PACKING LIST

1 - StoneVac for Additive Manufacturing
1 - Plastic Disposal Bag
1 - Power Cord
1 - Interface Cable
1 - Large Accumulator
1 - 2.5" x 6' Hose

IMPORTANT SERVICE INFORMATION:

SAVE SHIPPING BOX AND FOAM FOR FUTURE
SERVICE. SHIPPING WITHOUT PROPER FOAM
MAY CAUSE DAMAGE TO UNIT

INSTRUCTIONS

1.
Remove the unit and other parts from the box and check against the packing list. Remove the hose
and power cord from inside the dust bin as well as any protective paper packing material.
2.
Plug one end of the power cord into the back of the StoneVac and the other end into a designated
15 AMP circuit. Turn on the StoneVac by flipping the main power switch on the back of the Unit into
the ON position. Once the switch is in the ON position, the red LED indicator on the front of the unit
will illuminate.
3.
The 2.5" vacuum hose supplied slips onto the vacuum connection in the back of the unit and the
other end connects to the top of the Large Accumulator. The 1.5" vacuum hose connects from the
Large Accumulator's inlet arm to the collection point in your post-processing area. The ideal location
for the StoneVac is near the post-processing area. Hose extensions and adaptors are available from
your dealer. We recommend, however, that you try to keep the total length of hose less than 6 feet
between the StoneVac and the dust collection point; longer hose will reduce suction.
25799 Jefferson Ave.
Murrieta, CA 92562
1-800-VANIMAN (826-4626)
STONEVAC AM
www.vaniman.com
sales@vaniman.com
120V
Fig. 1
SV-AM-07/23 Page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the STONEVAC AM and is the answer not in the manual?

Questions and answers

Summary of Contents for Vaniman STONEVAC AM

  • Page 1 STONEVAC AM 120V PACKING LIST 1 - StoneVac for Additive Manufacturing 1 - Plastic Disposal Bag 1 - Power Cord 1 - Interface Cable 1 - Large Accumulator 1 - 2.5" x 6’ Hose IMPORTANT SERVICE INFORMATION: SAVE SHIPPING BOX AND FOAM FOR FUTURE SERVICE.
  • Page 2 Pull the edges of the bag together to close the bag for disposal. Replace the bag with a Vaniman replacement and carefully slide the dust bin back into the unit. Replacement bag re-order number P/N 97002 (pack of 12).
  • Page 3 Accumulator. Fasten to a wall or other vertical surface before sliding the Accumulator back into the clamp and tightening. The Accumulator can also be mounted to the side of Vaniman Dust Collectors by screwing the Bracket into the two mounting holes on the Dust Collector Case opposite the exhaust.
  • Page 4 120V ACCUMULATOR HOSE CONNECTION: The Inlet and Outlet of the Accumulator are designed to recieve Vaniman's 2.5" hose or 1.5" hose with Vaniman's reducing adapter. The Accumulator is installed between the workstation and the Dust Collector. Connect the hose from the Dust Collector to the Outlet on top of the Accumulator by gently sliding the hose end into the Accumulator until snug.
  • Page 5 120V REPLACEMENT PARTS The following items are offered to enhance the usage of your quality Vaniman unit. These items can be order through your supplier using the following part numbers. Please feel free to contact Vaniman Mfg. Co. with questions regarding our products.
