Jonsered PR521ES Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
IMPORTANT MANUAL
OWNER'S MANUAL
MODEL NUMBER:
PR521ES
SNOW THROWER
Gasoline containing up to 10% ethanol (E10) is acceptable for use in this machine.
The use of any gasoline exceeding 10% ethanol (E10) will void the product warranty.
Always Wear Eye Protection During Operation
580 84 98-32
Do Not Throw Away
WARNING:
Read the Owner's Manual and
fol low all Warnings and Safety
In struc tions. Fail ure to do so
can result in serious injury.
07.12.12 BD
Printed in the U.S.A.

Advertisement

Table of Contents
loading

Related Manuals for Jonsered PR521ES

Summary of Contents for Jonsered PR521ES

  • Page 1 WARNING: MODEL NUMBER: Read the Owner's Manual and fol low all Warnings and Safety PR521ES In struc tions. Fail ure to do so can result in serious injury. SNOW THROWER Gasoline containing up to 10% ethanol (E10) is acceptable for use in this machine.

  • Page 2: Safety Rules

    CONGRATULATIONS on your purchase of a new snow thrower. It has been designed, engineered and man u fac tured to give best possible dependability and per for mance. Should you experience any problem you cannot easily remedy, please contact your nearest authorized service center. We have competent, well-trained tech ni cians and the proper tools to service or repair this unit.

  • Page 3: Product Specifications

    Operation Maintenance and Storage 1. Do not put hands or feet near or under rotating parts. 1. Check shear bolts and other bolts at frequent intervals Keep clear of the discharge opening at all times. for proper tightness to be sure the equipment is in safe working condition.

  • Page 4: Table Of Contents

    TABLE OF CONTENTS SAFETY RULES ............2-3 MAINTENANCE ............. 12-16 PRODUCT SPECIFICATIONS ........3 STORAGE ..............17 CUSTOMER RESPONSIBILITIES ........ 3 TROUBLESHOOTING ..........18 SAFETY AND INSTRUCTIONAL DECALS ....4 REPAIR PARTS ............. 20-31 SETUP................ 5-6 WARRANTY ..............32 OPERATION ............7-11 KNOW YOUR SNOW THROWER READ THIS OWNER'S MANUAL AND ALL SAFETY RULES BEFORE OPERATING YOUR SNOW THROWER.

  • Page 5: Setup

    Setup Loose Parts Use the chart below to verify that all parts have been shipped. Procedure Description Qty. No parts required – Unfold the handle. Carriage bolts Install the discharge chute. Shoulder Bolt Install the discharge chute. Flange nuts Install the discharge chute. Washers Install the discharge chute.
  • Page 6 3. Filling the Engine with Oil Product Overview ENGINE See engine manual. LUBRICATION NOTE: SAE 10W30 or SAE 5W30 oil is acceptable for use in cold temperatures if engine is difficult to start. NOTE: Although multi-viscosity oils (5W30, 10W30 etc.) improve starting in cold weather, these multi-viscosity oils will result in increased oil consumption when used above 32°F.

  • Page 7: Operation

    Operation NOTE: For best results, purchase only the quantity of gasoline that you expect to use in 30 days. Otherwise, you may add fuel stabilizer to newly purchased gasoline NOTE: Determine the left and right sides of the machine to keep it fresh for up to 6 months. from the normal operating position.
  • Page 8 Starting the Engine 3. Firmly push in the primer 2 times with your thumb, holding the primer in a for a second before releasing it each time (Figure 11). 1. Push key in (Figure 9). Figure 11 1. Primer Figure 9 1.
  • Page 9 Engaging the Auger Blades The electrical cord can become damaged, causing To engage the auger blades, hold the control bar against a shock or fire. the handle (Figure 14). Thoroughly inspect the electrical cord before plug- ging it into a power source. If the cord is damaged, do not use it to start the snowthrower.
  • Page 10 Adjusting the Discharge IMPORTANT: During initial operation there may be wear between the auger blades and the scraper bar. Maximum Chute and Chute Deflector performance, both snow throwing and driving, occurs when there is zero clearance between these two parts (Figure 16).
  • Page 11 Clearing a Clogged Operating Tips Discharge Chute The auger blades can throw stones, toys, and other foreign objects and cause serious personal injury Hand contact with the rotating auger blades inside to the operator or to bystanders. the discharge chute is the most common cause of injury associated with snow throwers.

  • Page 12: Maintenance

    Maintenance NOTE: Determine the left and right sides of the machine from the normal operating position. Check for Loose Fasteners Clean / Inspect Snow Thrower Clean / Replace V-Belts Check / Replace Auger Blades and Scraper Bar Check Fuel Lines and Electrical Wires Check Engine Oil Level Change Engine Oil Inspect Muffler...
  • Page 13 Adjusting the Control Cable Adjusting the Control Cable 1. With the control bar disengaged, unhook and move Checking the Control Cable the control cable to the highest position. (Figure 21). Release the control bar to remove the slack in the control cable (Figure 20).
  • Page 14 Changing the Engine Oil 7. Clean around the oil filler cap/dipstick (Figure 24). 8. Unscrew the oil fill cap/dipstick and remove it (Figure 25). Run the engine a few minutes before changing the 9. With the snowthrower in the operating position, care- oil to warm it.
  • Page 15 Servicing the Spark Plug 5. Remove the oil fill cap. 6. Remove the shroud assembly (Figure 27). 7. Install the oil fill cap. Use a NGK BPR6ES, Champion RN9YC, or BOSCH WR6DC spark plug or equivalent. 8. Disconnect the spark plug wire from the spark plug (Figure 28).
  • Page 16 Replacing the Drive Belt 4. Install the new drive belt, routing it as shown in (Figure 31). NOTE: Route the new drive belt first around the engine If drive belt becomes worn, oil-soaked, excessively pulley, then the idler pulley, and finally around the drive cracked, frayed, or otherwise damaged, replace the belt.

  • Page 17: Storage

    Storage ENGINE OIL Drain oil (with engine warm) and replace with clean engine oil. (See “Changing the Engine Oil” section of this man ual). Storing the Snowthrower CYLINDER Immediately prepare your snow thrower for storage at 1. Remove spark plug. the end of the season or if the unit will not be used for 30 2.

  • Page 18: Troubleshooting

    Troubleshooting See appropriate section in manual unless directed to an authorized service center/department. PROBLEM CAUSE CORRECTION Does not start 1. Safety ignition key is not inserted. 1. Insert safety ignition key. 2. Out of fuel. 2. Fill fuel tank with fresh, clean gasoline. 3.
  • Page 19 SERVICE NOTES...

  • Page 20: Repair Parts

    REPAIR PARTS SNOW THROWER - - MODEL NUMBER PR521ES (96184000102) AUGER ASSEMBLY 06.03.001-D PART DESCRIPTION 532 44 27-59 BLADE 580 85 55-01 BEARING SUPPORT 532 43 76-22 BALL BEARING 812 00 00-28 RETAINING RING 817 06 04-08 1/4-20 X 3/8 HEX SCREW...
  • Page 21 REPAIR PARTS SNOW THROWER - - MODEL NUMBER PR521ES (96184000102) CHUTE ASSEMBLY PART DESCRIPTION 532 43 76-55 CHUTE (BLACK) 532 43 76-43 DEFLECTOR (BLACK) 532 43 76-42 HANDLE (BLACK) 532 43 73-18 CARRIAGE BOLT 5/16-18 UNC 873 97 05-00 NUT LOCK HEX W/INS 5/16-18...
  • Page 22 REPAIR PARTS SNOW THROWER - - MODEL NUMBER PR521ES (96184000102) HANDLE ASSEMBLY PART DESCRIPTION 580 85 70-01 UPPER HANDLE 580 86 04-01 BAIL 532 19 15-74 HANDLE BOLT 532 44 50-19 WING KNOB 532 43 75-06 AUGER CONTROL DECAL 06.07.001-A NOTE: All component dimensions given in U.S.
  • Page 23 REPAIR PARTS SNOW THROWER - - MODEL NUMBER PR521ES (96184000102) DRIVE ASSEMBLY 06.01.001-B PART DESCRIPTION 580 85 53-01 IDLER ARM 532 16 60-43 IDLER PULLEY 532 43 48-59 RETURN SPRING 817 06 06-20 SCREW 3/8-16 X 1-1/4 (TORQUE 13-18 FT-LBS)
  • Page 24 REPAIR PARTS SNOW THROWER - - MODEL NUMBER PR521ES (96184000102) ENGINE ASSEMBLY 06.02.009-A PART DESCRIPTION 580 81 06-01 ENGINE COMPLETE LCT PW3HK1840018E 580 85 02-01 KEY SWITCH 532 43 48-74 CHOKE LEVER 532 43 62-35 PRIMER BULB 532 43 55-78 SCREW 5/16-24 X 2.00 HHCS...
  • Page 25 REPAIR PARTS SNOW THROWER - - MODEL NUMBER PR521ES (96184000102) FRAME ASSEMBLY PART DESCRIPTION 580 85 62-01 FRAME WELDMENT 872 11 04-07 BOLT, CARRIAGE 1/4-20 X 7/8 580 50 26-01 BAR, SCRAPER UHMW 532 44 21-46 SCRAPER, SKIRT 819 09 12-16...
  • Page 26 REPAIR PARTS SNOW THROWER - - MODEL NUMBER PR521ES (96184000102) SHROUD ASSEMBLY 06.04.004-A PART DESCRIPTION 532 44 39-21 PLENUM 532 44 39-24 NON – DRIVE COVER 532 44 39-25 DRIVE COVER SIDE 819 13 13-16 WASHER 13/32 X 13/16 GA 532 42 88-67 BOLT 5/16-18 X .75...
  • Page 27 REPAIR PARTS SNOW THROWER - - MODEL NUMBER PR521ES (96184000102) SHROUD ASSEMBLY 06.04.013-B PART DESCRIPTION 532 44 39-26 TOP COVER 532 43 76-48 REAR UPPER COVER 817 41 13-12 BOLT 13-16 X .75 532 19 66-88 THREADED CLIP 532 43 48-68...
  • Page 28 REPAIR PARTS SNOW THROWER - - MODEL NUMBER PR521ES (96184000102) ENGINE, LCT COMPLETE ENGINE- 580810601 *Included with part #1 Carburetor Repair Kit Electric Start Only NOTE: All component dimensions given in U.S. inches. 1 inch = 25.4 mm IMPORTANT: Use only Original Equipment Manufacturer (O.E.M.) replacement parts.
  • Page 29 REPAIR PARTS SNOW THROWER - - MODEL NUMBER PR521ES (96184000102) ENGINE, LCT COMPLETE ENGINE- 580810601 KEY PART NO. NO. DESCRIPTION 532 43 80-06 Cylinder Head Assy (136cc) 532 43 80-11 Push Rod Kit (136cc)(incl. valve cover gskt) 532 43 79-97...

  • Page 30: Warranty

    LIMITED WARRANTY The Manufacturer warrants to the original consumer purchaser that this product as manufactured is free from defects in mate- rials and work man ship. For a period of two (2) years from date of purchase by the original consumer purchaser, we will repair or replace, at our option, without charge for parts or labor incurred in replacing parts, any part which we find to be defective due to materials or workmanship.
