AcuRite 01531 Instruction Manual

Professional weather center
Hide thumbs Also See for 01531:
Table of Contents

Advertisement

Quick Links

CONTENTS
Package Contents .................. 2
Product Registration ............... 2
Back of Display...................... 6
Setup .................................... 7
5-in-1 Sensor Setup ................ 7
Display Setup ........................ 8
Backlight Settings ................... 9
Placement Guidelines ............10
Questions?
(877) 221-1252 or visit www.AcuRite.com.
SAVE THIS MANUAL FOR FUTURE REFERENCE.
Professional Weather Center
Rainfall Tracking ...................13
Weather Ticker .....................14
Troubleshooting ....................15
Care & Maintenance.............17
Calibration ...........................17
Specifications........................19
FCC Information ...................19
Customer Support ................ 20
Warranty............................. 20
Contact Customer Support at
Instruction Manual
model 01512 / 01531

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 01531 and is the answer not in the manual?

Questions and answers

DANL
April 13, 2025

CLICKING NOISE WHEN NOT COVERING THE SOLAR PANAL

0
1 comments:
Mr. Anderson
May 14, 2025

The clicking noise in the AcuRite 01531 may be related to the cooling fan.

This answer is automatically generated

0
Stan
April 24, 2025

I have no clue how to change temp from C to F. There is no direction how to do it or a switch Thanks

0

Subscribe to Our Youtube Channel

Related Manuals for AcuRite 01531

Summary of Contents for AcuRite 01531

  • Page 1: Table Of Contents

    Instruction Manual Professional Weather Center model 01512 / 01531 CONTENTS Unpacking Instructions ... 2 5-in-1 Sensor Installation..11 Package Contents ....2 Using the Weather Center ..12 Product Registration ....2 Rainfall Tracking ....13 Weather Ticker .....14 Features & Benefits: 5-in-1..3 Features &...

  • Page 2: Unpacking Instructions

    Congratulations on your new AcuRite product. To ensure the best possible product performance, please read this manual in its entirety and retain it for future reference. Unpacking Instructions Remove the protective film that is applied to the LCD screen prior to using this product.

  • Page 3: Features & Benefits: 5-In-1

    Features & Benefits 5-in-1 SENSOR 5. Temperature & Humidity Sensors 1. Rainfall Collector Funnel (internal) 2. Solar Cell Panel 6. Mounting Point Converts sunlight into power to run internal aspirating fan. 7. Wind Speed Anemometer Internal Aspirating Fan 8. Wind Direction Vane (not shown) Draws ambient air into 9.

  • Page 4: Features & Benefits: Display

    Features & Benefits Display Unit...
  • Page 5 1. Previous 2 Wind Directions 19. SET Button For setup preferences. 2. Current Wind Speed Button 3. Current Wind Direction For setup preferences. 4. Current Indoor Temperature 21. SELECT Button Arrow icon indicates direction Press to change the WEATHER temperature is trending. SELECT category data being 5.

  • Page 6: Back Of Display

    Back of Display Unit BACK OF DISPLAY UNIT 1. Integrated Hang Hole For easy wall mounting. Button Dimmer control while using power adapter. Activates momentary backlight while on battery power. 6. A-B-C Switch 3. Plug-in for Power Adapter ID code that must match 5-in-1 sensor’s A-B-C switch to ensure 4.

  • Page 7: Setup

    Install or Replace Batteries shown. Follow the polarity (+/-) diagram in the battery Batteries MUST be installed for compartment. this product to operate. AcuRite recommends high quality alkaline 3. Replace the battery cover. or lithium batteries for the best product performance. Heavy duty...

  • Page 8: Display Setup

    Display Unit Setup AcuRite recommends high quality alkaline batteries for the best product performance. Heavy duty or rechargeable batteries are not recommended. Set the A-B-C Switch Plug Power Adapter into Electrical Outlet The A-B-C switch is located inside the battery compartment. It can be set to A, B or C.

  • Page 9: Set The Time, Date & Units

    Set the Time, Date & Units Press the “ SE T ” button, located on the front of the display, to enter SET MODE. Once in set mode, the preference you are currently setting will blink on the display. To adjust the currently selected (flashing) item, press and release the “ “...

  • Page 11: 5-In-1 Sensor Installation

    5-in-1 Sensor Installation Guidelines INSTALLATION HEIGHT Mount the sensor at a minimum height of 5 feet (1.5 meters) off the ground, in an open area. Higher is better for wind measurements - The National Weather Service recommends 33 feet high! MOUNTING OPTIONS The included mounting bracket it designed to screw directly onto wooden posts or surfaces that are 2x4 or larger.

  • Page 12: Using The Weather Center

    Weather Forecast AcuRite’s patented Self-Calibrating Forecasting provides your personal forecast of weather conditions for the next 12 to 24 hours by collecting data from the sensor in your backyard. It generates a forecast with pinpoint accuracy - personalized for your exact location.

  • Page 13: Rainfall Tracking

    Rainfall Tracking This weather station features enhanced tracking of historical rainfall data. Rain accumulation data is recorded for today, over all-time, by year, by month, and by rainfall event. Press the “RAINFALL” button to review rainfall records. The icon is shown on the display while historical data is being viewed.

  • Page 14: Weather Ticker

    Weather Ticker ™ The Weather Ticker automatically flashes your real-time weather information and alerts as text in the lower part of the display screen. The possible WEATHER TICKER messages are as follows: HEAT INDEX-XX WINDCHILL-XX DEW POINT-XX IT FEELS LIKE XX OUTSIDE 7 DAY HIGH TEMP.

  • Page 15: Troubleshooting

    Troubleshooting Problem Possible Solution • Relocate the display and/or the 5-in-1 sensor. The units must be within 330 ft (100 m) of each other. • Make sure both units are placed at least 3 feet (.9 m) away from electronics that may interfere with the wireless communication (such as TVs, microwaves, computers, etc).
  • Page 16 CLEAR ALL/RESET button, located in the battery compartment of the display. Date and time will need to be entered after a reset. If your AcuRite product does not operate properly after trying the troubleshooting steps, visit www.AcuRite.com or call (877) 221-1252 for assistance.

  • Page 18: Calibration

    • To adjust the rainfall reading by 2% turn both screws 1/8 of a turn. • To adjust the rainfall reading by 4% turn both screws 1/4 of a turn. • To adjust the rainfall reading by 8% turn both screws 1/2 of a turn. Watch the video at www.acurite.com/5n1...

  • Page 19: Specifications

    If your AcuRite product does not operate properly, visit www.AcuRite.com or call (877) 221-1252 for assistance. For more information, visit our Knowledge Base at http://www.AcuRite.com/kbase FCC Information This device complies with part 15 of FCC rules. Operation is subject to the following two conditions: 1- This device may NOT cause harmful interference, and 2- This device must accept any interference received, including interference that may cause undesired operation.

  • Page 20: Customer Support

    Customer Support AcuRite customer support is committed to providing you with best-in- class service. For assistance, please have the model number of this product available and contact us in any of the following ways: (877) 221-1252 AcuRite Visit us at www.
  • Page 24 Plan your day with confidence ™ www.AcuRite.com ©Chaney Instrument Co. All rights reserved. AcuRite is a registered trademark of the Chaney Instrument Co., Lake Geneva, WI 53147. All other trademarks and copy- rights are the property of their respective owners. AcuRite uses patented technology.
