. Included in this section is information which should help solve these problems for you. If after trying the suggested solutions, your monitor’s symptom remains the same, contact your authorized service center.
  • Page 13: Caring For Your Monitor

    Avoid excessive dampening. Clean the screen with slightly damp rag Ventilation slots The ventilation slots allow air to flow through the Monitor. They protect the unit from overheating. Therefore, do not cover or obstruct the ventilation slots. Likewise, do not place the Monitor on or near a heater.
