Pin Nose Gages and Seal Gage Operation Manual
PNI-3001/2/3 Int.
Setup Procedures
The round and frame style
setting
standards
are
designed to preset all
models of the PN-3000
Series gages for accurate
inspection of API pin end
seal
and
seal
taper
diameters
of
premium
connectors.
These
standards consist of a rigid,
non-adjustable steel block
precision
machined
to
proper size to tolerances of
Sweep Gage to
±.0003".
Locate Largest Indicator
Reading
