Asus ROG SWIFT PG32UQXR User Manual page 27

3. Color
Display Color Space
Gaming
Color Temp.
Saturation
Six-axis Saturation
Gamma
Color
Input Select
PIP/PBP Setup
• Display Color Space: "sRGB" is recommended when using Microsoft
based systems. "Wide Gamut" is recommended when using Mac OS
systems.
• Color Temp.: Contains 8 modes including 4000K, 5000K, 6500K, 7500K
, 8200K, 9300K, 10000K and User Mode.
• Saturation: The adjusting range is from 0 to 100.
This function is not available when Racing Mode, sRGB Mode or MOBA Mode
is selected.
• Six-axis Saturation: Adjusts the saturation for R, G, B, C, M, Y.
• Gamma: Allows you to set the color mode to 2.6, 2.4, 2.2, 2.0 or 1.8.
4. Input Select
Auto Input Detection
Gaming
HDMI-1
HDMI-2
DisplayPort-1
DisplayPort-2
Color
Input Select
PIP/PBP Setup
• Auto Input Detection: When enabled, the system will automatically
select the latest inserted I/O port.
• HDMI-1, HDMI-2, DisplayPort-1, DisplayPort-2: Manually selects the
input source.
ASUS PG32UQXR Series LCD Monitor
3840x2160 160Hz
Volume 80
3840x2160
160Hz
Volume 80
Input Select GameVisual
DisplayPort-1 Racing Mode
Back Enter Select
Input Select GameVisual
DisplayPort-1 Racing Mode
Back Enter Select
HDR
OFF
Exit
HDR
OFF
Exit
3-5
