3500-4P
MACHINE SIMPLE
USER MANUAL

Advertisement

loading
Need help?

Need help?

Do you have a question about the 3500-4P and is the answer not in the manual?

Questions and answers

Related Manuals for Creative Arcades 3500-4P

Summary of Contents for Creative Arcades 3500-4P

  • Page 1 3500-4P MACHINE SIMPLE USER MANUAL...

  • Page 2: Quick Start

    Control Panel Quick Start To start playing a game. First find the category by pressing the P1_B button and continue to press it until you come to the category that you want. Then use the joystick to navigate through the game selection screen. Push down on the joystick to move down one game at a time, Also you can push to the right to jump through games ten at a time.

  • Page 3: Game Selection

    Game Selection Game Category is displayed at top left of screen in Game Category - ------> Game List -------------> Begin game selection by choosing the game while on the game selection screen. You can push the blue Player1_b button to cycle through the game categories one at a time and then you can push down on the joystick to cycle down through the game list one at a time.
  • Page 4 Volume Control Figure D Some games may be louder than others and the volume can be adjusted to preference. To adjust the volume you have to open up the machine and locate the amplifier that has 4 knobs on it and looks similiar to Figure D. Once you locate that amplifier you simply just turn the volume knob counter clockwise to lower and clockwise to raise.
  • Page 5 Setting up machine to take quarters Figure D Figure E Step 1. Locate the coin assimulator in front of the machine and open the coin door. Step 2. Put in a sample quarter into the caddy tray as shown in figures D and E above. Step 3.
  • Page 6 De-activate freeplay when using coin acceptor Disabling Freeplay button on Four Player Standup To finish setting up your machine to take quarters you must de-activate the freeplay button on the control panel and to do this you must open up the machine and remove the control panel top.
  • Page 7 Removing front control panel for a narrow doorway (if required) When removed, arcade is 33' wide. (this applies to four player stand up) (1) Remove upper left and upper right screws. Lift panel (2) Remove the 4 screws 2 on the left and 2 under the panel (3) Lift box and gently place against screen while moving through doorway (4) Replace screws into pane once in desired location...
  • Page 8 My led’s are too bright is there a way to turn them down or off? Yes, there is a switch inside the machine behind the coin door that will turn off the led’s. We also have available a dimmer switch that can be installed to turn the lights down or up. My machine wont take my quarter what am I doing wrong? Before your machine will take quarters, you have to put a quarter in the caddy of the coin device.
  • Page 9 How do I change catergories on my game selection screen? Simply by hitting the player 1 ‘a’ button and sometimes the player 1 ‘b’ button but you will see what category you are in. It will be red and on the top left corner saying maze or gun or all and have the number of those games in that category Dragons layer is not working right how come? Exit out of the game and then run a different laserdisc type game like Space Ace and see if the...
