- Page 1 R A M B L A S P O R T R A M B L A S P O R T L A D Y 2 8 ” U S E R M A N U A L R A M B L A S P O R T M A N 2 8 ”...
-
Page 2: Table Of Contents
I N D E X 1. FOREWARD 4.9.5 Gender 1.1 Generalities 4.10 Error code 1.2 Assistance 4.10.1 Resolution of the problems 1.3 Graphical form of safety events 4.11 Battery 4.11.1 State of battery loading 2. SECURITY WARNINGS 4.11.2 Removal/Installation battery 2.1 General security warnings 4.11.3 Loading battery 2.2 Liability... - Page 3 12. WARRANTY STANDARDS 13. CONFORMITY...
-
Page 4: Foreward
1.FOREWARD 1.1 Generalities This manual is an integral and essential part of the RAMBLA SPORT model pedal assisted bicycle. Before commissioning, users must read, understand and scrupulously follow the instructions below. The manufacturer is not liable for damage caused to people and/or things or to the pedal assisted bicycle if it is used incorrectly in compliance with the instructions indicated. -
Page 5: Security Warnings
2. SECURITY WARNINGS USE OF THE PEDAL ASSISTED BICYCLE RISKS ASSOCIATED WITH THE USE OF THE PEDAL Each user must have first read the instruction manual, ASSISTED BICYCLE especially the chapter on the related instructions the • Despite the application of the safety devices, for safe use security. -
Page 6: Warnings For The Users
2.3 Warnings for the users 1. It can only be used by experienced adults and children; 2. Do not take alcohol or drugs before riding the pedal assisted bicycle; 3. These pedal assisted bicycle models are designed and built to be used outdoors, on roads and in private and public environments; 4. -
Page 7: Unpacking And Setting Up
3. UNPACKING AND SETTING UP The pedal assisted bicycle is delivered fully assembled and functional. Before each use, the driver must check the safety status of the pedal assisted bicycle. It is strictly forbidden to use the bicycle without having correctly fixed all the parts and used the adjustments to assume a comfortable and safe riding position. -
Page 8: Handlebar Adjustement
3.2 Handlebar adjustement For a comfortable posture on the bike, which does not cause neck or back pain, we recommend the handlebar stem height and handlebar bend rotation adjustments. To adjust the height of the handlebar column, remove the rubber protection plug (Ref. C – Fig. 2) and loosen the expander screw underneath, without removing it completely, using the suitable Allen key. -
Page 9: Brakes Adjustement
3.3 Brakes adjustement The brake levers (Ref. F – Fig. 4) are located on the handlebar near the grips. These systems allow the braking system to be activated by controlling the disc brake calipers located near the wheel hubs. The braking action is proportional to the force applied to the levers. -
Page 10: Pedal Assembly
3.4 Pedals assembly Right pedal: identified by the letter “R” marked on its pin. To fit the pedal, screw it in by turning the pin clockwise (Fig. 5). Left pedal: identified by the letter “L” marked on its pin. To fit the pedal, screw it in by turning the pin anticlockwise (Fig. 5). FIG. -
Page 11: Battery Charging
3.5 Battery charging Before using the bicycle for the first time, the battery must be charged for at least 8 hours, using the battery charger supplied. The RAMBLA SPORT model pedal assisted bicycle is equipped with an electric motor powered by a 36V lithium-ion battery. The battery pack is positioned inside the frame in the oblique tube of the vehicle. -
Page 12: Suspensions Adjustement
3.7 Suspensions adjustement At this point, adjust the suspension to make using the pedal assisted bicycle more comfortable. Depending on the route and the load on the vehicle, it is possible to vary the stiffness of the fork using a special lever located on the left side of the fork (Ref. -
Page 13: Description Of The Bicycle
4. DESCRIPTION OF THE BICYCLE 4.1 General description The pedal assisted bicycle is designed and built to be used outdoors, on roads and in private or public environments. In particular, the components and the type of pedal assisted bicycle allow you to tackle routes with asphalt surfaces or with similar characteristics without particular roughness. -
Page 14: Data Sheet
4.2 Scheda tecnica 1. HANDLEBAR AND CONTROLS 2. MOTOR 3. SADDLE 4. BATTERY 5. PEDALS 6. FORK 7. HEADLIGHT 8. TAILLIGHT 9. SHIFTER CODE E801U/ E801D FRAME HYDROFORMED ALUMINUM FORK RIGID CUSHIONED CRANKSET SHIFTER SHIMANO ACERA M2360 SHIFTER COMMAND 7 SPEEDS BRAKES Shimano Mt200 hydraulic DiSCKS... -
Page 15: Speed Change
4.4 Speed change The pedal assisted bicycle has a 7-speed gearbox integrated into the rear wheel hub. The gears can be selected by turning the lever positioned on the right handlebar grip. The indicator (Ref. K - Fig. 8) allows you to view the selected ratio. FIG. -
Page 16: Power On/Off Of The System
button short pressure/ < 1 second long pressure / > 2 seconds Allows you to: Allows you to: scroll in the Home from one main turn the display on and off; from (N) POWER screen to another; scroll between the Menu and Advanced section, the Home and the Menu;... -
Page 17: Graphical Interface Of Displays
4.6 Graphical interface of display After switching on, the first Distance screen of the Home section is displayed. The Home section consists of 6 screens. To scroll through the screens it is necessary to press the "POWER" key. From any screen in the Home section, you can: ›... -
Page 18: Computer Mode
4.7 Cumputer mode The on-board computer is able to adapt to various usage scenarios, from commuting to sports use. To move between the available display modes, briefly press the "POWER" key. 4.7.1 "RACE" mode It is the fifth screen of the Home section. In this screen the values in watts (w) of the engine power and cyclist power are expressed in full. -
Page 19: Summary Mode
4.7.2 Resume Mode It is the sixth screen of the Home section. This screen summarizes the variable parameters from the previous screens. 1. Indicate the distance traveled in kilometers (km) since the last reset. 2. Indicates the elapsed time in motion since the last reset. The value is expressed in hours:minutes:seconds. -
Page 20: Menù
4.9 Menù By pressing the "UP"+"DOWN" buttons simultaneously for two seconds, it is possible to open the menu screen. From any screen, by holding down the "POWER" key for 2 seconds, you can return to the last Home screen displayed. Once entered, it is possible to move in the menu with the "UP"... -
Page 21: Brightness Screen
4.9.1 Screen brightness From this screen you can adjust the brightness of the screen. Use the "UP" and "DOWN" keys to scroll through the values from 1 to 10. The selected value is highlighted in the center of the white line. 4.9.2 Change language From this screen you can choose the language of the unit texts. -
Page 22: Weight
4.9.4 Weight From this screen you can set your body weight by choosing a value between 50 and 150 kg. The setting of this datum is not necessary for the correct functioning of the eBike. The value has the sole purpose of making the calculation of calories consumed reliable.Use the up and down keys to scroll through the available items. - Page 23 ERROR CODE DESCRIPTION Battery communication problem. Battery status data may be displayed incorrectly. Check that the wiring and battery contacts are 0001 connected correctly and intact. 0101 Communication problem between drive and HMI. Check that the cables are connected correctly and intact. Speed sensor not detected.
-
Page 24: Resolution Of The Problems
4.10.1 Resolution of the problems PROBLEM SOLUTION The system does not turn on Check that the battery is inserted correctly in place, and that it is charged. Check that the assistance level selected is greater than 0, and that the battery charge level is The assistance does not activate sufficient. -
Page 25: Battery
4.11 Battery The assistance system of the pedal assisted bicycle, in order to work, it needs the presence of the power supply battery. Specifically, the battery is removable, so you can take it out for maintenance actions or when you want to store the vehicle 4.11.1 State of battery loading It is possible to view the battery charge status directly on the assistance system management display. -
Page 26: Loading Battery
To install the battery, proceed as follows: 1. This procedure must be performed without the release key; remove the key if inserted; 2. Align the battery over the oblique tube of the frame by matching the electrical connector (Ref. R – Fig. 13); 3. -
Page 27: Resolution Of The Problems
PRECAUTIONS WHEN CHARGING • Always connect the plug to the battery and then the power plug to the mains; • When recharging is complete, always remove the plug from the mains first and then the plug from the battery; • Always fully recharge the battery; DANGER •... -
Page 28: Terms Of Use And Environment Expected
5. CONDITIONS OF USE AND EXPECTED ENVIRONMENTS 5.1 Expected Use The pedal assisted bicycle is designed and built to be used outdoors, on roads and in private or public environments. particular, the components and the type of pedal assisted bicycle allow you to tackle routes with asphalted surfaces, or with similar characteristics, without particular roughness. -
Page 29: Improper Uses And Contraindications
5.3 Improper use and contoindications The actions described below, which obviously cannot cover the entire range of potential possibilities of "misuse" of the pedal assisted bicycle, are to be considered absolutely prohibited. FORBIDDEN OPERATIONS • Carrying out prohibited operations invalidates the guarantee; •... -
Page 30: Transportation
6.2 Transportation To ensure safe transport in vans, it is necessary to prevent the pedal assisted bicycle from moving. This is obtained by binding it with anchoring bands or cables in good condition. In this regard, the attachment devices must be installed in such a way as not to damage the frame and other parts of the bicycle. -
Page 31: Bicycle Drive Guidance
7.1 Bicycle drive guidance Before using the pedal assisted bicycle in places open to traffic, familiarize yourself with the behaviour of the vehicle. The first uses must be made in private environments away from traffic, other cyclists and obstacles of any kind. The driver must adapt the speed of the pedal assisted bicycle to the road conditions and the presence of other vehicles or pedestrians. -
Page 32: Maintenance
8. MAINTENANCE RISK OF INJURY During all maintenance work, follow the appropriate safety measures. All maintenance operations must be carried out with the battery disconnected from the pedal assisted bicycle and from the battery charger; the bicycle must be placed in a stable manner using special support elements. -
Page 33: Maintenance And Weekly Checks
8.2 Maintenance and weekly checks 8.2.1 Washing and cleaning The cleaning of the pedal assisted bicycle is not only a matter of decorum, but also allows you to immediately detect any defect of the same. To avoid damaging or compromising the functioning of the various components, especially the electrical parts, cleaning must be carried out taking certain precautions. -
Page 34: Technical Assistance And Sare Parts
9. TECHNICAL ASSISTANCE AND SPARE PARTS If you need technical assistance, contact your authorized dealer. In case of installation of non-original parts, the guarantee becomes void! ORIGINAL REPLECEMENT The manufacturer declines all responsibility for damages of any kind caused by the use of non- original spare parts. - Page 35 12. WARRANTY STANDARDS M.B.M. S.r.l. Unipersonale guarantees that its bicycles are free from any manufacturing or workmanship defect. This warranty covers the repair or replacement of any part recognized as defective, subject to the following conditions. TERMS AND CONDITIONS • Guarantee period: the pedal assisted bicycle is guaranteed for 24 months on the mechanical and electrical parts, except for the batteries and all the components subject to wear.
- Page 36 • Transportation fee. Except as provided in this warranty and subject to all other warranties, MBM and its employees and agents shall not be liable for any loss or damage of any kind (including incidental or consequential loss or damage caused by negligence or default) arising out of or relating to any MBM bicycle.
-
Page 37: Check Of Tags And Pictograms
