  • Page 1 Quick Setup Guide Model: QN-I-210...
  • Page 2 Copyright Information Copyright & trademark specifications are subject to change without prior notice. Copyright © 2018 Quantum® Networks (SG) Pte. Ltd. All Rights Reserved. Quantum Networks® & the logo are trademarks of Quantum Networks (SG) Pte. Ltd. Other brands or products mentioned may be trademarks or registered trademarks of their respective owners.

  • Page 3: Table Of Contents

    Prerequisites ......................5 Network requisites ...................... 5 Connect Access Point ....................5 Step 1 – Create new account on Quantum® RUDDER ..........6 Step 2 - Basic setup ....................7 Step 3 - Setting up device IP address ................ 8 Step 4 –...

  • Page 4: Glossary

    This Quick Setup Guide provides step-by-step instructions on how to set up Quantum Networks® Access Point. After completing the steps described in this Guide, you will be able to install the Access Point (AP) on-site and provide wireless network access to users.

  • Page 5: Before You Begin

    Before you begin Your Quantum Networks® Access Point can work in “Standalone Mode” or can be managed by “RUDDER”. Package contents  Access Point. Prerequisites  Internet access.  Desktop / Laptop / Handheld device.  802.3af / 802.3at PoE Switch / PoE Injector.

  • Page 6: Step 1 - Create New Account On Quantum® Rudder

    Once the account gets validated, it turns the page to “Add License Key” (User will get the license key from respective (Partner / Resource) )  Account on Quantum® RUDDER (Quantum Networks® Cloud Controller) is now ready to use. | www.qntmnet.com...

  • Page 7: Step 2 - Basic Setup

    Step 2 - Basic setup  Connect the WAN port of the Access Point to the network with Internet access.  You should see a new wireless network with SSID QN_XX:XX (where XX:XX are the last four digits of Access Point MAC Address). ...

  • Page 8: Step 3 - Setting Up Device Ip Address

    Step 3 - Setting up device IP address Click “Configure” and set the device IP address by selecting the required options.  Connectivity Mode – Select the connectivity mode.  Protocol - DHCP, Static or PPPoE  Interface – Select interface ...

  • Page 9: Step 4 - Set The Management Mode

    Step 4 – Set the management mode Management Mode Quantum Networks® Access Point can be configured in two modes: RUDDER (on cloud / on-premise) Centralized management of Access Points using Quantum® RUDDER Standalone Independent management of each Access Point Figure 4...

  • Page 10: Step 5 - Access Point Quick Setup In Rudder Mode

    Step 5 - Access Point quick setup in RUDDER Mode  Select “Management Mode” as “RUDDER”, enter Quantum® RUDDER login credentials and click “Proceed”. In the case of on-premise RUDDER, mention the local server IP Address/URL assigned to RUDDER, here.
  • Page 11  Upgrade QNOS version by either downloading from the cloud or by selecting manually from respective location and upgrade or click “Skip Upgrade” to move further.  The user will turn to a page where the user has to select the site and AP group. Figure 7 ...
  • Page 12  Select option Bridge and click “Proceed”.  Configure WLAN (SSID) parameters and click “Proceed”. Parameter Value WLAN Name Define a name for the network SSID Define visible wireless network name Passphrase Configure a passphrase for SSID Note: If you do not want to create WLAN (SSID)/LAN now, click the Skip option.
  • Page 13 Router  Select option Router and click “Proceed”.  Configure WLAN (SSID) and Local subnet parameters and click “Proceed”. Parameter Value WLAN WLAN Name Define a name for the network SSID Define visible wireless network name Password Configure passphrase for SSID Local Subnet IP Address LAN IP address.

  • Page 14: Step 6 - Access Point Quick Setup In Standalone Mode

     Review the Configuration Summary. Click “Reconfigure” if any changes are required or click “Proceed” to complete the configuration. Step 6 - Access Point quick setup in standalone mode Figure 14  Select “Management Mode” as “Standalone” if each Access Point is to be configured and managed individually.
  • Page 15 Bridge  Select option Bridge and click “Proceed”.  Configure WLAN (SSID) parameters and click “Proceed”. Parameter Value Country Select country for radio management. Timezone Select timezone for RUDDER management. WLAN Name Define a name for the network. SSID Define visible wireless network name. Passphrase Configure a passphrase for SSID.
  • Page 16 Router  Select option Router and click “Proceed”.  Configure WLAN (SSID) and Local subnet parameters and click “Proceed”. Parameter Value WLAN Country Select country for radio management. Timezone Select timezone for RUDDER management. WLAN Name Define a name for the network. SSID Define visible wireless network name.

  • Page 17: Reset Access Point To Factory Defaults

    Reset Access Point to factory defaults o Power on the Access Point o Push the reset button on the back panel and hold it for 10 seconds. o Access Point would restart with factory defaults Access Point default login detail With standalone mode: User Name: Created while doing "Quick Setup"...
