- Page 1 Outdoor Zoom Dome Hardware Manual Z83, Z84, Z810 Ver. 2022/04/7...
-
Page 2: Table Of Contents
Step 8: Close the Dome Cover ............20 Other Cable Connections How to Connect a Power Adapter (Optional) ....... 21 How to Connect DI/DO Device (Optional for Z810 only) ....22 How to Connect Audio Input /Output Device (Optional for Z810 only) ...................... 24... - Page 3 Hardware Manual Accessing the Camera Configure the IP Addresses ............30 Using DHCP Server to Assign IP Addresses ........ 30 Using the Default Camera IP Address .......... 31 Access the Camera ................. 33 www.acti.com...
-
Page 4: Precautions
Every reasonable care has been taken during the writing of this manual. Please inform your local office if you find any inaccuracies or omissions. We cannot be held responsible for any typographical or technical errors and reserve the right to make changes to the product and manuals without prior notice. www.acti.com... - Page 5 The product this manual refers to is covered by the Waste Electrical & Electronic Equipment (WEEE) Directive and must be disposed of in a responsible manner. Battery Directive-2013/56/EC Battery in the product complies with the European Battery Directive 2013/56/EC.For proper recycling,return the battery to your supplier or to a designated collection point. www.acti.com...
-
Page 6: Safety Instructions
Never look at the transmit laser while the power is on. Never look directly at the fiber ports and the fiber cable ends when they are powered on. Use of controls or adjustments to the performance or procedures other than those specified herein may result in hazardous laser emissions. www.acti.com... -
Page 7: Introduction
2MP Outdoor Zoom Dome with D/N, Adaptive IR, Superior WDR, SLLS, 4.3x Zoom lens 4MP Outdoor Zoom Dome with D/N, Adaptive IR, Superior WDR, SLLS, 4.3x Zoom lens 8MP Outdoor Dome with D/N, Adaptive IR, Superior WDR, SLLS, Z810 4.3x Zoom lens www.acti.com... -
Page 8: Package Contents
When the camera is taken out from the box, the lens cover is covered by a thin film. DO NOT remove this film. It is used to protect the lens cover from scratches or fingerprint marks which may happen during installation. Remove this film only after the camera is securely installed and all connections are complete. www.acti.com... -
Page 9: Physical Description
Restores the camera to its factory default settings. To reset the camera, use a pin to press and hold the Reset Button for about 15 seconds. Insert a memory card into this slot for local recording purposes. Memory Card Slot www.acti.com... -
Page 10: Z810
Hardware Manual Z810 Item Description DC 12V Power Input In case the camera is connected to a non-PoE (Power over Ethernet) switch, use this connector to connect the camera to an external power adapter (not included). See How to Connect a Power Adapter (Optional) on page 21 for more information. -
Page 11: Mounting Options
(optional accessory set) is required for this type of installation. NOTE: For more information about the mounting solutions and accessories, please check the Mounting Accessory Selector in our website (http://www.acti.com/mountingselector). The above mounting accessories are not included in the package. Contact your sales agents to purchase. www.acti.com... -
Page 12: Installation Procedures
It is also recommended to use the optional Junction Box to house the camera cable. Paste the drill tem cables through th 6.5mm drill bit to guide holes accor Knock the plastic guide holes and e are tightened up www.acti.com... - Page 13 5. If a memory card will be used for local recording, insert the card into the slot, at this point, with its metal contacts card facing the lens. Push the card until it clicks into place. www.acti.com...
-
Page 14: Step 2: Route The Cables
You may use a 3/4 NPS conduit gland (not bundled, contact Sales to purchase) with a flexible conduit to enclose the cables, and then screw the gland on the side cable hole. www.acti.com... -
Page 15: Step 3: Mount The Camera
1. Mount the camera to the surface using the three (2) bundled screws. 2. Pan and adjust the camera tilt angle, as needed. Rotate horizontally to pan the camera Loosen the screw to tilt the camera lens Rotate horizontally to rotate the lens viewing angle www.acti.com... -
Page 16: Step 4: Connect And Manage The Cables
19 for more details. DISCLAIMER: ACTi will not be responsible for camera damage caused by water entering the cable connections. Using the Cable Gland This section describes how to waterproof the cable-out or “pigtail” of the camera using the bundled cable gland. - Page 17 Hardware Manual 3. Insert the clamping nut into the Ethernet cable. 4. Insert the sealing insert through the Ethernet cable. 5. Insert the cable through the gland body. 6. Push the sealing insert into the gland body. www.acti.com...
- Page 18 8. Attach the gland body to the camera connector. 9. Attach the clamping nut to the gland body to complete the cable solution. NOTE: Make sure the clamping nut is tightly attached to the cable gland body and the sealing insert is squeezed tightly. www.acti.com...
-
Page 19: Using A Power Adapter (Optional)
Power Cable PoE Switch Ethernet Cable AC Power (Data + Power) Source Camera Step 6: Access the Camera Live View Accessing the Camera on page 30 for more information on how to access the Live View of the camera. www.acti.com... -
Page 20: Step 7: Adjust The Viewing Angle And Orientation
Hardware Manual Step 7: Adjust the Viewing Angle and Orientation Rotate horizontally to pan the camera Loosen the screw to tilt the camera lens Rotate horizontally to rotate the lens viewing angle Step 8: Close the Dome Cover www.acti.com... -
Page 21: Other Cable Connections
In case of using a non-PoE switch or your PoE switch has limited power supply, you can purchase a power adapter and directly connect the camera to a power outlet. After connecting the power adapter, make sure to protect the cable connection. NOTE: The power adapter is not bundled in the package. www.acti.com... -
Page 22: How To Connect Di/Do Device (Optional For Z810 Only)
Hardware Manual How to Connect DI/DO Device (Optional for Z810 only) Depending on your surveillance needs, you may connect one digital input and one digital output device to your camera. Digital Input (DI) devices can be used to notify the camera about an activity in the camera site. DI can be triggers of events. - Page 23 NOTE: For more information on DI/DO connections, please refer to the Knowledge Base article All About Digital Input and Digital Output downloadable from the link below (http://Download.acti.com?id=516). www.acti.com...
-
Page 24: How To Connect Audio Input /Output Device (Optional For Z810 Only)
DISCLAIMER: ACTi will not be responsible for camera damage due to water leakage caused by improper waterproofing of cables. www.acti.com... -
Page 25: Accessing The Camera
The IP Utility can be downloaded for free from http://www.acti.com/IP_Utility With just one click, you can launch the IP Utility and there will be an instant report as follows: You can quickly see the camera model in the list. Double-click on the IP address to automatically launch the default browser of the PC with the IP address of the target camera filled in the address bar of the browser already. -
Page 26: Using The Default Camera Ip Address
PC has to be configured to match the network segment of the camera. Manually adjust the IP address of the PC: In the following example, based on Windows 7, we will configure the IP address to 192.168.0.99 and set Subnet Mask to 255.255.255.0 by using the steps below: www.acti.com... - Page 27 In such case, please plug in only one camera at a time, and change its IP address by using the Web browser before plugging in the next one. This way, the Web browser will not be confused about two devices having the same IP address at the same time. www.acti.com...
-
Page 28: Access The Camera
Upon successful connection to the camera, the user interface called Web Configurator would appear together with the login page. The HTTP port number was not added behind the IP address since the default HTTP port of the camera is 80, which can be omitted from the address for convenience. www.acti.com... - Page 29 Hardware Manual Before logging in, you need to setup the root Account and Password of the camera. Then use this newly setup Account and Password to login to the Web Configurator. www.acti.com...
- Page 30 Copyright © 2020, ACTi Corporation All Rights Reserved 7F, No. 1, Alley 20, Lane 407, Sec. 2, Ti-Ding Blvd., Neihu District, Taipei, Taiwan 114, R.O.C. TEL : +886-2-2656-2588 FAX : +886-2-2656-2599 Email: sales@acti.com...
