Pna-3001/2/3 Vma Ext - GAGEMAKER PN-3000 Series Operation Manual

Pin Nose Gages and Seal Gage Operation Manual
7
6
5
Item Description
1 Dial Indicator (#803)
2 Upper Anvil (Factory Installed) 1
3 Lower Anvil
4 Slider Block
5 Slider Knob
6 Slider Spacer
7 T-Nut
8 End Cap
PNA-3001-VMA 30° External Apex Diameter Gage, Anvils 2 3/8" - 5 1/2"
PNA-3002-VMA 30° External Apex Diameter Gage, Anvils 6" - 9 5/8"
PNA-3003-VMA 30° External Apex Diameter Gage, Anvils 10" - 13 3/8"
PNA-3001/2/3 -VMA Ext.
System Components
4
2
3
Qty
1
1
1
1
1
1
1
8
1
HOW TO ORDER
1. Select the PNA-3001 Ext. Series gages
model, based on the size of the connector.
8
