- Page 1 4500-2P ARCADE USER MANUAL VER101620...
- Page 2 Table of Contents Page 3 Control Panel and button layout cheat sheet Page 4 Controls and navigating through game selection screen Page 5 Playing Doubles and Volume adjustment Setting up Machine to Accept Quarters Page 6 Page 7 De-Activating FreePlay button Page 8 Lifting Up the Tilt Screen Unlatching the Tilt Screen...
-
Page 3: Quick Starting
Control Panel Quick Starting To start playing a game. First find the category by pressing the Player 1_B button until you come to the category that you want. Then use the joystick to navigate through the game selection screen. Push down on the joystick to move down one game at a time, Also you can push to the right to jump through games ten at a time. -
Page 4: Game Selection
Game Selection Game Category is displayed at top left of screen in Game Category - ------> Game List -------------> While on the game selection screen you can push Player1_B button to cycle through the game categories one at a time then you can push down on joystick to cycle down through game list one at a time, or press to the right and cycle through game list TEN at a time. - Page 5 Playing Doubles Some games (donkey kong, pacman, galaga) require players to use the same controls. The original design of these games was based on taking turns using the same controls. As one player would play until his turn ended and then the other player would step up and take his turn on the same controls.
- Page 6 Setting up machine to take quarters Coin Assimulator Figure D Figure E Step 1. Locate the coin assimulator in fornt of the machine and open the coin door. Step 2. Put in a sample quarter into the caddy tray as shown in figures D and E above. Step 3.
- Page 7 De-activate freeplay when using coin acceptor Note that this process is for our Tabletop Lift Model only To finish setting up your machine to take quarters you must de-activate the freeplay button on the control panel and to do this you must open up the machine on the coin door side and look up to the right and you should see something similiar to figure f.
- Page 8 De-activate freeplay on 4 Player Slim model Once you loosen those bolts, you should be able to lift up on the control panel and have it open up to show you the backside. Once there, disconnect the green wire connected to the freeplay button.
- Page 9 Removing front control panel for a narrow doorway (if required) When removed, arcade is 33' wide. (this applies to four player stand up) (1) Remove upper left and upper right screws. Lift panel (2) Remove the 4 screws 2 on the left and 2 under the panel (3) Lift box and gently place against screen while moving through doorway (4) Replace screws into pane once in desired location...
- Page 10 Lifting up the tilt screen Step 1 : Locate the two latches (one on each side) that secure the screen to the unit during shipping. These images are from the top of the machine when the screen is up. To unlatch the screen, you have to reach into the machine from the back (opposite of Coin Door) and reach up through the hole that is in the picture and unlatch the clamp.
- Page 11 This is a view from the bottom inside pointed up Here is a view of the latches from the top side of the machine NOTE: When transporting machine, make sure that you have fastened these latches back down again to prevent damage...
- Page 12 My Games List Setup Start Machine with PC USB Keyboard and mouse wired/wireless If there are no USB ports available you can disconnect one temporarily to plug in your keyboard and mouse...
- Page 13 My Games List Setup Open the Setup Window by pressing the“D” Key “D” Key Open this window...
- Page 14 My Games List Setup Add one game to My Games List by using the mouse...
- Page 15 My Games List Setup Delete one game from My Games List by using the mouse...
- Page 16 My Games List Setup Save My Games List by using the mouse Click “Save” button...
- Page 17 My Games List Setup Show My Games List “Z” Key Open this Window...
- Page 18 My Games List Setup Check My Games then Save...
- Page 19 Hide Adult Games Check “Hide Adult Games” then Save ✔...
